Primera LX200e Quick Start

5

Installing Label Stock

(continued)
3. Place the label roll between the Stock Guide
Rollers and release the spring-loaded stock
guide to hold the label stock. The Stock
Guide Rollers allow the label stock roll to
move freely.
Stock Guide Rollers
6

Installing Ink Cartridges

To install the cartridge for the first time, click the
Install Cartridge link in the installer and follow
the on screen prompts. Refer to Section 2H of
the User Manual for normal cartridge change
instructions.
4. Place the leading edge of the label stock
between the throat guide and the side of
the printer.
Throat Guide
5. Feed the label stock further into the printer
until it senses the label and automatically
feeds it through the printer.
Note: If you are using fan-fold label stock or label stock
other than standard square / rectangular die-cut labels
see Sections 2F and 2G in the Users Manual before
continuing. You can download the manual at
http://primera-europe.eu/europe/manuals.html.
