W130 ENHANCE
NOTEBOOK
OPERATOR' S MANUAL
Part Number: 799001148001 R00
(June. 2006)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Getac W130 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MiTAC Getac W130

Summary of Contents for MiTAC Getac W130

  • Page 1 W130 ENHANCE NOTEBOOK OPERATOR’ S MANUAL Part Number: 799001148001 R00 (June. 2006)
  • Page 2 TRADEMARKS All brand and product names are trademarks or registered trademarks of their respective companies. NOTE Information in this manual is subject to change without notice.

  • Page 3: Regulations Information

    Regulations Information Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 4 Please note: The use of a non-shielded interface cable with this equipment is prohibited. Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.

  • Page 5: Caution Texts Concerning Lithium Batteries

    About the Battery Caution Texts Concerning Lithium Batteries DANISH ADVARSEL! Lithiumbatteri – Eksplosionsfare ved fejlagtig håndtering. Udskiftning må kun ske med batteri af samme fabrikat og type. Levér det brugte batteri tilbage til leverandøren. NORWEGIAN ADVARSEL: Eksplosjonsfare ved feilaktig skifte av batteri. Benytt samme batteritype eller en tilsvarende type anbefalt av apparatfabrikanten.
  • Page 6 CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT: Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.
  • Page 7 FRENCH ATTENTION: II y a danger d’explosion s’il y a remplacement incorrect de la batterie. Remplacer uniquement avec une batterie du même type ou d’un type équivalent recommandé par le constructeur. Mettre au rebut les batteries usagées conformément aux instructions du fabricant.
  • Page 8 Caution (for USA Users) To reduce the risk of fire, use only No.26 AWG or larger telecommunication line cord. Power Supply Cord: (optional) Detachable, minimum 1.5 m long. Listed, rated minimum 125 V, 7 A, having a 2/18 AWG , type SVT flexible cord. One end terminates with a parallel blade, molded-on, attachments plug with a 7 A, 125 V (NEMA 1-15P) configuration;...
  • Page 9 Table of Contents Preface ................v Chapter 1 Getting Started..........1-1 Getting the Computer Running ..........1-2 Unpacking..............1-2 Connecting to AC Power..........1-2 Opening the Cover ............1-3 Closing the Cover ............1-4 Turning On and Off the Computer ........1-4 Taking a Look at the Computer..........1-5 Right-side Components..........1-5 Left-side Components ............1-7 Rear Components ............1-8...
  • Page 10 Rear Components ............. 1-15 Front Components ............1-16 Bottom-Side Compontents ..........1-17 Top Compontents ............. 1-18 Chapter 2 Operating Your Computer ........ 2-1 Starting and Stopping the Computer ........2-2 Starting the Computer............ 2-2 Stopping the Computer ..........2-2 Using the Keyboard............2-4 Typewriter Keys ............
  • Page 11 Using the Video Features ..........2-17 Configuring the Display Modes ........2-17 Using the Audio Features ..........2-20 Connecting Audio Devices...........2-20 Using the Communication Features ........2-21 Using the Modem ............2-21 Using the LAN ............2-21 Using the Wireless LAN ..........2-22 Configuring the WLAN ..........2-22 Using the Wireless Modem (Optional) ......2-23 Chapter 3 Managing Power ..........3-1 AC and Car Adapter............3-2...
  • Page 12 Connecting a Parallel Device (optional) ....... 4-3 Connecting a Serial Device ..........4-4 Connecting a USB Device (USB 2.0)........4-5 Using PC Cards..............4-6 ZV and CardBus Support ..........4-6 Inserting and Removing a PC Card......... 4-6 System Memory Upgrade............ 4-8 Chapter 5 SCU (Setup Configuration Utility).....
  • Page 13 Taking Care of the Computer..........7-3 Location Guidelines ............7-3 General Guidelines ............7-3 Cleaning Guidelines............7-4 Battery Pack Guidelines ..........7-4 When Traveling..............7-5 Chapter 8 Troubleshooting ..........8-1 Preliminary Checklist ............8-2 Solving Common Problems ..........8-3 Battery Problems ............8-4 CD/COMBO Drive Problems (on optional docking station)8-5 Display Problems ............8-5 Floppy Disk Drive Problems (on optional docking station)8-7 Hardware Device Problems ..........8-8...

  • Page 14: Chapter 5 Scu (Setup Configuration Utility)

    Startup Problems ............8-15 Other Problems ............8-16 Resetting the Computer............. 8-17 Appendix A Specifications ..........A-1 Preface This manual contains information that will help you operate the computer. It is divided into 8 chapters and an appendix. Chapter 1, Getting Started, takes you through the process of setting up the computer and identifying its external components.

  • Page 15: Notational Conventions

    Notational Conventions Throughout this manual, the following conventions are used to distinguish elements of text. NOTE: identifies additional information that requires special attention. CAUTION: identifies important information which, if not followed, may result in loss of data or damage to the computer. Keyboard keys are shown in a bold typeset.

