Model No. PFTL66906.0
USER'S MANUAL
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–4 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Visit our website at
Read all precautions and instruc-
tions in this manual before using
www.proform.com
this equipment. Save this manual
new products, prizes,
for future reference.
fitness tips, and much more!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PFTL66906.0 and is the answer not in the manual?

Questions and answers

Related Manuals for ProForm PFTL66906.0

Summary of Contents for ProForm PFTL66906.0

  • Page 1 Model No. PFTL66906.0 USER'S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY.

  • Page 2: Table Of Contents

    HOW TO FOLD AND MOVE THE TREADMILL ........

  • Page 3: Important Precautions

    11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 9. To purchase a surge suppressor, see your local PROFORM dealer or call the toll- free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store.
  • Page 4 SAVE THESE INSTRUCTIONS The decals shown here have been placed on your treadmill. If a decal is missing, or if it is illegible, please call the toll-free telephone number on the front cover of this manual and order a free replacement decal.

  • Page 5: Before You Begin

    Adjustment Bolts ® number and serial number before calling. The model number of the treadmill is PFTL66906.0. The serial number can be found on a decal attached to the tread- mill (see the front cover of this manual for the location).

  • Page 6: Assembly

    3/4” Tek Screw (58)–8 top of the walking belt or the shipping carton. This is a normal condition and does not affect treadmill perfor- mance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner.
  • Page 7 3. With the help of a second person, carefully tip the treadmill onto its right side as shown. Partially fold the Frame (86) so the treadmill is more stable. Do not fully fold the treadmill until it is completely assembled.
  • Page 8 8. Make sure that all parts are properly tightened before you use the treadmill. Note: Extra hardware may be included. Keep the included hex keys in a secure place; the large hex key is used to adjust the walking belt (see page 20).

  • Page 9: How To Plug In Power Cord

    (see drawing 1 at the right). To purchase a surge suppressor, see your local PROFORM dealer or call the toll-free telephone number on the front cover of this man- ual and order part number 146148, or see your local electronics store.

  • Page 10: Console Diagram

    When you select the manual mode of the console, you can change the speed and incline of the treadmill with the touch of a button. As you exercise, the console will display continuous exercise feedback. You can even...

  • Page 11: How To Turn On The Power

    Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 10) and slide the clip onto the waistband of your clothes.
  • Page 12 If desired, press the Display button repeatedly until the upper part of the display shows the information you are most interested in viewing.
  • Page 13 Current Segment column and the column to the right will flash and a series of tones will sound. If the speed and/or incline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the display to alert you.

  • Page 14: How To Use A Preset Program

    To continue the cross trainer program, step onto the treadmill, slide the clip back onto the waistband of your clothes, and press the Start button. The treadmill will auto- matically adjust to the speed and incline settings for the next segment.
  • Page 15 If the speed and/or in- cline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the display to alert you.
  • Page 16 The lower right part of the display will show the total number of hours that the treadmill has been operated. In addition, an “E” for English miles or an “M” for metric kilometers will appear in the lower part of the display.

  • Page 17: How To Fold And Move The Treadmill

    HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If this is not done, the treadmill may be per- manently damaged. Next, unplug the power cord. CAUTION: You must be able to safely lift 45 pounds (20 kg) to raise, lower, or move the treadmill.
  • Page 18 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the treadmill with your right hand as shown. Pull the latch knob to the left and hold it. Pivot the frame downward until it is past the latch pin. 2. Hold the metal frame firmly with both hands, and lower it to the floor.

  • Page 19: Troubleshooting

    PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see the drawing above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
  • Page 20 Screw (100), move the Reed Switch slightly, and then retighten the Screw. Reattach the Hood (not shown), and run the treadmill for a few minutes to check for a correct speed reading. PROBLEM: The walking belt slows when walked on SOLUTION: a.

  • Page 21: Conditioning Guidelines

    For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”...

  • Page 22: Suggested Stretches

    SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.
  • Page 23 NOTES...

  • Page 24: Part List

    PART LIST—Model No. PFTL66906.0 No. Qty. Description Hood 3/4” Screw Motor Belt Motor Tension Bolt Fan Screw Motor Star Washer Optic Switch Star Washer Drive Motor Foot Rail Cover Reed Switch Latch Warning Decal Frame Spacer Frame Pivot Bolt Walking Platform...

  • Page 25: Exploded Drawing

    EXPLODED DRAWING A—Model No. PFTL66906.0 R0507A...
  • Page 26 EXPLODED DRAWING B—Model No. PFTL66906.0 R0507A...
  • Page 27 EXPLODED DRAWING C—Model No. PFTL66906.0 R0507A 73 90...

  • Page 28: Ordering Replacement Parts

    • the MODEL NUMBER of the product (PFTL66906.0) • the NAME of the product (PROFORM 675 CROSSTRAINER treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) • the KEY NUMBER AND DESCRIPTION OF THE PART(S) (see the EXPLODED DRAWING and the PART LIST on pages 24 to 27) ICON Health &...
