ProForm 831.23744.1 User Manual

Proform elliptical exerciser user's manual 831.23744.1
Hide thumbs

Advertisement

Table of Contents

Model No. 831.23744.1
Serial No.
Write the serial number in the
space above for reference.
• Assembly
• Operation
• Maintenance
• Part List and Drawing
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Keep this manual
for future reference.
ELLIPTICAL EXERCISER
Serial
Number
Decal
User's Manual
Sears, Roebuck and Co., Hoffman Estates, IL 60179

Advertisement

Table of Contents
loading

Related Manuals for ProForm 831.23744.1

Summary of Contents for ProForm 831.23744.1

  • Page 1 Model No. 831.23744.1 Serial No. Write the serial number in the space above for reference. Serial Number Decal • Assembly • Operation • Maintenance • Part List and Drawing CAUTION Read all precautions and instruc- tions in this manual before using this equipment.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. .2 IMPORTANT PRECAUTIONS .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your elliptical exerciser before using your elliptical exerciser. Sears assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for purchasing the revolutionary PROFORM ® XP 520 RAZOR elliptical exerciser. The XP 520 RAZOR elliptical exerciser provides a wide array of features designed to make your workouts at home more effective and enjoyable. For your benefit, read this manual carefully before you use the elliptical exerciser.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two persons. Place all parts of the elliptical exerciser in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included hex keys and your own Phillips screwdriver wrench , and rubber mallet As you assemble the elliptical exerciser, use the drawings below to identify small parts.
  • Page 6 To make assembly easier, read the information on page 5 before you begin assembling the elliptical exerciser. Pull the ramp handle outward and lower the Ramp (104) until it rests on the Frame (1). Attach a Wheel (50) to the front of the Frame (1) with an M10 x 35mm Shoulder Screw (63).
  • Page 7 3. Tip: Be careful not to pinch the Wire Harness (100) during this step. Start all screws before tightening any of them. Have another person hold the Upright (2) near the Frame (1). Locate the wire tie in the Upright. Tie the lower end of the wire tie to the Wire Harness (100).
  • Page 8 5. The Console (4) can be operated with four 1.5V “D” batteries (not included); alkaline batteries are recommended. IMPORTANT: If the elliptical exerciser has been exposed to cold tempera- tures, allow it to warm to room temperature before inserting batteries into the Console. If you do not do this, the console displays or other electronic components may become damaged.
  • Page 9 7. Slide the Console Cover (96) (see the drawing in step 6) upward to the Console (4). Attach the Console Cover with four M4 x 16mm Screws (84). 8. Apply a generous amount of the included grease to the Pivot Axle (16). Then, apply a small amount of grease to two Wave Washers (88).
  • Page 10 9. Attach the Left Pedal (12) to the left Pedal Arm (14) with three M10 x 70mm Button Screws (75), three M10 Split Washers (78), and an M4 x 16mm Screw (84). Repeat this step for the other side of the elliptical exerciser.
  • Page 11 11. At the same time, insert a Pedal Arm Axle (21) into the Right Upper Body Leg (124) and into the right Pedal Arm (14); make sure that the Upper Body Leg Spacer (113) and the Pedal Leg Spacer (114) are in the indicated loca- tions.

