Model No. PFSB62830

Serial No.

The serial number is on a sign

behind the access panel. Write the

serial number in the space above.

Access

Panel

QUESTIONS?

If you have questions, or if there

are missing parts, we will guar-

antee complete satisfaction

through direct assistance from

our factory.

TO AVOID DELAYS, PLEASE

CALL DIRECT TO OUR TOLL-

FREE CUSTOMER HOT LINE.

The technicians on our customer

hot line will provide immediate

assistance, free of charge.

CUSTOMER HOT LINE:

1 - 877 - 897 - 7493

Mon.–Fri., 8 a.m.–5 p.m. CST

CAUTION

Read all precautions and instruc-

tions in this manual before using

this equipment. Save this manual

for future reference.

USER'S MANUAL

Visit our website at

www.proform.com

new products, prizes,

fitness tips, and much more!

Table of Contents

Need help?

Do you have a question about the PFSB62830 and is the answer not in the manual?

Questions and answers

Summary of Contents for ProForm PFSB62830

Page 1 Model No. PFSB62830 Serial No. The serial number is on a sign behind the access panel. Write the serial number in the space above. Access Panel QUESTIONS? If you have questions, or if there are missing parts, we will guar-...
Page 2: Table Of Contents
Whenever the spa is moved, the sign must also be moved and reposted near the spa. If the sign becomes lost or illegible, call our toll-free Customer Hot Line at 1-877-897-7493 to obtain a replacement sign. Post the sign as described above. PROFORM is a registered trademark of ICON Health & Fitness, Inc.
Page 3: Important Safety Instructions
Important Safety Instructions WARNING: To reduce the risk of drowning, electric shock, or serious injury, read the fol- lowing important precautions before using the hydrotherapy spa. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions.
Page 4 The effects of hyperthermia include failure to per- ceive heat; failure to recognize the need to exit the spa or hot tub; unawareness of impending hazard; fetal damage in pregnant women; physical inability to exit the spa or hot tub and unconsciousness resulting in danger of drowning.
Page 5: Save These Instructions
35. WARNING: The spa jets produce a stream of water with relatively high pressure. Prolonged exposure of a localized area of the body may cause bruises to the skin. 36. The included warning sign must be posted where all users of the hydrotherapy spa can see and read it.
Page 6: Before You Begin
Time (excluding holidays). To help us assist you, please mention the product model number and serial number when calling. The model number is PFSB62830. The serial number can be found on a decal on the access panel inside the spa (see the front cover of this manual).
Page 7: Choosing A Location For The Hydrotherapy Spa
Choosing a Location for the Hydrotherapy Spa There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you plan to use the spa inside or outside. We have listed several factors you may wish to consider as you decide where to set up the spa.
Page 8: Assembly
Assembly Before beginning assembly, carefully read the following information and instructions: • Place all parts in a cleared area and remove the packing materials from the spa shell. Do not dis- pose of the packing materials until assembly is completed and the spa is operating. •...
Page 9 3. Locate the three pillows. Each pillow can be attached to the spa shell in a high position or a low position. To determine the high and low positions, attach one pillow to the spa shell, note its position, remove it, turn it 180°, and then re-attach it. Attach the three pillows in the desired positions.
Page 10: Using The Hydrotherapy Spa
Using the Hydrotherapy Spa The hydrotherapy spa is designed to seat five adults. The spa holds 295 gallons of water and offers a heat- ing system (80°F to 104°F), a filtration system, and adjustable hydrotherapy jets. Follow the guidelines below to use and maintain the spa for your long-term enjoyment.
Page 11: Spa Shell Diagram
Spa Shell Diagram Refer to the diagram above. The function of each component is explained below. A. The four adjustable, directional jets can be pivot- ed to direct their water flow. To open the jets, turn the rims counterclockwise; to close the jets, turn the rims clockwise.
Page 12: Using The Controls
Using the Controls Waterfall knob Air Control M Air Control L Diverter Knob Refer to the diagram above. The function of each control is explained below: Jet Button: Turns the spa jets on and off. If the but- ton is pressed once, the spa jets will run at low speed, providing gentle hydrotherapy.
Page 13: Maintenance
Maintenance The hydrotherapy spa is designed to provide years of enjoyment. Please follow the guidelines below to properly maintain your spa. MAINTENANCE SCHEDULE Daily • Check the water level and refill the spa to the level shown in step 5 on page 9. •...
Page 14 WATER CHEMISTRY CAUTION: The chemicals used to maintain the pH balance of the water and to sanitize the water can be dangerous. Always follow these basic guide- lines when handling the chemicals: 1. Always read and follow the directions on the label, unless directed otherwise.
Page 15 To drain the hydrotherapy spa, follow the steps below: 1. Using the console, adjust the temperature to the lowest setting. 2. Shut off the power to the spa, at the circuit breaker or GFCI. 3. Remove the access panel from the spa (see ATTACHING AND REMOVING THE ACCESS PANEL on page 14).
Page 16: Troubleshooting
Troubleshooting Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-877-897-7493, Monday through Friday, 8 a.m. until 5 p.m. Central Time. 1.
Page 17 10. SYMPTOM: THE SPA JET UNIT CONTINUES TO RUN AFTER IT HAS BEEN SHUT OFF a. The spa jets are controlled with the jet button. If the button is pressed once, the spa jets will run at low speed. If the button is pressed again, the spa jets will run at high speed.
Page 18: Part List
Part List—Model No. PFSB62830 Key No. Qty. Description Thermometer Fitting Access Panel Face Ring Small Rotator Short Panel Pivot Ring #10 x 2” Sheet Metal Screw Filter Cover #10 x 1 1/2” Sheet Metal Screw Medium Jet Housing Spa Cover...
Page 19: Exploded Drawing
Exploded Drawing—Model No. PFSB62830 R0203A...
Page 20: Ordering Replacement Parts
Friday, 8 a.m. until 5 p.m. Central Time (excluding holidays). To help us assist you, please be prepared to give the following information when calling: • The MODEL NUMBER of the product (PFSB62830) • The NAME of the product (PROFORM •...
