- Page 1 Intelligent Stick™ Intelligent Stick 2.0 Plus BD03 Series Rev. A.0 Sep 2006...
-
Page 2: Table Of Contents
Intelligent Stick™ Table of Contents 1. Introduction to Intelligent Stick 2. Main Features Overview ………..………...……...…...……………………………...… 1 3. Hardware Specification ………………………………………….………….……………………..… 1 ………………………….…..…………………..…...……………...……………… 1 3.1 USB Interface …………………………………………….……...……..…...………………. 1 3.2 NAND Flash Interface ………………………………………………...……...………..…...……………… 1 3.3 OS Support ……………………………………………………...…...………...……………. 1 3.4 Product Capacity 4. -
Page 3: Revision History
“PQI reserves the right to make changes without notification when fit, form, function, quality and reliability are not affected. The data sheets do not constitute contract documents and should not be considered part of the specification for purposes of any warranty.”... -
Page 4: Tm 2.0 Plus
Introduction to Intelligent Stick The Intelligent Stick Pro 2.0 Plus is a PQI patented technology. It combines characteristics of a flash card and a USB flash drive. It does not need a card reader to read from or write to thus making it the perfect storage medium for all types of digital devices. -
Page 5: Block Diagram
Intelligent Stick™ 4. Block Diagram 8051 Micro Controller Data / Address USB2.0 USB 2.0 USB1.1 USB2.0 or 1.1 Port Interface Host PLL, REG 5. Absolute Maximum Ratings Symbol Tstorage Storage Temperature Ambient Operating Temperature Vcc3 3.3V Supply Voltage Vcc18 1.8V Supply Voltage Vin3.3 3.3V Buffer Input Voltage Vin3/5... -
Page 6: Dc Characteristics
Intelligent Stick™ 6. DC Characteristics Symbol Parameter Power Supply Input Voltage Input Voltage Output Voltage Output Voltage Input leakage current Working Current IO output current IO output current Input Voltage 7. Recommended Operating Conditions Symbol Parameter Power Supply Voltage Input Voltage Internal Power Support 8. -
Page 7: Physical Specifications
Intelligent Stick™ 9. Physical Specifications 9.1 Dimensions: 9.1.1 Height: 43mm 9.1.2 Width: 18mm 9.1.3 Depth: 2.8mm 9.1.4 Weight: 2.7g ± 0.5g 9.2 Outline of top view Rev. A.0 Sep 2006...
