USB Flash Drive
Traveling Disk i161
BK07 Series
Rev. A.0
April 2008

Advertisement

Table of Contents
loading

  Related Manuals for PQI Traveling Disk i161

  Summary of Contents for PQI Traveling Disk i161

  • Page 1 USB Flash Drive Traveling Disk i161 BK07 Series Rev. A.0 April 2008...
  • Page 2: Table Of Contents

    USB Flash Drive Table of Contents 1. Introduction to Traveling Disk ………... 1 2. Main Features Overview …………..………...……...……………………………..…… 1 3. Hardware Specification ………………………………………..….………….……………………… 1 ………………………………….…………………...……………………………… 1 3.1 USB Interface ……………………………………..…………...………………………. 1 3.2 NAND Flash Interface ………………………………………………….…………...………………………… 1 3.3 OS Support ………………………………………………..…………...……………………….
  • Page 3: Usb Flash Drive

    “PQI reserves the right to make changes without notification when fit, form, function, quality and reliability are not affected. The data sheets do not constitute contract documents and should not be considered part of the specification for purposes of any warranty.”...
  • Page 4: Introduction To Traveling Disk

    USB Flash Drive 1. Introduction to i161 The i161 gives you portability and security to offer you a peace of mind. Compatible with USB 2.0 / 1.1 specifications with low power consumption and data protection. 2. Main Features Overview ♦ Mobile USB flash drive, USB 2.0 compatible ♦...
  • Page 5: Block Diagram

    USB Flash Drive 4. Block Diagram 8051 Micro Controller Data / Address USB2.0 USB 2.0 USB1.1 USB2.0 or Interface 1.1 Port Host PLL, REG 5. Absolute Maximum Ratings Symbol Tstorage Storage Temperature Ambient Operating Temperature Vcc3 3.3V Supply Voltage Vcc18 1.8V Supply Voltage Vin3.3 3.3V Buffer Input Voltage...
  • Page 6: Dc Characteristics

    USB Flash Drive 6. DC Characteristics Symbol Parameter Supply voltage for VCC3 or VCC3A Regulator output voltage for VCC or DD18 VCCA Input Low Voltage Input High Voltage Output Low Voltage (IOL=4mA) Output High Voltage (IOH=4mA) Input pin capacitance Supply current Suspend current (D+1.5KΩ) 7.
  • Page 7: Physical Specifications

    USB Flash Drive 9. Physical Specifications 9.1 Dimensions: 9.1.1 Height: 40.49 mm±0.1mm 9.1.2 Width: 17.70 mm±0.1mm 9.1.3 Depth: 6.10 mm±0.1mm 9.1.4 Weight: 8.5mm± 0.5g 9.2 Outline of top view Rev. A.0 April 2008...
