- Page 1 SG 4E - SG 45E SG 5E - SD 5E SD 5E BT Instructions for use and maintenance Ed. 03/2006...
- Page 2 DECLARATION OF CONFORMITY The following Blue Seal Units 6&7 Mount Street - Business Park Mount Street Nechelles,Birmingham B7 5QU hereby declares under full responsability that the following product DISHWASHING MACHINE (product description) SG 4 E - SG 45 E - SG 5 E - SD 5 E - SD 5 E BT ......
- Page 3 DISHWASHING MACHINE Mod. SG 4E - SG 45E SG 5E - SD 5E SD 5E BT ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○...
- Page 4 Become thoroughly familiar with the contents of thi manual before installing, setting up, adjusting and servicing diswasher machine Mod. SG 4E - SG 45 E - SG 5E - SD 5E - SD 5 E BT Only contact an authorized technical center or BLUE SEAL in the event of breakdowns or faulty machine operation.
- Page 5 OVERALL DIMENSIONS CHECK CYCLE START Model SG 4E 460 521 680 851 SG 45E 530 600 755 940 SG 5E - SD 5E 600 600 820 1005 330 SD 5E BT 600 620 820 1030 330...
- Page 6 TECHNICAL DATA SG 4E 60/30/20 230V ~ 50Hz 2620 W 2400 W 2000 W 220 W SG 45E 60/30/20 230V ~ 50Hz 4550 W 4000 W 2000 W 550 W SG 5E-SD 5E 60/30/20 230V ~ 50Hz 4750 W 4000 W...
-
Page 7: Control Panel
CONTROL PANEL CHECK CYCLE START LC1 LC2 LRCK LTV Fig. 1 LEGEND Line button ON/OFF Regeneration button ( only for models with "D") LRCK) CHECK led light (blue) LTV) Tank temperature led light (red) LC1) SHORT cycle led light (blue) LC2) MEDIUM cycle led light (blue) LC1+LC2) - Page 8 ENGLISH Part 1: General description and safety device Part 2: For the Operator Part 3: For Authorized and Qualified Technicians ENGLISH...
- Page 9 ENGLISH Never use the hands instead of adequate tools when operating PARTICULAR RECOMMENDATIONS the machine. FOR THE OPERATOR Never use the hands or other objects to stop moving parts. Do not operate the machine without having become fully familiar with the contents of this manual and without having PAY THE UTMOST ATTENTION TO THE DATA PLATES acquired a comprehensive knowledge of the specific AFFIXED TO THE MACHINE WHENEVER WORKING ON...
- Page 10 DEVICES The machine must be sheltered from the weather when shipped and stored. • Models BLUE SEAL are equipped with a safety 1.4 INSPECTIONS ON ARRIVAL microswitch that blocks the washing pump if the tub access door is accidentally opened.
- Page 11 Part 2: For the operator ENGLISH 2.1.c STARTING THE WASHING CYCLE WASHING PHASES To start the washing cycle, press and hold the START (ST) button for a few seconds, then release. Throughout the washing cycle the LED(s) for the selected cycle (LC1 LC2 or LC1...
- Page 12 ENGLISH Part 2: For the operator Manual draining for machines with drainage pump If there are traces of waste, ensure that: - The filters (22) (23) are clean; For machines fitted with a drainage pump it is possible - the water temperature is around 60°C; to empty the tank by carrying out the manual draining - items are correctly positioned in the basket;...
- Page 13 2. Wash the washing and rinsing arm. from BLUE SEAL which is the sole proprietor and If the nozzles (27) are clogged, unscrew them to which reserves the right to make any modifications as...
- Page 14 ENGLISH Part 2: For the operator SUMMARY TABLE of CYCLE LED CHECK SIGNALS MACHINE STATUS CYCLE LED CHECK CYCLE: washing, pause, rinsing ON CONSTANT ALARM: lack of heating RAPID flashing ALARM: door open RAPID flashing Manual drain ON CONSTANT Regeneration cycle SLOW flashing Machine off/standby *REGENERATION ALARM...
- Page 15 ENGLISH Part 3: For the technician IMPORTANT by failure to comply with the above listed provisions. • Connect the electrical power cable (14) to the main Every operation of installation, electrical or hydraulic switch installed prior to the machine. connection, programming, maintanance etc...has to be •...
- Page 19 WHITE BROWN GREY BROWN BLACK GREY FA15 GREY FA14 BROWN FA13 FA12 DARK BLUE FA11 ORANGE FA10 BLACK WHITE/BLACK ORANGE JELLOW/GREEN...
- Page 20 WHITE WHITE RED/BLACK WHITE BLACK BROWN GREY GREY FA15 FA14 BROWN FA13 FA12 DARK BLUE FA11 ORANGE BLACK FA10 PINK WHITE/BLACK ORANGE GREY BROWN BLACK BLACK BLACK GREY GREY BLACK BLACK DARK BLUE JELLOW/GREEN...
- Page 21 BROWN BLUE BLACK WHITE BLUE PINK BLACK BLUE BROWN BLACK BROWN PINK BLACK BLUE BLUE PINK FA15 VIOLET FA14 BROWN FA13 FA12 FA11 WHITE/RED BLUE FA10 GREY BLACK VIOLET PINK WHITE/BLACK ORANGE BLACK GREY BROWN BLACK BLACK GREY BLACK BLACK GREY BLUE JELLOW/GREEN...
- Page 22 Fig. 2 Fig. 3 BLUE SEAL LTD BIRMINGHAM 0121-3275575 Type: ......... Volt ....hz N°: ........Ph ..... Amp Weight: .......... kW Date: ......CE product Fig. 5 Fig. 4 LIFT LIFT Fig. 6 Fig. 7...
- Page 23 Fig. 8 CHECK CYCLE START LC1 LC2 LRCK LTV Fig. 9 SG 5E - SD 5E SG 4E SD 5E BT Fig. 10...
