- Page 1 KING COBRA/KING COBRA-2 NARROW STILE SERIES KC9232/KC9232-2 KC9233/KC9233-2 Keypad Programmable and SNAP Compatible Trim For Narrow Stile Doors 57041-D 04-11-2007...
-
Page 2: Contents Of The Box
KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Contents of the Box KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Contents of the Box 57041-D Page 2 04-11-2007... -
Page 3: Introduction / Tools And Materials Needed / Contact Info
Rite® instructions where applicable). An Audit Trail feature is available on the KC9232-2 and the KC9233-2 models. The KC9232/KC9232-2 (trim w/knob & MS Cam interface) is compatible with Adams Rite® MS1850, MS1850-050, MS1950, 4070 Deadbolts, 4710 Deadlatch locks and 8400 mortise exit devices. -
Page 4: Door Preparation
KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Door Preparation Door Preparation Door Conditions: Installation may require the use of a cover plate (a) to cover the holes left in the door. If the existing pull (b) must be removed, Ives offers a compatible pull. -
Page 5: Cams, Cores, Cylinders And Blocking Rings
Cams For Mechanical Override Cylinder: Cams, Cores, Cylinders and Blocking Rings The KC9000 trim requires the use of a clover leaf cam (a). This is a list of compatible Schlage parts. For other manufacturers, consult cross-reference charts. > Cam for Standard Mortise cylinder:... - Page 6 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 Installing the KC9232/KC9232-2 or KC9233/KC9233-2 Installing the KC9232/KC9232-2 or KC9233/KC9233-2 If your trim has a key cylinder already installed, skip to Position the Dead Latch’s Set Screw Hole: on page 10. Otherwise, continue with Loosen the Baseplate Screws: on this page .
- Page 7 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 3) Make Room for Key Cylinder: Due to the diameter of the key cylinder, it is necessary to have dead latch (a) placed out of the way when installing the key cylinder. Therefore...
- Page 8 • Screw in key cylinder until it stops. Use mechanical key as a han- • dle for turning if necessary. Table 1: Blocking Rings Key Cylinder Length Blocking Ring (Schlage P/N; XXX = finish) • 1-1/4” 1/8” (36-079-012-XXX) • 1-3/8”...
- Page 9 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 8) Alignment of Interchangeable Cores: If an IC Core is used, center the interface toward the • bottom. 9) Tighten the Four Screws in the Baseplate: Tighten the four baseplate screws in the fol- •...
- Page 10 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 11) Position the Dead Latch’s Set Screw Hole: Tilt the trim until you see the “critical • edge” align with the larger hole in the baseplate as shown in photo on right.
- Page 11 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 12) Partially Tighten the Set Screw: Using a 1/16” Allen wrench, partially turn • in the set screw until outer end of set screw is about flush with surface of base- plate.
- Page 12 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 14) What To Do With the Adams Rite Product: ® Retrofit Installation - Remove face plate (a). • Loosen key cylinder set screw (b). • Remove key cylinder (c). • Remove any Adams Rite® trim if present.
- Page 13 • NOTE: If optional blind nuts are used, see blind nut installation instructions (Schlage Lock Company form number: 57057) for correct hole size and mounting method. If you are installing a prep cover plate, continue with, Install the Interface Spacer: on page 13.
- Page 14 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 17) Install the Interface: Install interface (a) onto trim’s baseplate assembly • (b). 18) Secure the Interface: With cam (a) turned a little out of the way, secure • the interface with the supplied screw.
- Page 15 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 20) Apply the Exterior Gasket: Apply gasket to back of trim. • 21) Place Trim On Door: With key in cylinder, turn key counterclockwise until • it stops. Line up parts for proper engagement.
- Page 16 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 23) Remove Battery Cover: If not already done, insert key into cylinder and turn • it counterclockwise. Using a small, flat blade screwdriver, loosen the • battery cover screw (a) ONLY TWO TURNS COUNTERCLOCKWISE.
- Page 17 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 26) Fold Battery Bag: Fold battery bag over. • IMPORTANT: The battery bag is used to protect the batter- ies from moisture and to insulate them electrically from metallic parts. 27) Install Battery Pack: Install battery pack into compartment with bag open- •...
- Page 18 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Installing the KC9232/KC9232-2 or KC9233/KC9233-2 29) Tighten Latch Mechanism Set Screws: Tighten set screw in Adams Rite® latch mechanism. • Verify that the other set screw in latch mechanism • (closest to inside of door) is fully tightened.
- Page 19 KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Testing the KC9232/KC9232-2 or KC9233/KC9233-2 Testing: Testing the KC9232/KC9232-2 or KC9233/KC9233-2 1. Knob should rotate freely. 2. Insert key into cylinder and rotate knob in direction required to retract latch. > Direction of knob rotation depends on door hand - if it doesn’t work in one direction, try the other.
-
Page 20: Operational Recommendations / Dimensions
KC9232/KC9232-2 & KC9233/KC9233-2 INSTALLATION Operational Recommendations / Dimensions Operational Recommendations: Operational Recommendations / Dimensions The models with a knob operate the deadbolt much like a key, therefore more time to operate the dead- bolt/latch might be desired. See programming guide to change the relock time delay to a longer time.
