About the Dell Storage enclosure
This chapter describes the storage enclosure concepts, which help in configuring and operating the Dell
storage enclosures. The secli uses a number of terms to describe objects on which the software performs
actions.
NOTE: For detailed descriptions about the enclosure features, see the Owner's Manual for the
specific enclosure.
Dell PowerVault MD3060e
Front panel features and indicators
Figure 1. Front-panel features
1.
drawers (5)
3.
physical disk slot numbering
5.
front-panel indicators
8
2.
drawer release latches (2 per drawer)
4.
drawer indicator LEDs
2