  • Page 16: Chapter 1 Getting Started

    CHAPTER 1 Getting Started Congratulations on purchasing this industrial notebook computer. It’s rugged, compact, and portable design allows you to use it in the field or inside a vehicle and other demanding situations where conventional notebook computers just cannot measure up. It can also connect with a docking station to extend the capabilities of input/output devices.

  • Page 17: Getting The Computer Running

    Getting the Computer Running This section guides you through the procedures for getting the computer ready for operation. Unpacking After unpacking the shipping carton, you should find these standard items: l Notebook Computer l Accessories: − AC adapter (100~240 VAC, 50~60 Hz) −...

  • Page 18: Opening The Cover

    1. Make sure the computer is turned off. 2. Plug the DC cord of the AC adapter to the power connector on the computer. NOTE: When the computer is attached to the docking station, connect the DC cord to the power connector on the docking station instead. 3.

  • Page 19: Closing The Cover

    Closing the Cover When closing the cover, make sure that the hook is latched properly to safeguard against the following: l To prevent damage to the LCD screen during transport. l To prevent the computer from accidentally waking up from Suspend mode during transport without the user’...

  • Page 20: Taking A Look At The Computer

    Turning Off To turn off the computer power, use the “Shut Down” command of your operating system. NOTE: There are other ways you can stop the computer so that you will be back to where you left off when you next turn on the computer. (See “ Stopping the Computer” in Chapter 2 for information.) CAUTION: If you have to turn the computer on again immediately after turning it off, wait for at least five seconds.
  • Page 21 Component Description See Also Battery Charge Indicator: – glows green when the battery is fully charged. – Glows orange when the battery is being charged. – Is dark when battery has no charge left and AC adapter is connected and CMCIApowered on.

  • Page 22: Left-Side Components

    Left-Side Components Component Description See Also Œ Audio Output Connects a hi-fi set, radio set, synthesizer, Connector walkman, etc. • Microphone In Connects an external microphone. Connector Getting Started...

  • Page 23: Rear Components

    Rear Components Component Description See Also Œ USB Port Each of the two ports connects a USB device, such as a USB floppy drive, printer, digital camera, joystick, and more. • VGA Port Connects an external monitor. Ž Serial Port Connects a serial device, such as mouse.

  • Page 24: Front Components

    Front Components Component Description See Also Œ Notched Hole Allows you to hook the computer to the docking station. Serves as the antenna for the optional Wireless • Modem or wireless modem , GSM/GPRS, CDMA etc.. GSM Antenna Ž Touchscreen Provides a convenient way to use the touchscreen.
  • Page 25 Component Description See Also Œ Speaker Sends out sound and voice from the computer. • Battery Open the cover to access the battery pack. Compartment Cover Ž Battery Cover Locks the battery compartment. Latch • Docking Serves as the interface between the docking Connector station and the computer.

  • Page 26: Top-Open Components

    Top-Open Components Component Description See Also Œ LCD Screen Displays the output of the computer. • Device Indicators Shows the current status of the computer’s devices. Caps Lock Indicator – glows green when Caps Lock key is pressed and its function is activated.
  • Page 27 LAN 10/100 Indicator – glows orange when LAN speed is 10 MBPS – glows green when LAN speed is 100 MBPS Hard Disk Drive Indicator (includes Floppy Disk Drive or CD-ROM Drive In-use Indicator when computer is connected to docking station) Ž...

  • Page 28: Station

    Attaching and Detaching the Computer To/From the Docking Station WARNING: Make sure that the computer is off before connecting it to or disconnecting it from the docking station to prevent damage to either computer or docking station. Attaching the Docking Station To attach the computer to the docking station: 1.

  • Page 29: Taking A Look At The Docking Station (Option)

    Taking a Look at the Docking Station (option) This section identifies the external components of the docking station and briefly describes the function of each component. Right-Side Components Component Description See Also Œ Device Shows the current status of the docking station Indicators and computer’s devices.

  • Page 30: Left-Side Components

    Left-Side Components Component Description See Also Œ USB Ports Each of the two ports connects an USB device such as printer, digital camera, joystick and more. • Release Tab Press the Release Tab on both sides and lift up to release computer from docking station. Rear Components NOTE: The I/O ports located on the computer (except USB port) will be disabled when the docking station is installed.

  • Page 31: Front Components

    Component Description See Also Œ Serial Ports Connect serial devices such as mouse, etc. • Parallel Port Connects a parallel device such as printer. Ž VGA Port Connects an external monitor. • USB Port Connects a USB device, such as printer, digital camera, joystick and more.
  • Page 32 Bottom-Side Components Component Description See Also Œ Speaker Sends out sound and voice from the docking station. Getting Started 1-17...

  • Page 33: Top Components

    Top Components Component Description See Also Œ Hooks Secures the computer to the docking station. • Docking Serves as the interface between the docking Connector station and the computer. 1-18 Getting Started...

