Summary of Contents for Draneer TIGER MOTH 120
- Page 1 120 A IGER SSEMBLY NSTRUCTIONS SPECIFICATIONS Wing Span: 1920mm Length: 1580mm Radio: 4 channel with 6 servos Flying Weight: 4200g...
-
Page 2: Aileron Assembly
AILERON ASSEMBLY Start by removing the servo cover from the bottom of the lower wing panel. Locate the servo mounting blocks in the parts bag. - Page 3 AILERON ASSEMBLY CONTINUED Place your servo on the servo cover and when satisfied with the fit, CA glue the mounting blocks in place. Taking care not to glue your servo to the mounting blocks.
- Page 4 AILERON ASSEMBLY CONTINUED Install a servo extension (not provided) to your servo and place the assembly into the wing, using the guide string to pull the extension through the wing. Use four 3x8mm screws to secure the assembly to the wing. Repeat the Aileron Assembly Step 1 for the other lower wing panel.
-
Page 5: Fuselage Assembly
FUSELAGE ASSEMBLY Locate the two holes in the bottom rear of the fuselage and carefully remove the covering material. Locate the horizontal stabilizer and remove the material as you did with the rear fuselage. - Page 6 FUSELAGE ASSEMBLY CONTINUED Using the inside servo mount as a guide, cut the material on each side of the rear fuselage for the servo installation as shown. Install two servo extensions (not provided) to 2 servos for mounting into the rear of the fuselage sides for controlling your elevators.
- Page 7 FUSELAGE ASSEMBLY CONTINUED Locate the vertical stabilizer and the two mounting screws from the hardware package. Place the screws in the bottom rear holes of the fuselage and push the screws into the hole until it passes through the stabilizer saddle.
- Page 8 FUSELAGE ASSEMBLY CONTINUED Mount the horizontal stabilizer onto the fuselage stabilizer saddle. Passing the mounting screws through the stabilizer with the leading edge of the stabilizer being curved to match the curve in the fuselage. Mount the vertical stabilizer onto the mounting screws and snug the screws. With the fuselage on a flat and level surface, measure the distance from a center point at the firewall of the fuselage to the outer edge of the horizontal stabilizer on both sides.
-
Page 9: Tail Wheel Assembly
TAIL WHEEL ASSEMBLY Locate the tail wheel assembly in the hardware package and shape it as shown in the photo. Using four 2x8mm screws, mount the tail wheel assembly to the rear of the fuselage, being careful to center the assembly. - Page 10 TAIL WHEEL ASSEMBLY CONTINUED Drill a hole into the bottom of the rudder to actuate the tail wheel as shown in the photo. SERVO HARDWARE SETUP Install the actuator hardware for both elevator servos, as shown in the photo.
- Page 11 UPPER WING CABANE INSTALLATION Locate on the inside tank area the three pre-drilled holes and with a pin, punch through the covering material.
- Page 12 UPPER WING CABANE INSTALLATION CONTINUED Lay out and mark the cabane pieces, as shown in the photo. With a flat file or sandpaper, taper the edges of the cabane tabs so that the cabanes slide onto the tabs with ease.
- Page 13 Attach the lower cabanes to the fuselage sides with 1/4" sheet metal screws provided in the hardware package. Do this for both sides. Use the 1/2" machine screws and lock nuts to fasten the upper wing center section to the cabanes. On the rear cabane, fasten the guide wire bracket to the upper cabane.
- Page 14 LOWER WING ASSEMBLY Carefully cut out the servo wire and wing bolt holes as in the left photo. Mount the guide wire tabs near the leading edge of the lower wing, as in the photo on the right. Locate the outer wing struts and as in the previous step, with the upper wing, prepare the tabs to accept the struts.
- Page 15 LOWER WING ASSEMBLY CONTINUED Assemble the lower wing on the fuselage and measure the guide wire length. Use the aluminum crimps to fasten the wires to the tabs. Pull the wires snug, but not tight, and crimp the ends of the aluminum crimps.
-
Page 16: Landing Gear Assembly
LANDING GEAR ASSEMBLY On the bottom of the fuselage, locate the landing gear holes and cut out carefully. Set the landing gear into position and secure in place with the hardware provided. Now is the time to glue the landing gear fairings in place. -
Page 17: Cockpit Installation
COCKPIT INSTALLATION Locate the cockpit floors and install using the hardware provided. Locate the instrument panel decal and install at this time also. -
Page 18: Motor Installation
COCKPIT INSTALLATION CONTINUED Lay out the windshields and the rubber combing. The thinner pieces are for the windshield and the thicker pieces are for the cockpit edges. Use a rubber base glue like “RC 56” to clue the pieces to the windshield and cockpit edge. - Page 19 MOTOR INSTALLATION CONTINUED Mount your engine to the motor mounts as shown in the photo. Check that the center line on the engine aligns with the center line on the firewall. Drill the firewall for the motor mount using the blind nuts and machine screws in the hardware package to fasten the mount to the firewall.
- Page 20 MOTOR INSTALLATION CONTINUED Place the engine cowl on the fuselage positioning the cowl so at least 1/8" of the engine extends through the front of the cowl. Mark and measure where your exhaust pipe or muffler will exit the cowl and make cutouts carefully.
-
Page 21: Decal Installation
FINISH DETAILS The radio, tank and pull pull rudder installation is very straight forward and everyone has their own way of installing these items. DECAL INSTALLATION Install decals and balance the model. The center of gravity should be approximately 5.5" back from the leaning edge of the top wing. - Page 22 FINISH Enjoy flying your new CMP Tiger Moth.
