IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
PR827ES

SNOW THROWER

Always Wear Eye Protection During Operation
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
436134 06.22.10 TH
Printed in the U.S.A.
