POWERMAX

Fully Supervised Wireless Alarm Control System

TABLE OF CONTENTS

1. INTRODUCTION .......................................................... 2

2. SPECIFICATIONS ..................................................... 2

2. 1 General Data .......................................................2

2. 2 RF Section...........................................................2

2. 3 Electrical Data .....................................................2

2. 4 Communication ...................................................3

2. 5 Physical Properties .............................................3

3. INSTALLATION .......................................................... 3

3. 1 Unpacking the Equipment ...................................3

3. 2 Supplying Power to the Unit ................................3

3. 3 Programming.......................................................4

3. 4 Mounting the Bracket ..........................................4

3. 5 Wiring ..................................................................5

3. 6 Attaching the Control Panel to the Bracket .........6

3. 7 Connecting the AC Transformer..........................6

3. 8 PowerMax-Compatible Detectors........................7

3. 9 PowerMax-Compatible Transmitters ...................7

3. 10 Mounting the RS232 Module.............................8

3. 11 Installing an Optional X-10 Siren.......................8

The PowerMax control panel is supplied with 3 instruction manuals:

" Installation Instructions (this manual - for your exclusive use)

" Programming Guide (for your exclusive use)

" User's Guide (for your use during installation only. Must be handed over to the master user after testing the system).

Appendices A and B to the installation instructions will help you prepare an installation plan. Please take time to fill out

the forms - your job will become much easier and confusion will be prevented. Filling out the forms will also help you

create a list of detectors and transmitters that must be obtained for the particular application. Compatible detectors and

transmitters are listed and described briefly in Paragraphs 3.8 and 3.9 of this manual.

Remember - it is advisable to power up the control panel temporarily after unpacking and program it on the work bench,

in accordance with the installation plan. Paragraph 3.3 of this manual refers you to the programming guide.

The programming flow charts in the programming guide show all options available for each parameter. Factory defaults

are marked with a dark box to their right, and other options (that can be selected instead) are marked by clear boxes.

This method allows you to put a checkmark in the appropriate clear box whenever you deviate from the factory defaults.

To increase the backup time provided by the Ni-Cd battery (which is 4 -6 hours), we recommend the use of 6 size AA

Ni-Mh cells with a capacity of 1600 mAh (produced by GP). Under AC failure conditions, these batteries provide up to

20-hour backup with no alarms, and up to 16 hours if an alarm occurs (not to be used in UL-listed systems).

Although setting the correct time and date is one of the user tasks, we recommend that you set the time and date in the

course of programming. Access to the "User Settings" is possible through item 9 on the installer's menu (see User's

manual for exact procedure).

When you are through programming, proceed to install the system as detailed in the Installation Instructions, from

paragraph 3.4 onward.

WARNING! The PowerMax control unit has not been investigated by UL for household fire.

WARNING! All model PowerMax outputs are not power limited and shall not be used in UL-listed Systems.

WARNING! Zone type "emergency" can not be used for medical applications in UL-listed systems.

The installer should verify line seizure. Be aware of other phone line services such as DSL.

DE5450

4. TESTING PROCEDURES .......................................... 8

5. MAINTENANCE .......................................................... 9

APPENDIX A. DETECTOR DEPLOYMENT AND

APPENDIX B. X-10 UNIT ASSIGNMENTS ................... 12

FCC STATEMENTS ....................................................... 13

DECLARATION OF CONFORMITY............................... 14

MESSAGE TO THE INSTALLER

Installation Instructions

4. 1 Preparations ....................................................... 8

4. 2 Diagnostic Test................................................... 8

4. 3 Keyfob Transmitter Test ..................................... 8

4. 4 Appliance ON/OFF Test ..................................... 9

4. 5 Emergency Transmitter Test .............................. 9

5. 1 Dismounting the Control panel ........................... 9

5. 2 Replacing the Backup Battery ............................ 9

5. 3 Fuse Replacement ........................................... 10

TRANSMITTER ASSIGNMENTS ............................. 11

A. 1 Detector Deployment Plan ............................... 11

A. 2 Keyfob Transmitter List .................................... 11

A. 3 Emergency Transmitter List ............................. 12

A. 4 Non-Alarm Transmitter List .............................. 12

Table of Contents

Need help?

Do you have a question about the DE5450 and is the answer not in the manual?