  • Page 34: Where To Go From Here

    Where to Go from Here As your computer is ready for operation, you ma y want to do any of the following now: For this purpose… Do this… To know more about the computer… Go on to the next chapter. To install the operating system if your See the operating system manual.
  • Page 35 1-20 Getting Started...

  • Page 36: Chapter 2 Operating Your Computer

    CHAPTER 2 Operating Your Computer This chapter provides information about the use of the computer. If you are new to computers, reading this chapter will help you learn the operating basics. If you are already a computer user but are new to notebook computers, you may choose to read only the parts containing information unique to your computer.

  • Page 37: Starting And Stopping The Computer

    Starting and Stopping the Computer There are a number of ways to start and stop the computer. Starting the Computer You always start the computer using the power button. A computer starts up with an operating system (OS) existing on the storage device such as the hard disk;...
  • Page 38 To stop in Do this… To start up or this mode… resume again Depending on your settings in Windows, Hibernation Press the power you can place the computer in button. Hibernation mode by l pressing the power button l by closing the display cover. If you choose to stop in Standby or Hibernation mode, you can return to where you left off the next time you start up the computer.

  • Page 39: Using The Keyboard

    Using the Keyboard Your keyboard has all the standard functions of a full-sized computer keyboard plus a key added for specific functions. The standard functions of the keyboard can be further divided into four major categories: Typewriter keys Cursor-control keys Numeric keys Function keys Typewriter Keys...

  • Page 40: Numeric Keypad

    Numeric Keypad A 15-key numeric keypad is embedded in the typewriter keys as shown next: Numeric keys facilitate entering of numbers and calculations. Num Lk When is on, the numeric keys are activated; meaning you can use these keys to enter numerals with “Fn” key. NOTE: Some software may not be able to use the numeric keypad on the computer.

  • Page 41: Function Keys

    Function Keys On the top row of the keys are the function keys: . Function keys are multi-purpose keys that perform functions defined by individual programs. F1, F3 Hot key functions are assigned to , and by your computer. (See “Hot Keys” section in this chapter for information.) Fn.
  • Page 42 Description Fn+F9 Switches the display output to one of the following three when an external CRT monitor is connected through the docking station. CRT monitor Display on both NOTE: If the display mode is set to 256 colors or lower, or in DOS mode, there will be only two modes for selecting: CRT only and Display on both.

  • Page 43: Using The Touchpad

    Using the Touchpad CAUTION: Do not use a sharp object such as a pen on the touchpad. Doing so may damage the touchpad surface. NOTE: For optimal performance of the touchpad, keep your fingers and the pads clean and dry. When tapping on the pad, tap lightly. Do not use excessive force. The touchpad is a pointing device that allows you to communicate with the computer by controlling the location of the pointer on the screen and making selection with the buttons.

  • Page 44: Configuring The Touchpad

    Term Action Drag and Press and hold the left button, then move your fingers drop until you reach your destination (drag). Finally, release the button (drop) when you finish dragging your selection to the destination. The object will drop into the new location.

  • Page 45: Using The Touchscreen (Optional)

    Using the Touchscreen (Optional) CAUTION: Do not use a sharp object such as a ballpoint pen or pencil on the touchscreen. Doing so may damage the touchscreen surface. Use the included touchscreen pen instead, which can be stretched for better grip and handling. The touchscreen is a touch-sensitive device that allows you to communicate with the computer by controlling the location of the pointer on the screen and making selection with the buttons.

  • Page 46: Configuring The Touchscreen

    Term Action Scroll To scroll is to move up and down or left and right in the working area on the screen. To move vertically, place your finger or pen on the right edge of the touchscreen and slide your finger or pen up and down along the edge.

  • Page 47: Using The Floppy Disk Drive (Optional)

    Using the Floppy Disk Drive (optional) Your computer may come with the optional floppy disk drive as drive A through the optional docking station. A floppy disk drive allows you to install new programs into your computer, or to store information on a removable floppy disk so you can transfer information from one computer to another.

  • Page 48: Inserting And Ejecting Floppy Disks

    Inserting and Ejecting Floppy Disks To insert a floppy disk, hold it with the arrow facing up and towards the drive. Slide the disk into the drive until it clicks into place. To eject a floppy disk, first ensure that the floppy disk drive in-use indicator is off, and then press the eject button on the drive.

  • Page 49: Using The Hard Disk Drive

    Using the Hard Disk Drive Your computer comes with a hard disk drive as drive C. A hard disk drive is a storage device with non-removable, rotating, magnetic storage platters inside it. It is where your operating system and application software programs are stored. Your hard disk drive is a 2.5-inch IDE (Integrated Drive Electronics) hard disk drive.

  • Page 50: Using The Cd/Combo Drive (Optional)

    Using the CD/COMBO Drive (optional) Your computer may come with an optional CD-ROM drive, COMBO drives, or through the optional docking station. This drive is usually configured as drive D. The drive uses removable 5.25-inch silver CD-ROM discs, which look like standard music CDs.

