Model No. PFTL54806.0
Serial No.
Serial Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if parts are
damaged or missing, PLEASE
CONTACT OUR CUSTOMER
SERVICE DEPARTMENT
DIRECTLY.
CALL TOLL-FREE:
1-888-533-1333
Mon.–Fri. 6 a.m.–6 p.m. MST
Sat. 8 a.m.–5 p.m. MST
ON THE WEB:
www.proformservice.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ProForm PFTL54806.0
Summary of Contents for ProForm PFTL54806.0
- Page 1 Model No. PFTL54806.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if parts are damaged or missing, PLEASE CONTACT OUR CUSTOMER SERVICE DEPARTMENT DIRECTLY. CALL TOLL-FREE: 1-888-533-1333 Mon.–Fri.
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ -
Page 3: Important Precautions
11. Use only a single-outlet surge suppressor that meets all of the specifications described on page 12. To purchase a surge suppressor, see your local PROFORM dealer or call the toll- free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store. - Page 4 21. When folding or moving the treadmill, make sure that the storage latch is fully closed. 22. Do not change the incline of the treadmill by placing objects under the treadmill. 23. Inspect and properly tighten all parts of the treadmill regularly.
-
Page 5: Before You Begin
Adjustment Bolts ® number and serial number before contacting us. The model number of the treadmill is PFTL54806.0. The serial number can be found on a decal attached to the treadmill (see the front cover of this manual for the lo- cation). -
Page 6: Assembly
During shipping, a small amount of lubricant may be transferred to the top of the walking belt or the shipping carton. This does not affect treadmill performance. If there is lubricant on top of the walking belt, simply wipe off the lubricant with a soft cloth and a mild, non-abrasive cleaner. - Page 7 (32), and two Wheel Housing Nuts (43). 4. Position the Base (52) as close to the front of the treadmill as possible, as shown. See drawing 4a. Locate the strap in the lower end of the Right Upright (54). Wrap the strap around the Wire Harness (39) and secure the strap using the included plastic tie.
- Page 8 5. See the left inset drawing. Identify the two Frame Spacers (11). Open the included packet of grease, and apply grease to both sides of both Frame Spacers. Then, identify the outer side of each Frame Spacer. Hold a Frame Spacer (11) between the Right Upright (54) and the Lift Frame (23), with the outer side of the Frame Spacer facing the Right Upright.
- Page 9 7. Set the Console (91) face-down on a soft sur- face to avoid scratching the Console. Hold the Right Handrail (33), which has a large hole in the indicated location, near the Console. Next, insert the console wire into the hole in the side of the Right Handrail (33).
- Page 10 Pan (66) and the Hood (65). Be careful not to overtighten the Belly Pan Screws. 12. See the lower drawing. Position the Uprights (53, 54) so that the treadmill Frame (51) is cen- tered between the Uprights. See steps 2, 5, and 6. Firmly tighten the two Colored Patch Frame Bolts (1) and the four Upright Bolts (2).
- Page 11 (48). Then, tighten the knob onto the pin. 14. Make sure that all parts are properly tightened before you use the treadmill. Keep the included hex key in a secure place. The hex key is used to adjust the walking belt (see page 21). To protect the floor or carpet, place a mat under the treadmill.
-
Page 12: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge sup- pressor, see your local PROFORM dealer or call the toll-free telephone number on the front cover of this manual and order part number 146148, or see your local electronics store. -
Page 13: Console Diagram
When you select the manual mode of the console, you can change the speed and incline of the treadmill with the touch of a button. As you exercise, the console will display continuous exercise feedback. You can even... -
Page 14: How To Turn On The Power
Next, stand on the foot rails of the treadmill. Find the clip attached to the key (see the drawing on page 13) and slide the clip onto the waistband of your clothes. - Page 15 Step onto the foot rails, press the Stop button, and adjust the incline of the treadmill to the lowest setting. The incline must be at the lowest setting when the treadmill is folded to the storage posi- tion or the treadmill will be damaged.
-
Page 16: How To Use A Preset Program
If the speed and/or in- cline of the treadmill is about to change, the speed setting and/or the incline setting will flash in the display to alert you. - Page 17 The lower right part of the display will show the total number of hours that the treadmill has been operated. In addition, an “E” for English miles or an “M” for metric kilometers will appear in the lower part of the display.
-
Page 18: How To Fold And Move The Treadmill
1. Hold the handrails and place one foot against one of the wheels. Do not pull back on the frame. 2. Tilt the treadmill backward until it rolls freely on the wheels, and carefully move the treadmill to the desired location. - Page 19 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Next, lower the frame until it is past the latch pin.
-
Page 20: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please see the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a. - Page 21 Be careful to keep the walking belt centered. Then, plug in the power cord, insert the key, and run the treadmill for a few minutes. Repeat until the walking belt is properly tightened. c. If the walking belt still slows when walked on, please see the front cover of this manual.
-
Page 22: Conditioning Guidelines
For maximum fat burning, adjust the speed and incline of the treadmill until your heart rate is near the middle number in your training zone. Aerobic Exercise If your goal is to strengthen your cardiovascular sys- tem, your exercise must be “aerobic.”... -
Page 23: Part List
PART LIST—Model No. PFTL54806.0 To locate the parts listed below, see the EXPLODED DRAWING on pages 24 to 27. Qty. Description Colored Patch Frame Bolt Upright Bolt/ Lift Frame Bolt Console Fan Console Screw Handrail Star Washer Warning Decal Crossbar Star... -
Page 24: Exploded Drawing
EXPLODED DRAWING A—Model No. PFTL54806.0 R0407A... - Page 25 EXPLODED DRAWING B—Model No. PFTL54806.0 R0407A 42 21...
- Page 26 EXPLODED DRAWING C—Model No. PFTL54806.0 43 43 R0407A...
- Page 27 EXPLODED DRAWING D—Model No. PFTL54806.0 R0407A...
-
Page 28: Ordering Replacement Parts
To order replacement parts, please see the front cover of this manual. To help us assist you, be prepared to provide the following information when calling: • the MODEL NUMBER of the product (PFTL54806.0) • the NAME of the product (PROFORM 540 treadmill) •...
