Model No. PFSG51030
Serial No.
The serial number is on a sign
behind the access panel. Write the
serial number in the space above.
Access
Panel
QUESTIONS?
If you have questions, or if there
are missing parts, we will guar-
antee complete satisfaction
through direct assistance from
our factory.
TO AVOID DELAYS, PLEASE
CALL DIRECT TO OUR TOLL-
FREE CUSTOMER HOT LINE.
The technicians on our cus-
tomer hot line will provide imme-
diate assistance, free of charge.
CUSTOMER HOT LINE:
1-877-897-7493
Mon.–Fri., 8 a.m.–5 p.m. CST
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
new products, prizes,
fitness tips, and much more!
Advertisement
Table of Contents
Related Manuals for ProForm PFSG51030
Summary of Contents for ProForm PFSG51030
- Page 1 Model No. PFSG51030 Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar-...
-
Page 2: Table Of Contents
Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a replacement sign. Post the sign as described above. PROFORM is a registered trademark of ICON Health & Fitness, Inc. -
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions. - Page 4 The effects of hyperthermia include failure to per- ceive heat; failure to recognize the need to exit the spa or hot tub; unawareness of impending hazard; fetal damage in pregnant women; physical inability to exit the spa or hot tub and unconsciousness resulting in danger of drowning.
-
Page 5: Save These Instructions
35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it. -
Page 6: Before You Begin
The model number is PFSG51030. The serial number can be found on a decal on the access panel inside the spa (see the front cover of this manual). -
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa. -
Page 8: Assembly
Assembly Before beginning assembly, carefully read the following information and instructions: • Place all parts in a cleared area and remove the packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is completed and the spa is operating. •... - Page 9 3. Wipe out the spa shell using a damp cloth. Remove the two warning decals (not shown) from the spa shell. Before you fill the spa, make sure that it is in the position you want and that it can be easily serviced if needed.
-
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat two adults. The spa holds approximately 200 gallons of water and offers a heating system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. Follow the guidelines below to use and maintain the spa for your long-term enjoyment. -
Page 11: Spa Shell Diagram
Spa Shell Diagram SPA OPERATION Refer to the diagram above. The function of each component is explained below: The seven uni-directional jets (A) are located on both sides of the spa. Three jets focus a water mas- sage on your upper back, and the remaining jets pro- vide a foot massage. -
Page 12: Using The Controls
Using the Controls Display Pump Button Refer to the diagram above. The function of each control is explained below: Pump Button: Turns the spa jets on and off. If the button is pressed once, the spa jets will run at low speed, providing gentle hydrotherapy. -
Page 13: Maintenance
Maintenance The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. MAINTENANCE SCHEDULE Daily • Check the water level and refill the spa to the level shown in step 3 on page 9. •... - Page 14 Severe problems can occur when the pH balance is not maintained within this range. If the pH level exceeds 7.8, dissolved minerals can build up and clog the plumbing in the spa jet unit. If the pH level falls below 7.2, the acid level in the water will begin to cor- rode the metal parts in the spa jet unit.
- Page 15 To drain the hydrotherapy spa, follow the steps below: 1. Using the console, adjust the temperature to the lowest setting. 2. Shut off the power to the spa, at the circuit breaker or GFCI. 3. Remove the access panel from the spa (see ATTACHING AND REMOVING THE ACCESS PANEL on page 14).
-
Page 16: Troubleshooting
CLEANING THE FILTER The filter should be checked periodically for build-up of dirt and oil. To check or clean the filter, follow the steps below. Cleaning the Basket: 1. Turn off the power. 2. Pull the Filter Door (24) towards you until it is fully open. - Page 17 3. SYMPTOM: THE PUMP HUMS a. The filter may be dirty or damaged. Remove the filter from the filter housing and clean or replace the filter (see page 16). b. The pump may have a foreign object stuck in the impeller. Contact our customer service department.
-
Page 18: Part List
Part List—Model No. PFSG51030 Key No. Qty. Description Buckle Screw Buckle Corner Panel 1/4” Washer Rubber Insulator Blue Lens Waterfall Knob 2” O-ring Removable Collar Filter Cartridge Hinge Pin *10 x 1” Screw Pump Motor* Control Unit* Long Panel Heater Gasket... -
Page 19: Exploded Drawing
Exploded Drawing—Model No. PFSG51030 R0203A... -
Page 20: Ordering Replacement Parts
• The MODEL NUMBER of the product (PFSG51030) • The NAME of the product (PROFORM ORBIT hydrotherapy spa) • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the desired part(s) (see the PART LIST and EXPLODED DRAWING...