  • Page 51: Inserting And Removing A Cd

    Inserting and removing a CD Follow this procedure to insert or remove a CD. 1. Turn on the computer. 2. Press the eject button and the CD tray will slide out partially. Gently pull it until fully extended. 3. To insert a CD, put down the CD in the tray with its label facing up. Slightly press the center of the CD until it clicks into place.

  • Page 52: Using The Video Features

    Using the Video Features The video subsystem of your computer features: l 12.1-inch TFT (Thin-Film Transistor) color LCD display with 1024x768 XGA (Extended Video Graphics Array) resolution. l Sunlight Readable Panel , Hi-Contrast solution (Optional). l Simultaneous display on LCD and external monitor (connect through the docking station), which is useful when you have a presentation as you can control the screen from your computer and face the audience at the same time.
  • Page 53 Simultaneous Display Mode LCD Only CRT Only Display Resolution Colors √ √ √ 640x480 8-bit √ √ √ 16-bit √ √ √ 24-bit √ √ √ 32-bit √ √ √ 720x480 8-bit √ √ √ 16-bit √ √ √ 24-bit √...
  • Page 54 Simultaneous Display Mode Display LCD Only CRT Only √ √ √ 1024x768 8-bit √ √ √ 16-bit √ √ √ 24-bit √ √ √ 32-bit √ 1152x864 8-bit √ 16-bit √ 24-bit √ 32-bit √ 1280x1024 8-bit √ 16-bit √ 24-bit √...

  • Page 55: Using The Audio Features

    Using the Audio Features NOTE: To take advantage of the enhanced audio capabilities, the audio driver supplied with your computer must be installed. If you experience interference while recording, try lowering the microphone recording volume. The audio subsystem of your computer features: l Digital audio and analog mixing functions required for recording and playing sound on your computer l SoundBlaster Pro, Adlib, and Microsoft Windows Sound System...

  • Page 56: Using The Communication Features

    Using the Communication Features Using the Modem NOTE: To take advantage of the modem feature, the modem driver supplied with your computer must be installed. The internal 56 K fax/data modem allows you to use the telephone line to communicate with others by fax, email, or connect to an online service or bulletin board.

  • Page 57: Using The Wireless Lan

    Using the Wireless LAN Depending on your model, an internal Mini PCI wireless LAN (WLAN) card may have been pre-installed by your computer manufacturer at the factory. This card allows you to access corporate networks or the Internet in a wireless environment. The WLAN features include: IEEE 802.11b standard compliance 2.4 GHz DSSS (Direct Sequence Spread Spectrum) technology...

  • Page 58: Using The Wireless Modem (Optional)

    Using the Wireless Modem (Optional) Introduction This chapter describes how to open and close 1xEV-DO data connections. Connections over a 1xEV-DO network provide asymmetric data rates. Maximum throughput for the uplink direction is 153.6 kbps, while maximum throughput for the downlink is 2.4 Mbps. Only packet-switched data calls are supported by 1xEV-DO systems.

  • Page 59: Chapter 3 Managing Power

    CHAPTER 3 Managing Power Your computer operates either on external AC power, car adapter, or internal battery power. This chapter tells you how you can effectively manage power. To maintain optimal battery performance, it is important that you use the battery in the proper way.

  • Page 60: Ac And Car Adapter

    AC and Car Adapter CAUTION: The AC and car adapter is designed for use with your computer only. Connecting the AC adapter to another device can damage the adapter. The AC power cord supplied with your computer is for use in the country where you purchased your computer.

  • Page 61: Battery Pack

    Battery Pack The battery pack is the internal power source for the computer. It is rechargeable using the AC or car adapter. The operating time of a fully charged battery pack depends on how you are using the computer. When your applications often access peripherals, you will experience a shorter operating time.
  • Page 62 NOTE: Charging will not start if the battery’ s temperature is below 0°C (32°F) or above 40°C (104°F). The charging process will stop when the battery’ s temperature gets above 60°C (140°F). If this happens, the battery pack may be damaged, please contact your dealer.

  • Page 63: Initializing The Battery Pack

    Initializing the Battery Pack The battery pack is not charged when the computer is first bought. Make sure to charge it at least 8 hours before use it for the first time. Charging automatically starts when the AC adapter is plugged in to the computer.

  • Page 64: Replacing The Battery Pack

    Replacing the Battery Pack CAUTION: There is danger of explosion if the battery is incorrectly replaced. Replace the battery only with the computer manufacturer’ s optional battery packs. Discard used batteries according to the dealer’ s instructions. Do not attempt to disassemble the battery pack. If battery leaks and the fluid get into eyes, do not rub eyes and immediately flush eyes with clear water and see a doctor as soon as possible.
  • Page 65 Pull the battery block. Battery Block 5. Pull on the protruding strip to slide the battery pack to the left and lift the battery pack out of its compartment. Pull Battery 6. Insert the new battery pack into the compartment and slide the battery pack to the right to allow the proper connection of connectors.

