Description
The 1184 is a 3V battery powered wireless carbon
monoxide (CO) detector that provides early warning
when its electrochemical sensing technology measures
carbon monoxide levels in the air.
The detector consists of an electrochemical carbon
monoxide sensor assembly coupled with an 1100 Series
wireless transmitter. The transmitter can send alarm,
trouble, tamper and low battery condition messages to
the alarm panel.
The 1184 is an ideal carbon monoxide detector for
difficult to wire locations, applications where room
aesthetics are critical or where hazardous materials
exist.
Compatibility
All DMP 1100 Series Wireless Receivers and Panels
What is Included
The 1184 Wireless Carbon Monoxide Detector package includes the following items:
•
One 1184 Carbon Monoxide Detector with DMP wireless transmitter installed
•
One 3V lithium CR123-Fire battery
•
Hardware pack
•
Zone name and number label
•
Serial number labels
Transmitter Serial Number
For your convenience, an additional pre-printed serial number label is included. Prior to installing the device,
record the serial number or place the pre-printed serial number label on the panel programming sheet. This number
is required during programming. As needed, use the zone name and number label to identify a specific transmitter.
Programming the Transmitter in the Panel
Locate and record the detector serial number. This number is required during programming. Program the device as
an Emergency (EM) type zone in Zone Information during panel programming. At the Serial Number: prompt, enter
the eight-digit serial number. Continue to program the zone as directed in the panel programming guide.
Note: When a receiver is installed, powered up, or the panel is reset, the supervision time for transmitters is reset.
If the receiver has been powered down for more than one hour, wireless transmitters may take up to an additional
hour to send a supervision message unless tripped, tampered, or powered up. This operation extends battery life for
transmitters. A missing message may display on the keypad until the transmitter sends a supervision message.
Transmitted Signal Outputs
The CO detector provides the signals listed in the table:
1184 Wireless Carbon Monoxide Detector
Signal
Alarm
Low battery
Detector head removed
Inst alla tIon GuIde
Figure 1: Carbon Monoxide Detector
Keypad Display
ALARM
LO BAT
TROUBLE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DMP Electronics 1184
Summary of Contents for DMP Electronics 1184
- Page 1 Figure 1: Carbon Monoxide Detector Compatibility All DMP 1100 Series Wireless Receivers and Panels What is Included The 1184 Wireless Carbon Monoxide Detector package includes the following items: • One 1184 Carbon Monoxide Detector with DMP wireless transmitter installed •...
- Page 2 To remove the detector from the mounting base, grasp the detector and turn it counterclockwise approximately 15 degrees. The detector should snap off of the mounting base. See Figure 3. Figure 3: Exploded View of CO Detector Digital Monitoring Products 1184 Detector Installation Guide...
- Page 3 The following situations can reduce battery life expectancy: • If a receiver is unplugged or not installed. • Frequent transmissions, such as how often the detector is tested. • When installed in extreme hot or cold environments. Digital Monitoring Products 1184 Detector Installation Guide...
-
Page 4: Fcc Information
FCC Information This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications made by the user and not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
