Precor Handrail Option Kit
Fits Precor C944, C942, C940, M9.45, M9.41s Treadmills
Thank you for purchasing the Precor Handrail Option Kit. Each kit comes
complete with all the hardware required to install a handrail on one side of the
treadmill. If you wish handrails on both sides of the treadmill, you must order two
(2) option kits. When you receive the Handrail Option kit, check its contents with
the list below:
Note: If you purchase both handrails, check the contents of both kits with the list
below:
Handrail Option Kit Contents
One handrail
One upper end clamp
One upper center clamp
Three large bolts (two 5/16 - 18 x 2.5 and one 1/4 - 20 x 2.5)
One star washer
One nut plate
One lower clamp
One 5/32" hex key
One 3/16" hex key
Note: To assemble the handrail(s), you will need a Phillips head screwdriver.
ASSEMBLY INSTRUCTIONS
The assembly of each handrail is the same on opposite sides of the treadmill. To
properly install the handrail(s) on your unit, take the following steps:
CAUTION: Turn OFF the unit and unplug it from the power source before
installing the handrail(s).
I
A
L
P
R
O
D
U
C
T
S
D
I
V
I
S
I
O
N
Advertisement
Table of Contents
Related Manuals for Precor C940
Summary of Contents for Precor C940
- Page 1 Precor Handrail Option Kit Fits Precor C944, C942, C940, M9.45, M9.41s Treadmills Thank you for purchasing the Precor Handrail Option Kit. Each kit comes complete with all the hardware required to install a handrail on one side of the treadmill. If you wish handrails on both sides of the treadmill, you must order two (2) option kits.
- Page 2 Diagram 1 Installing the nut plate into the guide rail. End cap Bolt Finger guard Rear roller Side rail Guide rail Nut plate 1. To properly mount the lower handrail clamp, you need to install a nut plate into the guide rail. Remove the end cap from the rear of the treadmill using a Phillips head screwdriver.
- Page 3 4. Place the center clamp on the front portion of the handrail, followed by an end clamp. See Diagram 2. Align the two clamps with the handrail mounts on the upper frame. 5. Insert a bolt through each clamp. See Diagram 2. Using the supplied 3/16" hex key, screw each bolt through the handrail until the clamp is snug against the upright support.
- Page 4 Note: If you are installing both handrails, repeat assembly steps 1 through 6 to attach the handrail to the other side of the treadmill. Precor is a registered trademark of Precor Incorporated. “C” is a trademark of Precor Incorporated. ©1996 Precor Incorporated.