  • Page 66: Battery Low Signals And Actions

    Battery Low Signals and Actions Battery Low occurs when the battery has approximately 10% of its charge remaining. The computer in the Battery State Indicator LED blink to alert you to take actions. NOTE: You can set up your threshold and signals of Battery Low under Windows. Immediately save your data upon Battery Low.

  • Page 67: Power Management

    Power Management Your computer supports APM (Advanced Power Management) and ACPI (Advanced Configuration and Power Interface) for power management. The power management feature allows you to reduce the power consumption for energy saving. With an ACPI-compliant operating system such as Windows 98 and Windows 2000, power supply to different computer components is controlled on an as-needed basis.

  • Page 68: Manual Power Management

    Manual Power Management You can manually initiate Suspend-to-disk mode at any time in one of two ways: l Use the O/S that supports the Suspend function. l Press down the power button and release it in less than 4 seconds with the system on.

  • Page 69: Power-Saving Tips

    Power-Saving Tips In addition to your computer’s automatic power management, you can do your part to maximize the battery’s operating time by following these suggestions. l Do not disable Power Management. l Decrease the LCD brightness to the lowest comfortable level. l Disable the parallel and serial ports if no devices are connected to these ports.

  • Page 70: Chapter 4 Expanding Your Computer

    CHAPTER 4 Expanding Your Computer You can expand the capabilities of your computer by connecting other peripheral devices. When using a device, be sure to read the instructions accompanying the device together with the relevant section in this chapter. This chapter gives guidelines on installing and using these devices: External monitor Parallel device (through the optional docking station) Serial device...

  • Page 71: Connecting An External Monitor

    Connecting an External Monitor If you want the benefits of a larger display screen with higher resolution, you can connect an external CRT monitor to your computer through the optional docking station. Follow this procedure to connect an external monitor: 1.

  • Page 72: Connecting A Parallel Device (Optional)

    Connecting a Parallel Device (optional) The optional docking station has a p arallel port for connecting a parallel device such as printer. The port supports ECP (Extended Capabilities Port) and EPP (Enhanced Parallel Port) modes that turn the standard parallel port into a high-speed bi-directional peripheral port.

  • Page 73: Connecting A Serial Device

    Connecting a Serial Device Your computer has a serial port for connecting a serial device such as a serial mouse or modem. Follow this procedure to connect a serial device: 1. Make sure the “COM1 Port” item is set properly in the SCU program. (See “Advanced Menu”...

  • Page 74: Connecting A Usb Device (Usb 2.0)

    Connecting a USB Device (USB 2.0) Your computer has one USB port on the right side for connecting USB 2.0 devices such as digital camera, scanner, printer, modem, or mouse and two USB ports on the left side of the optional docking station.

  • Page 75: Using Pc Cards

    Using PC Cards Your computer has one PC Card slot to accommodate one type II card. ZV Port and CardBus Support Your computer’s PC Card slot supports CardBus and ZV (Zoomed-Video) Port specifications. CardBus is the 32-bit version of PC Card technology. It allows speeds of up to 133 Mbps at 33 MHz.
  • Page 76 To remove a PC Card: 1. Your operating system may require you to stop the PC Card before you actually remove it. (In Windows, double-click the PC Card icon in Control Panel to stop the card.) 2. Push the eject button and the card will slide out slightly. 3.

  • Page 77: System Memory Upgrade

    System Memory Upgrade You can upgrade your computer by changing system memory to a maximum of 1GB on the DDR SDRAM slot. However, to avoid damage during the installation procedure, please ask your dealer for help. Expanding Your Computer...
  • Page 78 CHAPTER 5 Setup Configuration Utility (SCU) SCU is a program for configuring the BIOS (Basic input/output System) settings of the computer. BIOS are a layer of software, called firmware that translates instructions from other layers of software into instructions that the computer hardware can understand.

  • Page 79: When And How To Use The Scu Program

    When and How to Use the SCU Program When to Use You need to run the SCU program when: l You see an error message on the screen requesting you to run Setup. l You want to restore the factory default settings. l You want to modify some specific settings according to the hardware.
  • Page 80 The menu can be divided into four areas: l On the top line is the menu bar containing the titles of the available menus. Each menu tit le brings a specific menu. l The center left column of the menu contains items that you can set for the selected menu title.

  • Page 81: Moving Around And Making Selections

    Moving Around and Making Selections A brief description of keyboard usage is listed next: Function ←, → Selects a menu title. ↑, ↓ Selects an item or option. Enter Opens or closes the options window when an item is selected. Space bar, Cycles through the pre-defined value for the selected item.

  • Page 82: Main Menu

    Main Menu The Main menu contains the basic configuration settings of the system. Date and Time Sets the system date and time. Setup Configuration Utility...
  • Page 83 Internal and Numlock sets if you can enter a number when Num Lock is turn off. When this item is enabled, you can press and hold FN, and then press a letter key to enter a number even if Num Lock is turned off. When this is disabled, you cannot enter a number with the above method.

