figure 1
M4 Front Panel Features
MASTER poWER SWITCh
When pressed in, the M4
permits zones to be turned
ON and OFF by keypad or
touch panel commands.
M4 QUICK START GUIDE
BLUE InDICAToR LIGhT
Blue indicates the master
power switch is ON and one
or more zones are active.
Red is OFF.
ZonE STATUS LEDS
LED indicators and labels:
Four blue LEDs indicate
that one or more zones
are currently active.
Advertisement
Related Manuals for Proficient Audio Systems M4
Summary of Contents for Proficient Audio Systems M4
- Page 1 M4 QUICK START GUIDE figure 1 M4 Front Panel Features MASTER poWER SWITCh When pressed in, the M4 permits zones to be turned ON and OFF by keypad or touch panel commands. BLUE InDICAToR LIGhT Blue indicates the master power switch is ON and one or more zones are active.
- Page 2 The jack is programmable by proficient Editor, to turn on as events, when triggered by the The M4 is a four-zone, six-source Audio Amplifier/Controller. It serves as the DOORBELL/STATUS IN Jack. “brains” of the entire keypad system. The M4 provides audio switching for six sources and 30W/channel audio power amplifiers for four zones.
- Page 3 TREB BASS BASS TREB TREB BASS BASS TREB TREB for the M4. When the system is off, all buttons have a background green color. When a source button is PLAY PLAY MUTE MUTE MUTE MUTE MUTE pressed, it turns to a low-level red color to show that it is the active source and the system is on.
- Page 4 SYSTEM ConnECTIonS AnD ConfIGURATIon factory Default System Whole house/party Mode As mentioned earlier, the M4 comes with a set of four 5. All zones are set for Whole House/Party Mode pre-configured PMKIR keypads, one for each zone. In capability Whole House/Party Mode: Forces all zones...
- Page 5 9 V Active High, 82 Ω (110 mA Peak) as provided above. In no event will Proficient Audio Systems be liable for any incidental or con- sequential damages arising out of the use or inability to use the product, even if Proficient Audio –...
