INSTRUCTIONS FOR INSTALLATION AND USE
Ceiling Fan Model Classic (FN433XX)

BEFORE YOU START

Proper use:
This product is intended exclusively for non-commercial use as ceiling fan.
-
The product has to be installed and used in accordance with these instructions.
-
Any use of this product that is not in accordance with these instructions will void the legal
-
warranty of the manufacturer.
Please keep the original carton and packaging material as the warranty will only be honored if product
is returned in complete original packaging.

FOR YOUR OWN SAFETY

General safety instructions:
For the safe use of this product, you need to have read and understood these instructions
-
before installing or using the product.
Please follow all safety instructions! If you ignore these safety instructions, you will endanger
-
yourself and others.
Keep these instructions for future reference.
-
All parts of this product have to be installed properly in order to ensure safe operation.
-
Modification of the product and use of non-approved parts are prohibited.
-
This product is not intended for use by persons (including children) with reduced physical,
-
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the product by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the product.
Electrical safety:
The electrical installation must be performed by a qualified electrician and must be in
-
accordance with national and local regulations.
Use a fault-current circuit breaker with a rated residual current of no more than 30 mA.
-
Make sure to install an all-pole disconnection switch having a contact separation of at least
-
3mm between poles in the supply wiring to the ceiling fan.
Before connecting the appliance to the electrical grid, make sure that it will only be operated
-
within the specified parameters.
The fan must be properly grounded to avoid the risk of electric shocks.
-
Switch off the power before connecting, repairing or cleaning the fan.
-
Install only bulbs of the type intended for your fan.
-
Storage and transport::
Always store the fan in a dry environment.
-
Protect the fan from damages during transport.
-
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FN433 series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for aireRyder FN433 series

  • Page 1 INSTRUCTIONS FOR INSTALLATION AND USE Ceiling Fan Model Classic (FN433XX) BEFORE YOU START Proper use: This product is intended exclusively for non-commercial use as ceiling fan. The product has to be installed and used in accordance with these instructions. Any use of this product that is not in accordance with these instructions will void the legal warranty of the manufacturer.
  • Page 2 Safety instructions specific to this fan: Attach the fan only directly to the ceiling structure. The carrying capacity of the ceiling structure from which the fan is hung must be at least 100kg. The minimum distance between the blades of the fan and the floor must be 2.3m. Never mount the fan outside or in a humid or wet environment.
  • Page 3 2. Hang the fan assembly with 3. Connect the internal lead the ball joint onto the mounting wire from the bracket to the fan 1. Pass the supply wires through the bracket. Make sure the guide body by clipping together the hole in the mounting bracket.
  • Page 4 INSTALLATION WITH REMOTE CONTROL (AVAILABLE AS OPTION) Start with steps 1-2 of the above fan installation illustration 3. Install the remote control 4. Connect the pair of 4-way (without remote control). receiver in the bracket as male/female connectors from the shown.
  • Page 5 Remote control (optional – not included with fan) Install two AAA batteries to the transmitter (batteries not included with transmitter). Press the "ON / OFF" button to turn the light on or off. For using the dimmer function, press and hold the "DIMMER" button to adjust the intensity of the light.
  • Page 6 MALFUNCTIONS – TROUBLE SHOOTING Risk of injury: Inappropriate repairs can lead to the fan not functioning safely. This can cause a hazard for yourself and your environment. Most malfunctions are caused by small errors which you can easily resolve by yourself. Please check the following table before contacting your retailer.
