K10145
Side
2 pcs
K13360
Suspension list
1 pcs
L06460
Door
1 pcs
Drawer slide left
300
1 pcs
Bumper
Screw flh
7x1,5
3,5x15 mm
2 pcs
10 pcs
20-11-2014 1
/
DO80,060,000
K11170
Base-top
2 pcs
Drawer slide right
300
1 pcs
BP00205-BP00250
Screw flh
Euro screw
3,5x45 mm
6,3x11 mm
8 pcs
4 pcs
O845,060-050-040
K12160
Shelf
2 pcs
BP00417
Mounting plate
Hinge 107 degrees
2 pcs
Shelf support
45x55x30x2 mm
5x7 mm Plast
8 pcs
K13185
Back panel
1 pcs
BP00418
2 pcs
Angle
2 pcs
1 /
8
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Kvik O845-060-050-040
Summary of Contents for Kvik O845-060-050-040
- Page 1 O845,060-050-040 DO80,060,000 K10145 K11170 K12160 Base-top Side Shelf K13185 Back panel 2 pcs 2 pcs 2 pcs K13360 Suspension list 1 pcs 1 pcs L06460 Door 1 pcs BP00417 Drawer slide left BP00418 Drawer slide right Mounting plate Hinge 107 degrees 2 pcs 2 pcs 1 pcs...
