Page 1 CU900ENT FITNESS BIKE OWNER’S MANUAL...
Page 2 Spirit Fitness...
Page 3: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS IMPORTANT ELECTRICAL INSTRUCTIONS IMPORTANT OPERATION INSTRUCTIONS PRODUCT REGISTRATION CU900ENT ASSEMBLY INSTRUCTIONS CONSOLE OPERATION TOUCH SCREEN OPERATION PROGRAMMING THE CONSOLE GENERAL MAINTENANCE MANUFACTURER’S LIMITED WARRANTY Thank you for purchasing our product, please save these instructions. Please do not perform or attempt any customizing, adjustments, repair or maintenance that is not described in this manual.
Page 4 Congratulations on your new tness bike and welcome to the Spirit Fitness family! Thank you for your purchase of this quality tness bike from Spirit Fitness. Your new tness bike was manufactured by one of the leading tness manufacturers in the world and is backed by one of the most comprehensive warranties available.
Page 5: Important Safety Instructions
40 to 120 degrees Fahrenheit, and humidity is 95% non-condensing (no water drops forming on surfaces). • Wear proper shoes. High heels, dress shoes, sandals or bare feet are not suitable for use on your tness bike. Quality athletic shoes are recommended www.spirit tness.com...
Page 6: Important Operation Instructions
SERIAL NUMBER: REGISTER YOUR PURCHASE The self-addressed product registration card must be completed in full and returned to Spirit Fitness. You can also go to www.spirit tness.com/commercialwarrantyregistration.html under the Support tab to register online. Spirit Fitness...
Page 7 CU900ENT PRE-ASSEMBLY UNPACKING TOOLS INCLUDED: 1. Cut the straps, then along the dotted line on the bottom of the box; lift the box over ‰ 13/15mm Wrench ‰ Phillips Screwdriver the unit and unpack. ‰ 5mm Allen Wrench 2. Locate the hardware package. The hardware is separated into four steps. Remove ‰...
Page 8 CU900ENT CU900ENT CU900ENT STEP ONE HARDWARE FOR STEP 1 PART TYPE DESCRIPTION BOLT M8XP1.25X20L FLAT WASHER 8.5X18X1.5T M5XP0.8X12L SCREW FLAT WASHER 13X23X2.0T BOLT M10X55L 1. Install REAR STABILIZER (4) to MAIN FRAME (1) with 3 BOLTS (61) and 3 WASHERS (60).
Page 9 CU900ENT CU900ENT CU900ENT STEP TWO HARDWARE FOR STEP 2 PART TYPE DESCRIPTION M8XP1.25X20L BOLT FLAT WASHER 8.5X18X1.5T SCREW M5XP0.8X12L 1. Run the WIRING HARNESS through the CONSOLE MAST (2) and out the top. 2. Install CONSOLE MAST (2) to MAIN FRAME (1) with 6 BOLTS (52) and 6 WASHERS (112).
Page 10 CU900ENT CU900ENT CU900ENT STEP THREE HARDWARE FOR STEP 3 PART TYPE DESCRIPTION 8.5x18x1.5T FLAT WASHER BOLT M8xP1.25x65L LOCK WASHER 8x1.5T NYLOCK NUT M8xP1.25x7T SCREW M5xP0.8x6L 1. Install HANDLEBARS (3) to CONSOLE MAST (2) with 4 BOLTS (56), 4 LOCK WASHERS (57), 8 WASHERS (53), and 4 NUTS (58).
Page 11 CU900ENT CU900ENT CU900ENT STEP FOUR HARDWARE FOR STEP 4 PART TYPE DESCRIPTION M5xP0.8x12L SCREW SELF-TAPPING SCREW 3.5x12L 1. Attach CUP HOLDER (36) to CONSOLE MAST (2) using 2 SCREWS (54). 2. Attach CONSOLE MAST COVERS (37 & 38) over CONSOLE MAST (2) using 4 SELF-TAPPING SCREWS (55).
Page 12: Console Operation
CU900ENT CONSOLE OPERATION Spirit Fitness...
Page 13 tness.com...
Page 14 Plug in the power cord located at the front base of the unit. When the power is turned on, the screen will show the initial image and then enter the Home screen. Home screen: Begin operation by touching the icons. Quick operating buttons are convenient for basic bike functions. Spirit Fitness...
Page 15 The two most commonly used menus for setting up the exercise machine are described below; the TV Setup and Maintenance menus. For information on other sections of the Maintenance suite refer to the technical service manual or call Spirit service. www.spirit tness.com...
Page 16 OSD Enter. The tuner will now scan for all available channels. Press OSD Exit when done. You can modify the channels by pressing the Update Channel List. 4. The OSD Command button is for engineering use only. Spirit Fitness...
