Manual de Instrucciones
For Occasional Use Only
WARNING:
Read and follow all Safety Rules and Operating Instructions before
using this product. Failure to do so can result in serious injury.
ADVERTENCIA:
Lea el manual de instrucciones y siga todas las advertencias e
instrucciones de seguridad. El no hacerlo puede resultar en le-
siones graves.
AVERTISSEMENT:
Lire le manuel d'instructions et bien respecter tous les avertisse-
ments et toutes les instructions de sécurité. Tout défaut de le
faire pourrait entraîner des blessures graves.
Electrolux Home Products, Inc.
250 Bobby Jones Expressway
Augusta, GA 30907
Copyright E2002 Electrolux Home Products, Inc.
Instruction Manual
Manuel d'Instructions
530163732
R
PP035
11/11/02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Poulan Pro 530163732
Summary of Contents for Poulan Pro 530163732
- Page 1 Lire le manuel d’instructions et bien respecter tous les avertisse- ments et toutes les instructions de sécurité. Tout défaut de le faire pourrait entraîner des blessures graves. Electrolux Home Products, Inc. 250 Bobby Jones Expressway Augusta, GA 30907 Copyright E2002 Electrolux Home Products, Inc. PP035 530163732 11/11/02...
-
Page 2: Safety Rules
Never use flailing de- vices with any attachment. This unit (when used with supplied line trimmer attachment) is designed for line trimmer use only. Use of any other accessories with line trimmer attach- ment will increase the risk of injury. - Page 3 Look for and repair fuel leaks before use. Keep in good working condition. S Replace trimmer head parts that are chipped, cracked, broken, or damaged in any other way before using the unit. S Maintain unit according to recommended procedures.
- Page 4 Blade can thrust violently away from material it does not cut. Blade thrust can cause amputation of arms or legs. WARNING: Do not use trimmer head as a fastening device for the blade. WARNING: The blade continues to spin after the throttle is released or engine is turned off.
- Page 5 The tines become very sharp from use. S Do not run unit at high speed unless culti- vating. HEDGE TRIMMER SAFETY DANGER: RISK OF CUT; KEEP HANDS AWAY FROM BLADE -- Blade moves momentarily after the trigger is re- leased.
- Page 6 WARNING: To prevent serious inju- ry, do not use more than one boom extension with a pole pruner attachment. WARNING: Keep the pruner away from power lines or electrical wires. S Only use for pruning limbs or branches up to 4 inches in diameter. S Do not operate the unit faster than the speed needed to prune.
-
Page 7: Adjusting The Handle
Knob TIGHTEN 2. Remove shipping protector from coupler. 3. Remove the tube cap from the trimmer at- tachment (if present). 4. Position locking/release button of attach- ment into guide recess of coupler. 5. Push the attachment into the coupler until the locking/release button snaps into the primary hole. -
Page 8: Operation
2-cycle air-cooled engine oil designed to be mixed at a ratio of 40:1. Poulan/Weed Eater brand synthetic oil is recommended. Mix gasoline and oil at a ratio of 40:1. A 40:1 ratio is obtained by mixing 3.2 ounces (95 ml) of oil... -
Page 9: Starting A Cold Engine
ON/OFF Switch HOW TO START YOUR UNIT WARNING: The trimmer head will turn while starting the engine. Avoid any contact with the muffler. A hot muf- fler can cause serious burns. STARTING A COLD ENGINE (or a warm engine after running out of... - Page 10 TRIMMER LINE ADVANCE The trimmer line will advance approximately 2 in. (5 cm) each time the bottom of the trimmer head is tapped on the ground with the engine running at full throttle. The most efficient line length is the maximum length allowed by the line limiter.
-
Page 11: Cutting Methods
Always tap the trimmer head on a grassy area. Tapping on surfaces such as concrete or asphalt can cause excessive wear to the trimmer head. If the line is worn down to 2 in. (5 cm) or less, more than one tap will be required to obtain the most efficient line length. -
Page 12: Service And Adjustments
Idle Speed Adjustment Allow engine to idle. Adjust speed until engine runs without trimmer head or any optional at- tachment moving or spinning (idle too fast) or engine stalling (idle speed too slow). S Turn idle speed screw clockwise to increase engine speed if engine stalls or dies. -
Page 13: Seasonal Storage
S Turn idle speed screw counterclockwise to decrease engine speed if trimmer head or any optional attachment moves or spins at idle. WARNING: Recheck the idle speed after each adjustment. The trimmer head or any optional attachment must not move or spin at idle speed to avoid serious injury to the operator or others. -
Page 14: Troubleshooting Table
TROUBLESHOOTING TABLE WARNING: Always stop unit and disconnect spark plug before performing all of the recommended remedies below except remedies that require operation of the unit. TROUBLE CAUSE Engine will not 1. ON/OFF switch in start. OFF position. 2. Engine flooded. 3. -
Page 15: Limited Warranty
LIMITED WARRANTY ELECTROLUX HOME PRODUCTS, INC., warrants to the original purchaser that each Poulan PROr brand gasoline tool or at- tachment is free from defects in material and workmanship and agrees to repair or replace under this warranty any defective gasoline product or attachment as follows from the original date of purchase. - Page 16 TROLUX HOME PRODUCTS, INC., servic- ing center. If you have any questions regard- ing your warranty rights and responsibilities, you should contact your nearest authorized service center or call ELECTROLUX HOME PRODUCTS, INC., at 1--800--554--6723. WARRANTY PERIOD: Any warranted part which is not scheduled for replacement as re- quired maintenance, or which is scheduled only for regular inspection to the effect of “re-...
