Model No. PFTL49400
Serial No.
Serial
Number
Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts, we
will guarantee complete satis-
faction through direct assistance
from our factory.
TO AVOID UNNECESSARY DE-
LAYS, PLEASE CALL DIRECT TO
OUR TOLL-FREE CUSTOMER
HOT LINE. The trained techni-
cians on our Customer Hot Line
will provide immediate assis-
tance, free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
¨
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ProForm PFTL49400
Summary of Contents for ProForm PFTL49400
- Page 1 Model No. PFTL49400 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, we will guarantee complete satis- faction through direct assistance from our factory.
-
Page 2: Table Of Contents
HOW TO FOLD AND MOVE THE TREADMILL ........ - Page 3 SAVE THESE INSTRUCTIONS The decal shown below has been placed on your treadmill. If the decal is missing, or if it is not legible, please call our Customer Service Department, toll-free, to order a free replacement decal (see ORDERING REPLACEMENT PARTS on the back cover of this manual).
-
Page 4: Before You Begin
The model number of the treadmill is PFTL49400. The serial num- ber can be found on a decal attached to the treadmill (see the front cover of this manual for the location). -
Page 5: Assembly
ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until assembly is completed. Refer to the drawings below to identify the small parts used in assembly. Assembly requires the included allen wrench... - Page 6 6. Attach the Storage Latch (12) to the left Upright (14) with two 3/4Ó Screws (13). Be careful not to overtighten the Screws. 7. Make sure that all parts are tightened before you use the treadmill. To protect the floor or carpet, place a mat under the treadmill. Bracket...
-
Page 7: Operation And Adjustment
(see drawing 1 at the right). To purchase a surge suppressor, see your local PROFORM dealer or call 1-800-999-3756 and order part number 146148. Use only a single-outlet surge suppressor that is UL 1449 listed as a transient voltage surge suppressor (TVSS). - Page 8 (see HOW TO PLUG IN THE POWER CORD on page 7). When you are ready to begin exercising, step onto the foot rails of the treadmill. Find the clip attached to the Main Heart Rate...
- Page 9 Remember to stand still while measuring your heart rate. Mode Arrows Adjust the incline of the treadmill as desired. To change the incline, press the top or bottom of the incline...
-
Page 10: How To Fold And Move The Treadmill
HOW TO USE THE UPPER BODY ARMS As you exercise on the treadmill, you can hold either the handrails or the upper body arms. The upper body arms are designed to exercise your arms, shoulders, and back for a total body workout. Hold one upper body arm with each hand, and move them forward and back as you walk on the treadmill. -
Page 11: To Move/Lower
HOW TO LOWER THE TREADMILL FOR USE 1. Refer to drawing 2 on page 10. Hold the upper end of the treadmill with your right hands shown. Using your left thumb, press the storage latch and hold it. Pivot the treadmill until the frame and foot rail are past the storage latch. - Page 12 PROBLEM: The power turns off during use SOLUTION: a. Check the circuit breaker located on the treadmill frame near the power cord (see c. above). If the circuit breaker has tripped, wait for five minutes and then press the switch back in.
- Page 13 1/4 of a turn each. Be careful not to overtighten the walking belt. Plug in the power cord, insert the key and run the treadmill for a few minutes. Repeat until the walking belt is centered. b. If the walking belt has shifted to the right, first remove the key and UNPLUG THE POWER CORD.
-
Page 14: Conditioning Guidelines
If your goal is to burn fat, adjust the speed and incline of the treadmill until your heart rate is near one of the lower two numbers in your training zone. -
Page 15: Exercise Frequency
EXERCISE FREQUENCY To maintain or improve your condition, complete three workouts each week, with at least one day of rest be- SUGGESTED STRETCHES The correct form for several basic stretches is described below. Move slowly as you stretchÑnever bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. - Page 16 PART LISTÑModel No. PFTL49400 No. Qty. Description Key/Clip Left Handrail Cage Nut Incline Control Rear Isolator Screw Console Base Speed Control Knob Speed Potentiometer Battery Cover Incline Motor Console Assembly Storage Latch 3/4Ó Screw Upright/Base Handrail Bolt Handrail Washer Motor Belt...
-
Page 18: Ordering Replacement Parts
Friday, 6 a.m. until 6 p.m. Mountain Time (excluding holidays). When ordering parts, please be prepared to give the following information: ¥ The MODEL NUMBER OF THE PRODUCT (PFTL49400) ¥ The NAME OF THE PRODUCT (PROFORM ¥ The SERIAL NUMBER OF THE PRODUCT (see the front cover of this manual) ¥...
