Model No. PFCCEL3906.0
Serial No.
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you have
questions, or if there are missing
parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 17h00 EST
(excluding holidays).
customerservice@iconcanada.ca
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
_
Serial
Number
Decal
USER'S MANUAL
Visit our website at
www.proform.com
Visit our website at
Advertisement
Table of Contents
Related Manuals for ProForm PFCCEL3906.0
Summary of Contents for ProForm PFCCEL3906.0
- Page 1 Model No. PFCCEL3906.0 Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 1-888-936-4266 Mon.–Fri. 8h00 until 17h00 EST (excluding holidays).
-
Page 2: Table Of Contents
LIMITED WARRANTY ............. .Back Cover PROFORM is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read the following important precau- tions before using the elliptical exerciser. 1. Read all instructions in this manual and all warnings on the elliptical exerciser before using the elliptical exerciser. Use the ellipti- cal exerciser only as described in this manual. -
Page 4: Before You Begin
To help us assist you, note the product model number and serial number before con- tacting us. The model number is PFCCEL3906.0. The serial number can be found on a decal attached to the elliptical exerciser (see the front cover of this manual). -
Page 5: Assembly
Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. In addition to the included hex keys, assembly requires a phillips screwdriver wrench , and a rubber mallet As you assemble the elliptical exerciser, use the drawings below to identify small parts. - Page 6 1. Identify the Rear Stabilizer (4). While another person lifts the rear of the Frame (1), attach the Rear Stabilizer to the Frame with two M10 x 75mm Carriage Bolts (34) and two M10 Nylon Locknuts (29). 2. See the inset drawing. Remove the two M10 x 45mm Button Bolts (33) and the packing tubes from the front of the Frame (1).
- Page 7 tion shown, connect the Upper Wire Harness (86) to the Extension Wire Harness (95). Next, insert the Upright (2) into the Mast (15); make sure that the Upright is oriented as shown. Attach the Upright with two M8 x 70mm Button Bolts (67), two M8 Split Washers (83), and two M8 Nylon Locknuts (46).
- Page 8 7. Slide the Right Crank Arm (38) onto the four indicated welded bolts; make sure that the Right Crank Arm is in the indicated cutout in the Pedal Disk (8). Next, finger tighten four M8 Jamnuts (80) onto the welded bolts.
- Page 9 10. Identify the Left Handlebar (9), which is marked with a sticker. Insert the Left Handlebar into one of the Handlebar Legs (79); make sure that the Handlebar Leg is turned so the hexagonal holes are on the indicated side. Attach the Left Handlebar with two M8 x 45mm Button Bolts (50) and two M8 Nylon Locknuts (46).
-
Page 10: How To Use The Elliptical Exerciser
HOW TO EXERCISE ON THE ELLIPTICAL EXERCISER To mount the elliptical exerciser, hold the handgrip pulse sensor and step onto the pedal that is in the low- est position. Next, step onto the other pedal. Push the pedals until they begin to move with a continuous motion. -
Page 11: Features Of The Console
Program Button Profiles Program Button FEATURES OF THE CONSOLE The advanced console offers a selection of features designed to make your workouts more effective. When the manual mode of the console is selected, the resis- tance of the pedals can be changed with the touch of a button. - Page 12 The upper half of the display will show the elapsed time, the distance (total revolutions) you have pedaled, and the resistance level of the pedals. The display will change from one mode to the next every few seconds. Note: When a program is selected (except for pulse pro- gram 2), the display will show the time remaining in the program instead of the elapsed time.
- Page 13 HOW TO USE A PULSE PROGRAM Pulse program 1 is designed to keep your heart rate within a set range during your workout. Pulse program 2 is designed to keep your heart rate near a target heart rate setting that you select. Follow the steps below to use a pulse program.
- Page 14 See step 6 on page 12. When you are finished exercising, the console will automatically turn off. See step 7 on page 12. HOW TO USE A PRESET PROGRAM Preset programs 3, 4, 5, and 6 automatically change the resistance of the pedals and prompt you to increase or decrease your pedaling pace as they guide you through effective workouts.
-
Page 15: Maintenance And Troubleshooting
Inspect and tighten all parts of the elliptical exerciser regularly. Replace any worn parts immediately. To clean the elliptical exerciser, use a damp cloth and a small amount of mild soap. Important: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight. -
Page 16: Conditioning Guidelines
WARNING: Before beginning this or any exercise pro- gram, consult your physician. This is espe- cially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings. -
Page 17: Part List
Key No. Qty. Description Frame Upright Front Stabilizer Rear Stabilizer Console Left Side Shield Right Side Shield Pedal Disc Left Handlebar Right Handlebar Foam Grip Pedal Upright Endcap Left Pedal Arm Mast Pedal Post Adjustment Pin Pedal Arm Bushing Adjustment Spring Adjustment Bracket Snap Ring M8 x 25mm Patch Screw... -
Page 18: Exploded Drawing
R0706A... - Page 19 R0706A...
-
Page 20: How To Order Replacement Parts
• the MODEL NUMBER of the product (PFCCEL3906.0) • the NAME of the product (PROFORM STRIDE SELECT 825 elliptical exerciser) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
