The Rs-232 Connector - Metro DataVac DPC 20 User Manual

is true independently of the measurement mode chosen for the SPC400 Aerosol (i. e.
measurements part by part or characteristic by characteristic ).
Important : Once all pressure measurements have been downloaded to the SPC400
Aerosol, leave the manometer connected until the message « end of sample »
appears on the screen. This is to allow memory reset of the DPC 20.
5. HOW TO USE THE SERIAL LINK (RS-232)
This interface enables release and transfer of measurements to a PC or an SPC400
Aerosol as well as loading of configuration parameters from a PC.
The protocol of communication of the manometer is as follows:
-1200 baud, 8 bits, no parity, 1 stop, no hand shake

5.1 The RS-232 connector

The connector is equipped with a Sub D 9 pin-plug.
Description of signals and assignment of pins.
Pin Signal
1
2 RX
3 TX
4 9V
5 Gnd
6 to 9
5.2 Commands
NOTE: In the following examples, '_' indicates a space character (ASCII code 32),
CrLf indicates the codes Cr (code 13) and Lf (code 10). Messages containing
« ****** » are error messages.
You will find below a presentation of each of the commands the manometer is able to
receive.
5.2.1 Transfer of the measurement made on part number n
Command: nCrLf
When receiving this command, the manometer will transfer the value of
measurement number n. n can assume any value between 0 and 20 expressed in
ASCII code on one or two bytes:
If n = 0, the transferred value is always the one displayed !
If sample size = 0, whichever measurement number is requested, the manometer will
always transfer the current measurement.
Page 12
Direction Description
Reserved (do not connect)
Input Reception of data
Output Transfer of data
Input Battery power supply
- Ground
Reserved (do not connect)
MANOMETER DPC 20
HOW TO USE THE SERIAL LINK
