PQI Network Device 019 Specifications

Hi-Speed DOM
The Leading Industrial Storage Solution
Hi-Speed DOM 019 40Pin IDE
Hi-Speed DOM 419 44Pin IDE
Features
Compatible with IDE interface
●
No seek error & no noise
●
Low power consumption
●
No latency delay
●
Shock resistant & anti-vibration
●
POWER QUOTIENT INTERNATIONAL CO., LTD.
Customer Hotline:+886 0800200186
PQI and PQI logo are registered trademarks of Power Quotient International Co., Ltd. All other trademarks and logos are the property of their respective owners. The appearance and specifications of all products are subject to change without notice.
Hi-Speed DOM 030 40Pin IDE
Hi-Speed DOM 432 44Pin IDE
Web: www.pqi.com.tw
Model 019
40Pin IDE
Connector
Orientation Vertical
Height 27.2 mm
Width 59.2 mm
Thickness 6.2 mm
Housing Yes
Capacity 32MB~6GB
Sector Size
Interface Data
Transfer Rate
Sustained Data
Transfer Rate
DC Input
Requirement
Power
Read : 15mA, Write : 20mA, Suspend : 3mA
Consumption
Operating
Environment Relative Humidity : 8% ~ 95% Non-Condensing
Reliability
Operating Shock : 1,000G, Vibration : 15G
Endurance
RoHS Compliant with RoHS Directives
Hi-Speed DOM Ordering Information
Model P/N
019 DJ0032M
*
030 DE0032M
*
419 DQ0032M
432 DH0032M
*
*1：032M=32M,064M=64M, 128M=128M, 256M=256M, 512M=512M, 010G=1G, 015G=1.5G, 020G=2G
040G=4G, 060G=6G, 080G=8G
*2：Connector Direction :
0=Normal, 1=LFD, 2=LDF, 3=LMD, 4=LDM, 5=LMF, 6=LFM
Sales: sales@pqi.com.tw
030 419
40Pin IDE 44Pin IDE
Horizontal Vertical
30.4 mm 27.5 mm
55.0 mm 50.2 mm
Depends on 6.5 mm
connector type
No Yes
32MB~8GB 32MB~4GB
512 Bytes
PIO mode 4 ~ 16.6MB/Sec
Multiword DMA Mode 2
Read : 6.7MB/Sec
Write : 5.4MB/Sec
+ -
Standard : +5V 10%
+ -
Optional : +3.3V 5%
Temperature : 0 ~ 70 C
o o
MTBF 1,000,000 Hours
Remarks
22RX0 Up to 6GB
*
1 2
22RX1
1 * 2
Up to 4GB
22RX0
* *
1 2
22RX1 Up to 6GB
*
1 2
432
44Pin IDE
Horizontal
32.6 mm
48.0 mm
Depends on
connector type
No
32MB~6GB
RoHS