Questions and answers

Summary of Contents for PowerMax DE5450

Page 1: Table Of Contents
WARNING! The PowerMax control unit has not been investigated by UL for household fire. WARNING! All model PowerMax outputs are not power limited and shall not be used in UL-listed Systems. WARNING! Zone type "emergency" can not be used for medical applications in UL-listed systems.
Page 2: Introduction
• Unequivocal visual prompts and audible signals. • The installer can gain access to the user menu. A fully equipped alarm system based on the PowerMax consists of the units shown in Figure 2 of the user’s guide. Compliance with U.S. Standards: UL1023: household burglar alarm system unit - Grade A Meets FCC Part 15 and Part 68 requirements.
Page 3: Communication
Connect a twisted pair between the transformer’s 9 VAC screw terminals and the 9 VAC POWER terminals (located in the rectangular opening at the back of the PowerMax cabinet - see Figure 10). Note: If the transformer does not have screw terminals, connect the transformer’s integral twisted pair across the...
Page 4: Programming
Guide (Publication DE5450P). 3.4 Mounting the Bracket A. Detaching the Bracket from the Cabinet A notable advantage of the PowerMax is that the unit can be mounted without having to open its cabinet. All connectors and terminals are accessible through a rectangular opening at the rear, and wiring channels are provided across the rear of the cabinet.
Page 5: Wiring
Be sure to insert the special plastic washer into the ring, as shown in Figure 8. 3.5 Wiring All terminals and connectors are accessible within the opening at the back of the PowerMax (see Figure 9). All screw terminal appropriately and plugged back in.
Page 6: Cabinet-To-Bracket Attachment
Each detector compatible with the PowerMax system is packed with its own installation instructions. Read them carefully and install as indicated. A. PIR Motion Detectors The wireless passive infrared (PIR) motion detectors used in the system are of the PowerCode type. The PowerMax B. CLOSED DE5450...
Page 7: Powermax-Compatible Transmitters
Note: Each transmitter is packed with its own instructions for battery installation and use. Be sure to pass these documents on to the “Master User“ of the alarm system. The PowerMax system is compatible with multi-button and DE5450 PowerCode and CodeSecure coding methods.
Page 8: Installing An Optional X-10 Siren
E. Prepare an RS-232 flat modular cable and terminate it with a 6-position RJ-11 plug at the PowerMax end. Terminations at the computer’s end may vary. F. Mate the plug with the RJ-11 socket and bend the cable backward to route it out via the wiring channel.
Page 9: Appliance On/Off Test
Figure 29. Unlocking the Bracket E. Insert the bracket release key, supplied with the PowerMax kit, as far as it will go into the hole at the bottom of the unit (see Figure 30). This action frees the catch from the trap.
Page 10: Replacing The Backup Battery
Clear it by arming the system and immediately disarming. 5.3 Fuse Replacement The PowerMax has two fuses which can burn out: " Battery Fuse - 1A, time delay type, UL recognized (exists in U.S. variants only).
Page 11: Appendix A. Detector Deployment And Transmitter Assignments
Status or Arming “instant” Indicate the desired function (if any) - see Para. 5.16 in the programming guide. System status Arming “instant” ! DE5450 Chime (Yes / No) AUX button Assignments PGM Control Indicate whether Mark the boxes of the X-10 units to...
Page 12: A3. Emergency Transmitter List
Transmitter Type Enrolled to Zone APPENDIX B. X-10 Unit Assignments Unit Controlled Appliance by Arming by Memory Name of holder Name of holder by Delay by Keyfob Assignment ON by Timer ON by Zone No. ON Time OFF Time DE5450...
Page 13: Fcc Statements
When programming or making test calls to an emergency number, briefly explain to the dispatcher the reason for the call. Perform such activities in the off-peak hours; such as early morning or late evening. DE5450 FCC PART 15 STATEMENT FCC PART 68 STATEMENT...
Page 14: Declaration Of Conformity
DE5450...
Page 15 NOTES: DE5450...
Page 16 INTERNET VISONIC LTD. 2002 POWERMAX DE5450- (REV. 4, 04/02) The Manufacturer does not represent that its Product may not be compromised and/or circumvented, or that the Product will prevent any death, personal and/or bodily injury and/or damage to property resulting from burglary, robbery, fire or otherwise, or that the Product will in all cases provide adequate warning or protection.
