Manual de Instrucciones
NOT DESIGNED FOR USE WITH
ELECTRIC POWERHEADS
NO ESTA DISEÑADO PARA EL USO CON
CABEZAS DE MOTOR ELÉCTRICO
NON CONÇU POUR L'USAGE AVEC
BLOC ---MOTEURS ÉLECTRIQUES
DANGER:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
PELIGRO:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
DANGER:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2003 Electrolux Home Products, Inc.
Instruction Manual
Manuel d'Instructions
PPB4000C
530164694
R
12/8/03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 530164694 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Poulan Pro 530164694

Summary of Contents for Poulan Pro 530164694

  • Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2003 Electrolux Home Products, Inc. PPB4000C 530164694 12/8/03...

  • Page 2: Identification Of Symbols

    Thrown Protection objects Guards Boots WARNING: Hazard zone for thrown objects. Blade/trimmer line can throw objects vi- olently. Others can be blinded or injured. Keep people and animals 50 feet (15 meters) away. Hazard Zone 50 Feet (15 Meters) WARNING: Do not use trimmer head as a fastening device for the blade.
  • Page 3 S Keep others away when making carburetor adjustments. S Use only recommended Poulan PRO! ac- cessories and replacement parts. S Have all maintenance and service not ex- plained in this manual performed by an au- thorized service dealer.

  • Page 4: Special Notice

    S Large nut for installing blade S Retaining washer S Cupped washer S Metal shield (assembled on brushcutter at- tachment) S Trimmer head S Plastic shield S Wing nut (screwed onto plastic shield) S Attachment hanger S Hex wrench WARNING:...
  • Page 5 HANDLEBAR CLAMP BASE Spacer Tabs Spacer Tabs positioned for use on 1" diameter upper shaft Place the shaft clamp over the upper shaft above the arrow on the safety decal. Position the clamp base under the upper shaft and align the shaft clamp and clamp base screw holes (use spacer tabs be- tween shaft clamp and clamp base if nec- essary to secure clamp, i.e.
  • Page 6 30 inches (76 cm) CONFIGURING YOUR UNIT You can configure your unit using a trimmer head for grass and light weeds, or a weed blade for cutting grass, weeds, and brush up to 1/2 inch (1 cm) in diameter. To assemble your unit, go to the section for the desired configuration and follow the instructions.
  • Page 7 Do not use any blades, or fastening hardware other than the washers and nuts shown in the following illustrations. These parts must be provided by Poulan/Weed Eater and installed as shown below. Failure to use proper parts can cause the blade to fly off and seriously hurt you or others.

  • Page 8: Operation

    The BLADE is designed for cutting grass, weeds, and brush up to 1/2 inch (1 cm) in diameter. TRIMMER HEAD The TRIMMER HEAD holds cutting line and is designed for cutting grass and light weeds. OPERATING THE COUPLER Your powerhead is equipped with a coupler which enables optional attachments to be installed.

  • Page 9: Cutting Methods

    MENT WITH TRIMMER HEAD WARNING: Always wear eye protec- tion. Never lean over the trimmer head. Rocks or debris can ricochet or be thrown into eyes and face and cause blindness or other serious injury. Before trimming, bring engine to a speed suffi- cient to cut material to be trimmed.
  • Page 10 This technique increases line wear. Scalping MOWING - - Your trimmer is ideal for mowing in places conventional lawn mowers cannot reach. In the mowing position, keep the line parallel to the ground. Avoid pressing the head into the ground as this can scalp the ground and damage the tool.

  • Page 11: Maintenance

    S Blade Shield - - Discontinue use of brushcut- ter attachment if blade shield is damaged. S Trimmer Shield - - Discontinue use of brush- cutter attachment if trimmer shield is dam- aged. CHECK FOR LOOSE FASTENERS...

  • Page 12: Blade Replacement

    LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each new Poulan PRO! ! ! ! brand gasoline tool or at- tachment is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase.
