ProForm PFTL72580 User Manual

Proform user's manual treadmill pftl72580
Hide thumbs

Advertisement

Table of Contents

Model No. PFTL72580
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
VISIT OUR WEBSITE:
www.proformfitness.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
¨
USER'S MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL72580 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ProForm PFTL72580

Summary of Contents for ProForm PFTL72580

  • Page 1 Model No. PFTL72580 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satis- faction through direct assistance from our factory.

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    2. Use the treadmill only as described in this manual. 3. Place the treadmill on a level surface, with at least eight feet of clearance behind it. Do not place the treadmill on any surface that blocks air openings.
  • Page 4 22. Inspect and tighten all parts of the treadmill regularly. 23. Never drop or insert any object into any opening. DANGER: Always unplug the power cord immediately after use, before cleaning the treadmill, and before performing the main- tenance and adjustment procedures de- WARNING: Before beginning this or any exercise program, consult your physician.

  • Page 5: Before You Begin

    The model number of the treadmill is PFTL72580. The serial num- ber can be found on a decal attached to the treadmill (see the front cover of this manual for the location).

  • Page 6: Assembly

    Adhesive Clip onto the base of one of the Uprights (15). Press the Allen Wrench (24) into the Adhesive Clip. 4. Make sure that all parts are tightened before you use the treadmill. Place a mat under the treadmill to protect the floor or carpet.

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT Your treadmill features a walking belt coated with PERFORMANT LUBE , a high-performance lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or the walking plat- form. They will deteriorate the walking belt and cause excessive wear.

  • Page 8: Console Diagram

    Step onto the foot rails of the treadmill. Find the clip attached to the key (see the drawing above), and slide the clip onto the waistband of your clothing. Follow the steps below to operate the console.
  • Page 9 STOP button for two seconds. Adjust the incline of the treadmill as desired To change the incline of the treadmill, press the INCLINE buttons. Each time one of the buttons is pressed, the incline will change by 0.5%. The but- tons can be held down to change the incline quickly.
  • Page 10 TIME/INCLINE display. This number is the maxi- mum incline that the treadmill will reach during the selected program. If you want to change the maximum incline setting, press the INCLINE setting can be from 4% to 10%. If the setting is in- creased, the difficulty level of the entire program will increase.
  • Page 11 The incline of the treadmill can be changed by pressing the INCLINE buttons. The time remaining in the program will be shown in the TIME/INCLINE display.

  • Page 12: How To Fold And Move The Treadmill

    2. Move your right hand to the position shown and hold the treadmill firmly. Using your left hand, pull the latch knob to the left and hold it. Raise the treadmill until the latch pin is aligned with the hole in the catch. Insert the latch pin into the catch.

  • Page 13: How To Move The Treadmill

    Do not hold or push on the book holder or the book holder may be damaged. 2. Tilt the treadmill back until it rolls freely on the front wheels. Carefully move the treadmill to the desired location. Never move the treadmill without tipping it back. To reduce the risk of injury, use extreme caution while moving the treadmill.

  • Page 14: Maintenance And Trouble-Shooting

    2. SYMPTOM: THE POWER TURNS OFF DURING USE a. Check the circuit breaker located on the treadmill frame near the power cord (see 1. c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 15 Reed Switch Screw (109) and move the Reed Switch slightly. Retighten the Screw. Re-attach the hood, and run the treadmill for a few minutes to check for a correct speed reading. 5. SYMPTOM: The walking belt slows when walked on a.

  • Page 16: Conditioning Guidelines

    It may also be helpful to use one of the consoleÕs FAT BURN programs (see pages 10 to 13). For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be Òaerobic.Ó...

  • Page 17: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 18: Part List

    PART LISTÑModel No. PFTL72580 No. Qty. Description Center Track Foot Rail Left Foot Rail Cap Front Roller Adjustment Nut Isolator Bumper Platform Screw Walking Platform Frame Pivot Bolt Frame Pivot Spacer Walking Belt Front Roller/Pulley Small Screw Motor Belt Upright/Base...
  • Page 19 No. Qty. Description Magnet Incline Reed Switch Reed Switch Screw Reed Switch Clip 14Ó White Wire, 2 F 8Ó White Wire, M/F 4Ó White Wire, M/F 4Ó Black Wire, 2 F 4Ó Black Wire, M/Ring 9Ó Black Wire, M/F Specifications are subject to change without notice. For information about ordering replacement parts, see the back cover of this manual.

  • Page 22: Ordering Replacement Parts

    Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: ¥ The MODEL NUMBER OF THE PRODUCT (PFTL72580). ¥ The NAME OF THE PRODUCT (PROFORM ¥ The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual).

This manual is also suitable for:

725ex
