Patent Pending
Model No. 831.210050
Serial No.
Write the serial number in the space
above for reference. The serial
number decal is on the frame behind
the access cover.
QUESTIONS?
PLEASE CALL DIRECT TO OUR
TOLL-FREE CUSTOMER HOT
LINE. The trained technicians
on our customer hot line will
provide immediate assistance,
free of charge to you.
CUSTOMER HOT LINE:
1-800-999-3756
Mon.ÐFri., 6 a.m.Ð6 p.m. MST
CAUTION
Read all precautions and instruc-
tions in this manual before
using this equipment. Save this
manual for future reference.
Hydrotherapy Spa
USER'S MANUAL
A pH testing kit (not included) is required
for proper use and maintenance of this
product. A pH testing kit can be pur-
chased at any spa or pool supply store.
SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179
Advertisement
Table of Contents
Related Manuals for ProForm 831.21005
Summary of Contents for ProForm 831.21005
- Page 1 Patent Pending Model No. 831.210050 Serial No. Write the serial number in the space above for reference. The serial number decal is on the frame behind the access cover. QUESTIONS? PLEASE CALL DIRECT TO OUR TOLL-FREE CUSTOMER HOT LINE. The trained technicians on our customer hot line will provide immediate assistance, free of charge to you.
-
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS ............3 BEFORE YOU BEGIN . -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS WARNING: TO REDUCE THE RISK OF DROWNING, ELECTRIC SHOCK, OR SERIOUS INJURY, READ THE FOLLOWING IMPORTANT PRECAUTIONS BEFORE USING THE RESTORATION 5.1. READ AND FOLLOW ALL INSTRUCTIONS 1. It is the responsibility of the owner to ensure that all users of the hydrotherapy spa are adequately informed of all precautions. - Page 4 20. DANGERÑIf you will be using the hydrother- apy spa outside, do not bury the power cord; you should also keep the power cord away from lawn mowers, hedge trimmers, and other similar equipment. 21. WARNINGÑThe hydrotherapy spa must be wired directly into a 240 volt power source equipped with a Ground Fault Circuit Interrupter (GFCI).
-
Page 5: Save These Instructions
34. WARNINGÑTo reduce the risk of injury or drowning: Consult your physician about pos- sible side-effects of any medications you may be taking before using the hydrotherapy spa. Heat from the water, in conjunction with some medications may cause drowsiness and increase the risk of drowning. -
Page 6: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the innovative PROFORM RESTORATION 5.1 hydrotherapy spa. The RESTORATION 5.1 hydrotherapy spa offers the fea- tures and quality of a traditional hot tub at an afford- able price. Best of all, the RESTORATION 5.1 hydrotherapy spa provides the benefits of hydrothera- py in the comfort and privacy of your own home. -
Page 7: Choosing A Location For The Hydrotherapy Spa
CHOOSING A LOCATION FOR THE HYDROTHERAPY SPA There are many factors to consider when choosing a location to set up the hydrotherapy spa. These factors vary depending on whether you use the hydrotherapy spa inside or outside. We have listed several factors you may wish to consider as you decide where you want to use the hydrotherapy spa. -
Page 8: Set-Up And Assembly
SET-UP AND ASSEMBLY Before beginning assembly, carefully read the following information and instructions: ¥ Place all parts in a cleared area and remove the packing materials from the spa shell; do not dis- pose of the packing materials until assembly is completed and the spa is in operation. - Page 9 3. Place the Spa Cover (18) over the spa. Be sure that the Spa Cover is properly centered. Snap a Buckle (2) onto each of the four latches on the Spa Cover (18). See the inset drawing. Position one of the Buckles (2) on the wood panels on the Spa Unit (15).
