Summary of Contents for PQI Traveling Disk U260
- Page 1 USB Flash Drive Traveling Disk U260 BB64 Series Rev. A.0 Sep 2006...
- Page 2 USB Flash Drive Table of Contents 1. Introduction to Cool Drive ……...……... 1 2. Main Features Overview …………..………...……...……………………………..…… 1 3. Hardware Specification ………………………………………..….………….……………………… 1 ……………………………………………………...……………………………… 1 3.1 USB Interface …………………………………..………...……...………………………. 1 3.2 NAND Flash Interface ……………………………………………………………...………………………… 1 3.3 OS Support ………………………………………………..…..…...……………………….
-
Page 3: Usb Flash Drive
“PQI reserves the right to make changes without notification when fit, form, function, quality and reliability are not affected. The data sheets do not constitute contract documents and should not be considered part of the specification for purposes of any warranty.”... - Page 4 USB Flash Drive 1. Introduction to U260 The U260 gives you portability and security to offer you a peace of mind. Compatible with USB 2.0 / 1.1 specifications with low power consumption and data protection. 2. Main Features Overview ♦ Mobile USB flash drive, USB 2.0 compatible ♦...
- Page 5 USB Flash Drive 4. Block Diagram 8051 Micro Controller Data / Address USB2.0 USB 2.0 USB1.1 USB2.0 or Interface 1.1 Port Host PLL, REG 5. Absolute Maximum Ratings Symbol Tstorage Storage Temperature Ambient Operating Temperature Vcc3 3.3V Supply Voltage Vcc18 1.8V Supply Voltage Vin3.3 3.3V Buffer Input Voltage...
-
Page 6: Recommended Operating Conditions
USB Flash Drive 6. DC Characteristics Symbol Parameter Supply voltage for VCC3 or VCC3A Regulator output voltage for VCC or DD18 VCCA Input Low Voltage Input High Voltage Output Low Voltage (IOL=4mA) Output High Voltage (IOH=4mA) Input pin capacitance Supply current Suspend current (D+1.5KΩ) 7. - Page 7 USB Flash Drive 9. Physical Specifications 9.1 Dimensions: 9.1.1 Height: 57.00mm 9.1.2 Width: 17.80mm 9.1.3 Depth: 10.15mm 9.1.4 Weight: 8g ± 1g 9.2 Outline of top view Rev. A.0 Sep 2006...