  • Page 84: Advanced Menu

    USB Emulation enables or disables the system’s support for the USB port in DOS mode. Advanced Menu The Advanced menu contains the input/output configuration settings of the system. Setup Configuration Utility...

  • Page 85: Geyserville Support

    Geyserville Support Enables or disables the Geyserville feature of the CPU. The Geyserville feature helps conserve battery life by decreasing the CPU’s running speed under certain conditions while still maintaining a high performance. If this item is enabled, the CPU will automatically change its speed whenever necessary based on the “Power Scheme”...
  • Page 86 Com Ports HDD Heater A new feature creates safe and reliable operating conditions for the Hard Disk Drive (HDD) in excessive cold temperature conditions (-20°). The feature will allow flexible configurable settings to customize the operational parameters of the HDD heater. Setup Configuration Utility...

  • Page 87: Security Menu

    Security Menu The Security menu contains the security setting that safeguards your system against unauthorized use. 5-10 Setup Configuration Utility...
  • Page 88 Power-on Password Set Password allows you to set the password for your system. When typing password, first ma ke sure that Num Lock is off, then type your password in the entry fields and press Enter. Confirm your password by typing it again and pressing Enter.
  • Page 89 SCU Password Set Password allows you to set the password for your system. When typing password, first make sure that Num Lock is off, then type your password in the entry fields and press Enter. Confirm your password by typing it again and pressing Enter. If the Enable Password to SCU sub-item is enabled, the set password is always required to enter SCU.

  • Page 90: Boot Menu

    Boot Menu The Boot men sets the sequence of the devices to be searched for the operating system. Boot Sequence sets the first, second, third, and fourth booting devices. The system will try to boot from the first device but if it is not available, will try the next boot device.

  • Page 91: Exit Menu

    Exit Menu The Exit menu displays ways of exiting SCU. After finished with your setting, you must save and exit so that the new setting can take effect. Save Change and Exit saves the changes you have made and exits SCU.
  • Page 92 Setup Configuration Utility 5-15...

  • Page 93: Chapter 6 Installing Software Drivers

    CHAPTER 6 Installing Software Drivers To take full advantage of the unique features of your computer, some operating systems require custom software, known as drivers, to be installed. If you purchased the computer with Windows pre-installed; your dealer may have already installed the drivers. If not, you need to install the drivers using the CD supplied with your computer.
  • Page 94 How to Use the CD NOTES: • The drivers may have been updated after this manual was published. For driver’ s upgrade, please contact your dealer. • You can always find README or document files on the CD. These files contain the latest information from the software supplier.
  • Page 95 Install Device Driver for Windows 2000/Windows XP To install the necessary driver, just click on the particular option and follow the onscreen instructions to continue and complete installation. Device Driver Press the “Device driver” button, the system will auto install include VGA, Audio, Modem, LAN , Wireless LAN, USB 2.0, DirectX 8.1, Chipset driver.
  • Page 96 VGA Allows you to select high-resolution displays with richer colors. It can drive CD displays as well as CRT displays. Audio Allows you to take full advantage of the audio subsystem. Modem The modem driver allows you to transmit information over a standard telephone line through RJ-11 port.
  • Page 97 Vehicle Dock Click on the Vehicle Dock button to install docking driver, the system will auto install USB TO COM Port and Video Capture drivers. NOTE: Proceed immediately to the section “ . Wireless LAN Utility Installation” for more details. BROWSE CD Browses the contents of the CD.
  • Page 98 STEP 3 2. Cursor not steady Note: The transient abnormal cursor movement might occur before driver installation. Please wait for seconds until recovery 3. Touch Pad Driver only for Windows XP installation. Installing Software Drivers...

  • Page 99: Chapter 7 Caring For The Computer

    CHAPTER 7 Caring for the Computer Taking good care of your computer will ensure a trouble-free operation and reduce the risk of damage to your computer. This chapter gives you guidelines covering these areas of maintenance: l How to protect the computer l What to note when using and storing the computer l How to clean the computer l What to note when using the battery pack...

  • Page 100: Protecting The Computer

    Protecting the Computer To safeguard the integrity of your computer data as well as the computer itself, you can protect the computer in several ways as described in this section. Using the Password The power-on password protects your computer against unauthorized use.

  • Page 101: Taking Care Of The Computer

    Taking Care of the Computer Location Guidelines l Use the computer where the temperature is between 0 °C to 55 °C . l Avoid placing the computer in a location subject to high humidity, extreme temperatures, mechanical vibration, direct sunlight, or heavy dust. l Do not cover or block any ventilation openings on the computer.

  • Page 102: Cleaning Guidelines

    Cleaning Guidelines l Never clean the computer with its power on. l Use a soft cloth moistened with water or a non-alkaline detergent to wipe the exterior of the computer. l Gently wipe the display with a soft, lint-free cloth. Do not use alcohol or detergent on the display.