  • Page 12: How To Use The Elliptical Exerciser

    HOW TO USE THE ELLIPTICAL EXERCISER HOW TO MOVE THE ELLIPTICAL EXERCISER Due to the size and weight of the elliptical exercis- er, moving it requires two persons. Stand in front of the elliptical exerciser, hold the upright, and place one foot against one of the front wheels.
  • Page 13 HOW TO ADJUST THE STRIDE OF THE ELLIPTICAL EXERCISER To adjust the stride of the elliptical exerciser, first pull one of the adjustment knobs until the adjustment bracket pivots freely. Pivot the adjustment bracket until the adjustment knob is aligned with one of the holes in the crank arm, and gently release the knob.
  • Page 14 CONSOLE DIAGRAM FEATURES OF THE CONSOLE The advanced console offers an array of features designed to make your workouts more effective and enjoyable. When you use the manual mode of the console, you can change the resistance of the pedals with the touch of a button.
  • Page 15 HOW TO USE THE MANUAL MODE Note: If there is a sheet of clear plastic on the face of the console, remove the plastic. 1. Press the Resistance decrease button or begin pedaling to turn on the console. A moment after you turn on the console, the dis- plays will light.
  • Page 16 5. Measure your heart rate if desired. If there are sheets of clear plastic on the metal contacts on the handgrip pulse sen- sor, remove the plas- tic. To measure your heart rate, hold the handgrip pulse sensor with your palms resting against the metal con- tacts.
  • Page 17 As you exercise, you will be prompted to keep your pedaling pace near the target rpm setting for the current segment. When the words PEDAL FASTER appear in the upper display or the GO FASTER indicator on the pace guide is lit, increase your pace.
  • Page 18 HOW TO USE A TARGET TONING WORKOUT 1. Turn on the console. See step 1 on page 15. 2. Select a target toning workout. To select a target toning workout, press the Workout button repeatedly until the words TAR- GET TONING 1 or TARGET TONING 2 appear in the upper display.
  • Page 19 HOW TO USE A CALORIE GOAL WORKOUT 1. Turn on the console. See step 1 on page 15. 2. Select a calorie goal workout. Press the Workout button repeatedly until the name of the desired calorie goal workout appears in the upper display.
  • Page 20 HOW TO USE THE HIGH PERFORMANCE WORKOUT 1. Turn on the console. See step 1 on page 15. 2. Select the high performance workout. Press the Workout button repeatedly until the words HIGH PERFORMANCE appear in the upper dis- play. The workout time will appear in the left dis- play and a profile of the resistance levels for the workout will scroll across the center display.

  • Page 21: Maintenance And Troubleshooting

    MAINTENANCE AND TROUBLESHOOTING Inspect and tighten all parts of the elliptical exerciser regularly. Replace any worn parts immediately. To clean the elliptical exerciser, use a damp cloth and a small amount of mild soap. IMPORTANT: To avoid damage to the console, keep liquids away from the console and keep the console out of direct sunlight.

  • Page 22: Exercise Guidelines

    EXERCISE GUIDELINES WARNING: Before beginning this or any exercise program, consult your physician. This is especially important for persons over the age of 35 or persons with pre-existing health problems. The pulse sensor is not a medical device. Various factors may affect the accuracy of heart rate readings.
  • Page 23 SUGGESTED STRETCHES The correct form for several basic stretches is shown at the right. Move slowly as you stretch—never bounce. 1. Toe Touch Stretch Stand with your knees bent slightly and slowly bend forward from your hips. Allow your back and shoulders to relax as you reach down toward your toes as far as possible.

  • Page 24: Part List

    PART LIST—Model No. 831.23744.1 Key No. Qty. Description Frame Upright Console Bracket Console Bottle Holder Left Upper Body Leg Idler Wheel Left Upper Body Arm Right Upper Body Arm Foam Grip Upper Endcap Left Pedal Right Pedal Pedal Arm Pedal Bracket...
  • Page 25 Key No. Qty. Description M4 x 48mm Screw M4 x 25mm Screw M4 x 35mm Screw M4 x 16mm Flat Head Screw M4 x 32mm Screw Console Cover M8 x 18mm Button Screw M5 x 12mm Screw M3 x 12mm Screw Wire Harness Extended Reed Switch Wire Right Adjustment Bracket...

  • Page 26: Exploded Drawing

    EXPLODED DRAWING A—Model No. 831.23744.1 116 115 R1107A...
  • Page 27 EXPLODED DRAWING B—Model No. 831.23744.1 R1107A...

  • Page 28: 90 Day Full Warranty
