SPECIFICATIONS （総合仕様）
GENERAL
Type
Overall Frequency Response
Maximum Output Level
Demensions (W x H x D)
Weight
Magnetic Shielding
SPEAKER SECTION
Components
Enclosure
AMPLIFIER SECTION
Output Power *
S/N, IHF-A filter
Input Sensitivity
Input Connectors, Impedance
Output Connectors
Controls
Indicators
Power Consumption
AC CORD
Length
* This specification apply to rated power supplies of 100, 120, 230 and 240 V.
Powered subwoofer
25 Hz - 150 Hz (-10 dB)
111 dB, 1 m on Axis
328 x 459 x 476 mm
26.5 kg
Yes (None coverd type)
LF
10" cone
HF
Type Bass-Reflex
Material MDF
180W
f = 100 Hz, THD = 1 %, RL = 8 Ω
≧ 100 dB, LEVEL = Max
+4 dBu, LEVEL = Center
XLR-3-31
–6 dBu, LEVEL = Max
XLR-3-31 x 3 (balanced), 10 kΩ
XLR-3-32 x 3 (balanced),
Parallel connection with Input
LEVEL control
Center Click VR
(Min = – ∞ Attenuation)
LOW CUT switch
POWER switch on/off
PHASE switch Normal/Reverse
LPF control 40-120 Hz, 80 Hz at Center Click
Green: Power On
LED
Red: Clipping
160 W
2.5 m
SW10 STUDIO
