- Page 1 Synergy TRU-Balance BASIC OPERATION INSTRUCTIONS Dynamic Controller ACN# 088 609 661 ACN# 088 609 661...
-
Page 2: Safety Guidelines
The latest/current version of this manual is available on our website. 088 609 661 Copyright © 2008 Pride Mobility Products Corporation INFMANU3676/Rev B/May 2008 Dynamic Controller Basic Operation Instructions... -
Page 3: Table Of Contents
TABLE OF CONTENTS Basic Operation Instructions LABEL INFORMATION ... 4 INTRODUCTION ... 5 DYNAMIC CONTROLLER ... 7 PRECAUTIONARY GUIDELINES ... 7 OPERATING THE DYNAMIC CONTROLLER ... 11 CONTROLLER CONNECTOR ... 16 OFF-BOARD CHARGER/PROGRAMMING SOCKET ... 16 LOCK MODE ... 16 ACTUATOR ADJUSTMENT ... -
Page 4: Label Information
LABEL INFORMATION PRODUCT SAFETY SYMBOLS The symbols below are used on the controller to identify warnings, mandatory actions, and prohibited actions. It is very important for you to read and under- stand them completely. Read and follow the information in the owner’s manual. Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. -
Page 5: Introduction
Basic Operation Instructions INTRODUCTION WELCOME to Pride Mobility Products Corporation (Pride). The product you have purchased combines state-of-the-art components with safety, comfort, and styling in mind. We are confident that the design features will provide you with the conveniences you expect during your daily activities. Understanding how to safely operate and care for this product should bring you years of trouble free operations and service. - Page 6 NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and we will be glad to send you a new one immediately. My authorized Pride Provider Is: Name: _____________________________________________________ Address: ____________________________________________________ Phone Number: ______________________________________________ Purchase Date: _______________________________________________ Dynamic Controller...
-
Page 7: Dynamic Controller
Basic Operation Instructions DYNAMIC CONTROLLER The Dynamic controller is a modular electronic controller system that allows you to operate your power chair. It is designed to allow the user to have complete control over chair movement and speed. The controller is available in both 50-amp and 60-amp configurations, and has been pre-programmed to meet a typical user’s needs. - Page 8 Electromagnetic and Radio Frequency Interference (EMI/RFI) WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can have an adverse affect on the performance of electrically-powered mobility vehicles. Electromagnetic and Radio Frequency Interference can come from sources such as cellular phones, mobile two-way radios (such as walkie-talkies), radio stations, TV stations, amateur radio (HAM) transmitters, wireless computer links, microwave sig- nals, paging transmitters, and medium-range mobile transceivers used by emergency...
-
Page 9: Sleep Mode
Basic Operation Instructions Dynamic Controller Features Figure 1 provides information on the Dynamic controller components and connections. Use this diagram to familiarize yourself with the function and location of each component before using the Dynamic controller. The following functions are available with the Dynamic controller: ! Joystick Control The joystick is used to control the direction and speed of the power chair. - Page 10 On/Off Key Press to power on or off the power chair and controller. Speed Decrease Key Used to decrease the speed setting. Speed Setting Indicator Series of five colored LEDs which display the speed setting. Joystick A multi-functional tool used to control speed and direction.
-
Page 11: Operating The Dynamic Controller
Basic Operation Instructions OPERATING THE DYNAMIC CONTROLLER The Dynamic controller is used to operate your power chair and all of its components. The Dynamic controller consists of (see figure 2): 1. joystick 2. keypad 3. off-board charger/programming socket 4. controller connector 5. - Page 12 Basic Operation Instructions Figure 3. Dynamic Controller 4-key Keypad Figure 4. Dynamic Controller 7-key Keypad Dynamic Controller www.pridemobility.com...
- Page 13 Basic Operation Instructions Figure 5. Dynamic Controller 8-key Keypad Figure 6. Dynamic Controller 9-key Keypad www.pridemobility.com Dynamic Controller...
- Page 14 Keypad The keypad is located directly in front of the joystick. It contains keys that you will use to control your power chair. See figure 2. On/Off Key The on/off key turns the system on and off. WARNING! Unless faced with an emergency situation, do not use the on/off key to stop the chair.
- Page 15 Basic Operation Instructions Speed Keys There are two keys that control the speed. Press the speed increase key to in- crease the speed. Press the speed decrease key to decrease the speed. The speed setting is displayed on the speed setting indicator. If your power chair was pro- grammed with a drive profile, contact your authorized Pride Provider for more information.
-
Page 16: Controller Connector
Right/Left Turn Indicator Keys (For Optional Equipment) The right/left turn indicator keys toggle either the left or right turn indicators. Press once to turn on and press again to turn off. You can also turn off the selected turn indicator by pressing the opposite indicator key or the hazard key. Light Key (For Optional Equipment) The light key turns the headlights/taillights on and off independent of other indicators. -
Page 17: Actuator Adjustment
Basic Operation Instructions To unlock the Dynamic controller: 1. While the Dynamic controller is locked, press the on/off key to turn on the controller. All LEDs will flash briefly. The LEDs will then slowly ripple from right to left. 2. Press the horn key twice before the LED ripple has completed, approximately 10 seconds. -
Page 18: Sleep Mode (If Enabled)
SLEEP MODE (IF ENABLED) The power chair controller features a sleep mode. Sleep mode is a built-in circuit that will automatically shut off the main power if the joystick is not moved in any direction for a period of time. This time factor is programmed into the controller. To restore power and continue, push any key on the keypad. -
Page 19: Care And Maintenance
Basic Operation Instructions Error Code Probable Cause Possible stall timeout or user error Battery Fault Left Motor Fault Right Motor Fault Left Park Brake Fault Right Park Brake Fault Dynamic Controller Module Fault Dynamic Controller Power Module Fault Dynamic Controller Communications Fault Unknown Fault Incompatible Controller Fault... - Page 20 St. Catharines, Ontario L2R 6P7 Canada Pride Mobility Products Ltd. 32 Wedgwood Road Bicester, Oxon OX26 4UL Pride Mobility Products Australia Pty. Ltd. 21 Healey Road Dandenong, 3175 Victoria, Australia Pride Mobility Products Italia S.r.l. Via del Progresso - ang. Via del Lavoro Loc.