-
Page 10: Wiring The Restoration 5.1
WIRING THE RESTORATION 5.1 The RESTORATION 5.1 is designed to operate with a 240 volt AC power source; it must be wired by a qualified electrician directly into a 240 volt AC GFCI in your home. The steps below are intended to be used as a reference for the qualified electrician who wires your spa and installs the 240 volt AC GFCI in your home. - Page 11 5. For a 40 amp 240 volt AC power supply, set the jumper J1 to pins 1 and 2 on the power board and leave the other jumpers at the factory settings, as shown at the right. This will allow the heater and the pump to operate at high speed simultaneously.
-
Page 12: Using The Hydrotherapy Spa
USING THE HYDROTHERAPY SPA The hydrotherapy spa is designed to seat five adults. The fifteen thera-jets can be regulated to provide a relaxing massage to sooth away stress, and the strength of the water massage can be adjusted by the air control. - Page 13 SPA SHELL DIAGRAM SPA OPERATION Refer to the diagram above. The function of each component is explained below: The eight uni-directional thera-jets (A) are located on both sides of the spa. Five jets focus the water massage on your upper or lower back. The remaining three jets provide a foot hydro-massage for three of the seating positions.
- Page 14 CONSOLE DIAGRAM USING THE CONSOLE Refer to the console diagram above. The function of each console control is explained below: Temperature Display: During normal use this display shows the actual water temperature. When the Set Temp indicator is lit, the display shows the set temperature.
- Page 15 ADJUSTING THE FILTER CYCLE The spa filter cycle runs automatically to clean the water in the spa. However, the number of times that the filter cycle needs to run depends on how often the spa is used. If many different people use the spa regularly, then the water will need to be filtered more often than if it is only used occasionally by a few.
-
Page 16: Maintenance
MAINTENANCE The hydrotherapy spa is designed to provide you with years of enjoyment. Please follow the guidelines below to properly maintain your hydrotherapy spa. MAINTENANCE SCHEDULE DAILY ¥ Check the water level and refill the spa to the level shown on page 9, step 5. ¥... - Page 17 SANITIZING THE HYDROTHERAPY SPA Please refer to your local pool and spa supplier for information concerning which chemicals you should use in your area to sanitize the spa. The most common sanitizing agent is a solid bromine concentrate. The amount required varies according to several factors, such as user load, temperature, water conditions, and so forth.
- Page 18 should also be drained if you will not be using it for long periods of time. The spa must always be drained before major repairs are made. The hydrotherapy spa should always be covered when it is empty. Direct sunlight can cause exten- sive damage.
- Page 19 WINTER USE AND CARE The hydrotherapy spa is designed for year-round use. If you decide to store the hydrotherapy spa for the winter, store it in a warm, dry location. Follow the steps below to winterize the hydrotherapy spa. 1. Drain the spa (see DRAINING THE HYDROTHERAPY SPA on pages 17 and 18).
-
Page 20: Trouble-Shooting
TROUBLE - SHOOTING Most problems can be solved by following the simple steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, call our Customer Service Department toll-free at 1-800-999-3756, Monday through Friday, 6 a.m. until 6 p.m. Mountain Time. 1. - Page 21 ment for excess water, and watch the pump unit while it is operating to see if water drips from any of the plumbing. If you can identify the location of the leak inside the spa jet unit, tight- en the clamp or replace the damaged seal. 10.
-
Page 22: Part List
PART LISTÑModel No. 831.210050 Key No. Qty. Description Buckle Screw Buckle Motor Screw Motor Washer Rubber Insulator Blue Lens Heater Switch Small Star Washer Heat Sensor Filter Hose Cap Rubber Damper Pump Motor Control Unit Spa Unit Console Control Knob Spa Cover Control Unit Screw Small Index Nut... -
Page 23: Exploded Drawing
EXPLODED DRAWINGÑModel No. 831.210050 R0498A... -
Page 24: Ordering Replacement Parts
1. The MODEL NUMBER of the product (831.210050). 2. The NAME of the product (PROFORM 3. The SERIAL NUMBER of the product (see the front cover of this manual).