  • Page 103: When Traveling

    l If you remove the battery pack, make sure the battery terminals do not contact any conductors such as metal objects or water. Otherwise, the battery may become unusable as a result of a short circuit. l Do not leave the battery pack in storage for more than 3 months without recharging it.
  • Page 104 l If you need to leave the computer in the car, put it in the trunk of the car to avoid exposing the computer to excessive heat. l Allow extra time for airport security. Many airports inspect electronic devices carefully. l When going through airport security, it is recommended that you send the computer and floppy disks through the X-ray machine (the device you set your bags on).

  • Page 105: Chapter 8 Troubleshooting

    CHAPTER 8 Troubleshooting Hardware, software, or a combination of both can cause computer problems. When you encounter any problem, it might be a typical problem that can easily be solved. This chapter tells you what actions to take when solving common computer problems.

  • Page 106: Preliminary Checklist

    Preliminary Checklist Here are helpful hints to follow before you take further actions when you encounter any problem: l Try to isolate which part of the computer is causing the problem. l Make sure that you turn on all peripheral devices before turning on the computer.

  • Page 107: Solving Common Problems

    Solving Common Problems For easy reference, the problems are divided into these categories. Problem Type Go to Battery problems P. 8-4 CD/COMBO drive problems (on optional docking P. 8-5 station) Display problems P. 8-5 Floppy disk drive problems (on optional docking station) P.

  • Page 108: Battery Problems

    Battery Problems The battery does not charge (Battery Charge LED indicator does not light orange). l Make sure that the AC adapter is properly connected. l Make sure that the battery is not too hot – gets above 55 or too cold – below 0 C.

  • Page 109: Display Problems

    CD/COMBO Drive Problems (on optional docking station) The CD/COMBO drive cannot read a CD. l Make sure that the CD is correctly seated in the tray, with the label facing up. l Make sure that the CD is not dirty. Clean the CD with a CD cleaning kit, available in most computer stores.
  • Page 110 l The brightness level might be too low. Increase brightness by pressing l The display output might be set to an external monitor. To switch the display back to the LCD, press l Reset the computer by pressing the Ctrl keys if you are using an external keyboard.
  • Page 111 The external monitor displays nothing. l Make sure that the monitor is turned on. l Make sure that the monitor’s signal cable is properly connected. l Check if the Setup item Display Mode on the Main menu of the SCU program is configured correctly.

  • Page 112: Hardware Device Problems

    The disk drive cannot read a floppy disk. l Make sure that the floppy disk is formatted. l Make sure that you are reading the correct drive. Hardware Device Problems The computer does not recognize a newly installed device. l The device may not be correctly configured in the SCU program. Run the SCU program to identify the new type.

  • Page 113: Keyboard, Mouse, And Touchpad Problems

    The hard disk drive in-use indicator glows without blinking. l The data files stored on the hard disk drive may be fragmented. Use a tool such as Window’s Disk Defragmenter to defragment the files. Keyboard, Mouse and Touchpad Problems The keyboard does not respond. l Try connecting an external keyboard.

  • Page 114: Lan Problems

    LAN Problems I cannot access the network. l Make sure that the LAN/Wireless LAN driver is correctly installed. l Make sure that the LAN /Wireless LAN cable is properly connected to the RJ-45 connector and the network hub. l Make sure that the network configuration is appropriate. l Make sure that the user name or password is correct.
  • Page 115 I cannot to another WLAN device. l Make sure that the WLAN feature is turned on. l Make sure that the SSID setting is the same for every WLAN device in the network. l Your computer is not recognizing changes. Restart the computer. l Make sure that the IP address or subnet mask setting is correct.

  • Page 116: Modem Problems

    Modem Problems The modem does not work. l Make sure that the modem driver is correctly installed. l Make sure that the telephone line is properly connected. l Make sure that the COM port in the communication software is correctly set.

  • Page 117: Power Management Problems (For Windows)

    COM3 (reserved for IRQ3 touchscreen only) The PC Card stops communicating properly. l The application may have been reset when the computer is turned off or in Standby mode. Exit and restart the application. Power Management Problems (for Windows) The computer does not enter Standby or Suspend mode automatically.

  • Page 118: Software Problems

    Printer Problems (connected through optional docking station) The printer does not work. l Make sure that the printer is turned on (if with independent power source) and is online (ready to use). l Make sure that the printer’s signal cable is properly connected. l Make sure that the printer driver is correctly installed.

  • Page 119: Startup Problems

    l Make sure that the computer is not in Standby mode. l If using an external speaker, make sure that the speaker is properly connected. Distorted sound is produced. l Make sure that the volume control is not set too high or too low. In most cases, a high setting can cause the audio electronics to distort the sound.

  • Page 120: Other Problems

    The message “Operating system not found” appears on the screen after you turn on the computer. l Make sure that there is no floppy disk in the floppy disk drive (when connected to the docking station). If there is, remove it and restart the system.

  • Page 121: Resetting The Computer

    Resetting the Computer You may have to reset (reboot) your computer on some occasions when an error occurs and the program you are using hangs up. If the system operation seems to hang up, first wait. It is possible that the system is processing data.
  • Page 122 8-18 Troubleshooting...
  • Page 123 Troubleshooting 8-19...
  • Page 125 Troubleshooting 8-16...

