MOSFET POWER AMPLIFIERS

Installation Instructions / Owner's Manual
CA200
CA400
CA600
CA800
CA1200
CA440
CA640
CA400M
CA600M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the California CA1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for Profile California CA1200

  • Page 1: Mosfet Power Amplifiers

    MOSFET POWER AMPLIFIERS Installation Instructions / Owner's Manual CA200 CA400 CA600 CA800 CA1200 CA440 CA640 CA400M CA600M...
  • Page 3 It is recommended that you have our product installed by an authorized Profile retailer. However, if you decide to install it yourself, please carefully read through this manual and take your time to do a quality installation.
  • Page 4: Safety Precautions

    AFETY PRECAUTIONS Fuse amplifier’s power wire at the battery. Be sure to fuse the power wire within 12” of the car's battery. This will protect the car's battery in case of a short circuit between the power amplifier and battery. THIS IS A MUST, the amplifier's built-in fuse will only protect the power amplifier not the car's battery! The fuse value is based on the amplifiers rated power and how many amplifiers will be run off the same power wire.
  • Page 5: Features And Benefits

    EATURES AND BENEFITS DC Offset Protection This circuit protects the output of the amplifier against DC voltage. If for some reason DC voltage is detected at the output stage, the amplifier will shut down protecting the speakers from direct current. Short Circuit Protection The circuit protects the amplifier from damage due to a short found in the speakers or wiring.
  • Page 6: Remote Turn-On

    Bass Boost For added low frequency performance the amplifiers are equipped with a variable 0~12 dB bass boost @ 45Hz. Power Fusing This protects the amplifier against short circuits and excessive current. Remote Turn-on Automatically turns amplifier on when connected to the head unit's remote output. The amplifier will turn on and off with the head unit to save current consumption.
  • Page 7: Power Connections

    RADIO'S REMOTE RADIO'S REMOTE TURN-ON OUTPUT TURN-ON OUTPUT IMPORTANT! Before making any connections, disconnect the car’s battery until the installation is completed to avoid possible damage to the electrical system. Connect the amplifier to the car's battery. At times, the amplifier will need to draw large levels of current that cannot be provided by any circuit in the car's fuse box.
  • Page 8: Mounting Location

    Before you start the installation, it will be necessary to find a mounting location for the amplifier. Find a location in which the amplifier will receive adequate ventilation in order to dissipate the heat it develops during operation. Two popular mounting locations are in the trunk or under the seat.
  • Page 9: Signal Connections

    Connect the RCA output of the head unit (AM/FM cassette player, CD, or DAT) to the RCA input terminals of the amplifier. To make these connections, we recommend high quality RCA cables, which are available at your local car audio retailer. Run signal wires away from electrical wires to avoid possibility of induced noise from the car's electrical system (i.e.
  • Page 10 IGH LEVEL CONNECTIONS (OPTIONAL) High Level inputs have been included to connect the amplifier to a radio without low-level outputs (i.e. factory radio). This connection will allow you to connect directly to the speaker output of the radio with out the need of an external adapter. Determine the type of radio you have and make one of the following connections.
  • Page 11: Speaker Connections

    Make the speaker connections using speaker wire that is at least 14 gauge or heavier. As with any audio component, proper phasing of the amplifier and speakers is essential for strong bass response. When connecting, make sure that positive (+) from the amplifier is connected to the positive (+) of the speaker, and the same for negative (-).
  • Page 12 PEAKER CONNECTIONS (BRIDGED) The California amplifiers are capable of being bridged in a mono configuration. This feature allows you the flexibility of using the amplifier to drive a ** subwoofer or a center channel. In this configuration the amplifier sums the right and left channel to deliver one channel (mono) output.
  • Page 13 4 Ohm connections. If you wish to use multiple speakers to achieve a lower impedance and higher power, it is strongly recommended that you seek professional advice from your Profile retailer before attempting to make these connections. Please Note: In the Tri-mode configuration, the amplifier’s built-in crossover must be set to...
  • Page 14 ETTING THE CROSSOVER AND BASS BOOST Select your crossover type and frequency. (Please note: If you intend to u se the amplifier in the Tri-mode configuration, it is necessary to set the crossover control to the “Off” setting in order to receive full range output) The California amplifiers are equipped with a built-in variable crossover network allowing you to select the crossover type (i.e.
  • Page 15: Troubleshooting The System

    ROUBLE SHOOTING THE SYSTEM We have put together this trouble-shooting guide if you experience problems after installing the amplifier. Please keep in mind that the majority of problems incurred are caused by improper installation and not the equipment itself. In addition, there are many components in the system that could cause various signal problems such as inducted electrical noise and engine noise.
  • Page 16: Specifications

    6 Gauge 1 x 20A 2” x 9 / ” x 7 / ” 2” x 9 / ” x 10 / ” CA800 CA1200 2 x 400W 2 x 600W 2 x 200W 2 x 300W 2 x 300W...
  • Page 17 Output Power @ 4 Ohm Power @ 4 Ohm Power @ 2 Ohm Bridged RMS @ 4 Ohm THD @ RMS Power Frequency Response Signal To Noise Stereo Separation Low Level Input RCA Input Impedance Load Impedance Stereo Load Impedance Bridged Crossover Type (12dB/Octave) Crossover Frequency (Variable) Bass Boost @ 45Hz...
  • Page 18: Limited Warranty

    One (1) Year from the date of sale to the original consumer purchaser. If this product is proven to be defective within this one year period, Profile will repair it when said product is returned, with a copy of the dated sales receipt, freight prepaid to Profile.
  • Page 19: Warranty Repair Policy

    5) Include the return street address and daytime telephone number. 6) Allow 2~3 weeks for repair (this period includes shipping time). Send unit to : PROFILE CONSUMER ELECTRONICS, INC. 15060 SHOEMAKER AVE SANTA FE SPRINGS, CA 90670 TEL: (562) 404-9393...
  • Page 20 PROFILE CONSUMER ELECTRONICS, INC. 15060 SHOEMAKER AVE SANTA FE SPRINGS, CA 90670 TEL: (562)404-9393 FAX: (562)404-9433 WWW.PROFILEUSA.COM...
