INSTALLATION MANUAL
Universal Flat Dual Pole Arms*
A
Shilton, Coventry, England CV79JY
Phone: +44 (0) 2476 614700
UFA
E
U
R
O
P
E
Swallow House,
Shilton Industrial Estate,
Fax: +44 (0) 2476 614710
AUSTRALIA, NEW ZEALAND,
OCEANIA (DISTRIBUTOR)
P.O. Box 295
Mordialloc Victoria 3195
Australia
Phone: 03 9586 6330
www.premiermounts.com.au
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Premier Mounts UFA
Summary of Contents for Premier Mounts UFA
- Page 1 3130 East Miraloma Avenue Anaheim, CA 92806 USA USA and Canada – Phone: 800-368-9700 Fax: 800-832-4888 Other Locations – Phone: 001.714.632.7100; Fax: 001.714.632.1044 ©Premier Mounts 2007 9532-006-001-01 * Base and Poles not included. INSTALLATION MANUAL Universal Flat Dual Pole Arms* Swallow House,...
-
Page 2: Table Of Contents
TECHNICAL SPECIFICATIONS ... - 8 - WARNING: PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY... -
Page 3: Warranty
What and Who is Covered by this Limited Warranty and for How Long Premier Mounts warrants this product to be free from defects in material and workmanship for the lifetime of the original owner of this product. The limited warranty is only valid for the original purchaser of the product. -
Page 4: Installation Instructions
Mounting Hardware (Qty 8) M4 x 16 (Qty 8) M4 x 25 M5 x 12 (Qty 8) (Qty 8) M5 x 16 (Qty 8) M5 x 20 (Qty 8) M5 x 25 (Qty 8) M5 x 50 (Qty 8) M6 x 16 NOTE: The nylon spacers may be stacked to achieve proper spacing. -
Page 5: Thread Depth Indicator
Thread Depth Indicator Insert the thread depth indicator (supplied) through the thread inserts found on the back of the flat panel to make sure the inserts measure the same full depth and mark it (Figure 1). Locate the correct diameter screw for the thread insert. Compare your marking to the screws (supplied). If your selected screw is longer than the marking on the thread depth indicator, DO NOT USE this screw. -
Page 6: Support Tube Installation
NOTE: If the optional shelf has been purchased, the shelf must be attached prior to attaching the UFA bracket arms. Please refer to the shelf installation instructions. When working with the shelf, take precautions not to scratch it. -
Page 7: Installing The Display On The Support Tubes
PEOPLE. FAILURE TO DO SO WILL RESULT IN PHYSICAL DAMAGE TO THE DISPLAY AND/OR THE PERSONNEL PERFORMING THESE STEPS. 1. Two people, one on each side, must pick up the display. 2. Align the upper UFA mounting bracket above the two support tubes and lower the unit down. Set Screw 3. -
Page 8: Technical Specifications
AND ONE TO TIGHTEN/LOOSEN THE SET SCREWS. 5. To adjust the overall height of the unit loosen the set screws that are located on the upper and lower UFA arms. Tighten the set screws down when the adjustment is complete.