  • Page 126: Specifications

    APPENDIX Specifications NOTE: Specifications are subject to change without any prior notices. • Intel Dothan LV 1.4 GHZ in µ-FCBGA package, 400MHz FSB • Optional Intel Celeron M Processor 900 MGHz in µ-FCBGA package, 400MHz FS Intel 855GME chipset + ICH4-M (with Dothan and Celeron CPU) Core logic System BIOS 512KB Flash EEPROM...

  • Page 127: Docking Station

    Type II x 1 - Card Bus support PCMCIA • 10/100 Base-T LAN Communication • 56K, V90. Modem • 802.11b or b/g Wireless LAN (Intel PRO/Wireless 2200BG LAN mini-PCI type 3B adapter) • Wireless Modem (GPRS/GSM or CDMA ) optional •...

  • Page 128: Regulatory Information

    APPENDIX Regulatory Information This appendix provides regulatory statements and safety notices on your computer. NOTE: Marking labels located on the exterior of your computer indicate the regulations that your model complies with. Please check the marking labels and refer to the corresponding statements in this appendix.

  • Page 129: On The Use Of The System

    On the Use of the System Class B Regulations Federal Communications Commission Radio Frequency Interference Statement NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 130: Safety Notices

    Canada Canadian Department of Communications Radio Interference Regulations Class B Compliance Notice This Class B digital apparatus meets all requirements of the Canada Interference-Causing equipment regulations. Cet appareil numérique de Classe B respecte toutes les exigences du Règlement Canadien sur le matériel brouileur. This digital apparatus does not exceed the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference Regulations of the Canadian Department of Communications.
  • Page 131 ENGLISH CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the equipment manufacturer. Discard used batteries according to manufacturer's instructions. DEUTSCH VORSICHT : Explosionsgefahr bei unsachgemäßem Austausch der Batterie. Ersatz nur durch denselben oder einen vom Hersteller empfohlenen gleich-wertigen Typ.
  • Page 132 About the Modem Caution Never install telephone wiring during a lightning storm. Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations. Never touch non-insulated telephone wires or terminals unless the telephone line has been disconnected at the network interface. Use caution when installing or modifying telephone lines.

  • Page 133: Usa And Canada Safety Requirements And Notices

    On the Use of RF Device NOTE: The information in this section applies to models with the wireless LAN module. USA and Canada Safety Requirements and Notices IMPORTANT NOTE: To comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operating in conjunction with any other antenna or transmitter.
  • Page 134 Antenna use: To comply with FCC RF exposure compliance requirements, the antenna must not be co-located or operating in conjunction with any other antenna or transmitter. Explosive Device Proximity Warning WARNING: Do not operate a portable transmitter (such as a wireless network device) near unshielded blasting caps or in an explosive environment unless the device has been modified to be qualified for such use.
  • Page 135 EMC Requirements This device uses, generates and radiates radio frequency energy. The radio frequency energy produced by this device is well below the maximum exposure allowed by the Federal Communications Commission (FCC). This device complies with the limits for a Class B digital device pursuant to Part 15 subpart C of the FCC Rules and Regulations.
  • Page 136 Information to User: To assure continued compliance, any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. IMPORTANT NOTE: This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.

  • Page 137: European Union Ce Marking And Compliance Notices

    Canada Radio Frequency Interference Requirements To prevent radio interference to the licensed service, this device is intended to be operated indoors and away from windows to provide maximum shielding. Equipment (or its transmit antenna) that is installed outdoors is subject to licensing. Pour empêcher que cet appareil cause du brouillage au service faisant l'objet d'une licence, il doit être utilisé...
  • Page 138 Greek To p????? a?t? p????? t?? p??ß???e?? t?? ????pa???? ? d???a? 1999/5/EC. Icelandic Þessi vara stenst reglugerð Evrópska Efnahags Bandalagsins númer 1999/5/EC. Italian Questo prodotto è conforme alla Direttiva Europea 1999/5/EC. Norwegian Dette produktet er i henhold til bestemmelsene i det europeiske direktivet 1999/5/EC.
  • Page 139 General European standards dictate maximum radiated transmit power of 100 mW Effective Isotropic Radiated Power (EIRP) and the frequency range 2400 – 2483.5 MHz. Belgium and the Netherlands In Belgium and the Netherlands, the product may not be used outdoors. See the instructions next under the heading “How to Turn Off the Wireless LAN.”...
  • Page 140 Departments in Which the Wireless LAN Module’s Maximum EIRP Not Shown in the Previous Table Frequency Ranges (MHz) Indoors Outdoors 2400 – 2446.5 10 mW Not permitted 2446.5 – 2483.5 100 mW 100 mW on private property with Ministry of Defense approval Turning Off the Wireless LAN Radio NOTE: Turning the wireless LAN radio off is not the same as disabling the wireless LAN card.

Table of Contents