Page 17 Machine Setup allows you to select whether the Csafe port is • used for Csafe or CAB TV Tuner. This menu also allows you to set the screen brightness. • FTP Settings is the Spirit FTP site address where Error logs and remote troubleshooting can be managed. www.spirit tness.com...
Page 18 You could also just use a default-look button and type in the name of the site, which will then be the button icon. Spirit Fitness...
Page 19 Turn Wi on and press scan for available Wi connections. Press desired connection and follow the on-screen directions. ETHERNET SETUP Press Ethernet Con guration to set Select DHCP to search for connection up a new connection. or Static IP to enter manually www.spirit tness.com...
Page 20 4. The A2DP console and phone will ask you to con rm pairing, press OK. 5. Pairing complete 6. Open audio APP on phone and the audio will be played through the headphone port on the ENT console. Spirit Fitness...
Page 21: Touch Screen Operation
When you press the Language button on Home screen, it enters the menu with all language options. There are 12 languages to choose from. Touch the desired language and the system will return to the Home screen which will now be in the chosen language. www.spirit tness.com...
Page 22 Volume Up/Down buttons to change the sound levels. If you want to silence the audio touch Mute button. Touch the Max Screen to switch to full screen viewing. Touching anywhere on the screen will return it to the original screen size. Spirit Fitness...
Page 23: Exercise Programs
There are 12 programs to choose from. Press the desired program button and follow the on-screen directions. For Manual Program as an example, just touch Manual button on the screen to enter the programming for Manual. www.spirit tness.com...
Page 24: Quick Start
Levels 10-20 are more challenging but the increases from one level to the next remain small. Levels 20-30 start getting tough as the levels jump more dramatically. Levels 30-40 are extremely hard and are good for short interval peaks and elite athletic training. Spirit Fitness...
Page 25 A muscle pro le displays active muscle groups as workloads change. TRACK gives a graphical representation of your Track display position on a virtual track. The image shows the track with a lap counter and other values. www.spirit tness.com...
Page 26 There is only a tiny amount of current used in sleep mode (about the same as your TV when it is turned off) and it is perfectly ne to leave the main power switch on in sleep mode. Spirit Fitness...
Page 27: Programming The Console
This is because every person is different and burns calories at a different rate. Some good news is that you will continue to burn calories at an accelerated rate for at least an hour after you have nished exercising! www.spirit tness.com...
Page 28 Message Window. If you start a program without changing the settings, the default, or pre-saved settings will be used. The Spirit Fitness CU900ENT offers ten preset programs: Manual, Hills, Fat Burn, Cardio, Strength, Interval, HR, Custom, Fitness Test, and Constant Power.
Page 29: Fat Burn
(default or user input level). It has slight uctuations up and down to allow your heart rate to elevate, and then recover repeatedly, before beginning a quick cool down. This will build up your heart muscle and increase blood ow and lung capacity. www.spirit tness.com...
Page 30 The default value is 65% of your projected rate maximum. You have the option of changing your target heart rate. The machine will attempt to keep you within ve beats of your target heart rate. Spirit Fitness...
Page 31 35 or persons with pre-existing health conditions. Make sure you have warmed up and stretched before taking the test. • Do not take in caffeine before the test. • Hold the hand grips gently, do not tense up. • www.spirit tness.com...
Page 32 4. Time is the total elapsed time of the test. After The Test: Cool down for about one to three minutes. ƒ Take note of your score because the console will automatically return to the start-up mode after a few minutes. ƒ Spirit Fitness...
Page 33 What Your Score Means: VO2MAX CHART FOR MALES AND VERY FIT FEMALES VO2MAX CHART FOR FEMALES AND DECONDITIONED MALES www.spirit tness.com...
Page 34: General Maintenance
2. The crank arm nut needs to be retightened. If squeaks or other noises persist, check that the unit is properly leveled. There are 2 leveling pads on the bottom of the rear stabilizer, use a 14mm wrench (or adjustable wrench) to adjust the levelers. Spirit Fitness...
Page 35: Manufacturer's Limited Warranty
EFFECTIVE JANUARY 1, 2017 Spirit Fitness warrants this tness bike for a period of time listed below from the date of sale, as determined by sale receipt, or in the absence of a sales receipt eighteen (18) months from the original factory shipping date. Spirit Fitness’...
Page 36 5. Products that have been: sold, transferred, bartered, or given to a third party. 6. Products that do not have a warranty registration card on le at Spirit Fitness. Spirit Fitness reserves the right to request proof of purchase if no warranty record exists for the product.
Page 37 Jonesboro, AR 72402-2037 Product features or speci cations as described or illustrated are subject to change without notice. All warranties are made by Spirit Manufacturing, Inc. This warranty applies only in the 48 contiguous United States. NOTE: This does not apply to Alaska or Hawaii.
Page 38 NOTES Spirit Fitness...
Page 39 NOTES www.spirit tness.com...
