OWNER'S MANUAL
Model LTT354
Mfg. ID No. 96072001200
Product No. 960 72 00-12
54 Inch Mower
Grass Catcher
Assembly
Operation
Customer Responsibilities
Repair Parts
406288 06.05.06 rad
Printed in U.S.A.

Advertisement

loading

  Related Manuals for Electrolux 406288

  Summary of Contents for Electrolux 406288

  • Page 1 OWNER’S MANUAL Model LTT354 Mfg. ID No. 96072001200 Product No. 960 72 00-12 54 Inch Mower Grass Catcher • Assembly • Operation • Customer Responsibilities • Repair Parts 406288 06.05.06 rad Printed in U.S.A.
  • Page 2: Safety Rules

    Safe Operation Practices for Ride-On Mowers IMPORTANT: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. WARNING: In order to prevent ac- ci den tal starting when setting up, trans port ing, ad just ing or making re- pairs, al ways dis con nect spark plug...
  • Page 3: Table Of Contents

    Safe Operation Practices for Ride-On Mowers IV. TOWING • Tow only with a machine that has a hitch designed for towing. Do not attach towed equipment except at the hitch point. • Follow the manufacturer's recommendation for weight limits for towed equipment and towing on slopes. •...
  • Page 4: Carton Contents

    READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE ASSEMBLING OR OPERATING YOUR GRASS CATCH ER. Compare the illustrations with the carton contents to familiarize yourself with the parts before starting the assembly. Study the operating instructions and safety precautions thoroughly to insure proper functioning of your Grass Catcher and to prevent injury to yourself and others.
  • Page 5: Assembly

    BAGGER SUPPORT ASSEMBLY 1. Align support assembly pin with hole in drawbar and hang assembly over the shoulder bolts. 2. Be sure support assembly is seated properly and secure with retainer spring supplied. SHOULDER BOLTS SUPPORT ASSEMBLY RETAINER SPRING FIG. 1 ASSEMBLY MOUNTING COVER ASSEMBLY TO SUPPORT ASSEMBLY (See Fig.
  • Page 6 CONTAINER ASSEMBLY (See Fig. 3) 1. Place bottom half inside of top half, as shown. 2. Place one foot inside bottom half and lift top half to meet bottom half. 3. Press halves tightly together while lifting top to lock into place as shown.
  • Page 7 LOWER CHUTE (See Fig. 5) 1. Raise and hold defl ector shield in upright position. 2. Place slot in lower chute over tab on mower and position lower chute over mower opening as shown. 3. Hook rear latch into fl ange hole on back of mower. 4.
  • Page 8: Operation

    TIPS FOR IMPROVED BAGGING OPE RA TION: Follow the mower operation instructions in your tractor owner's manual. When operating your grass catcher on a lawn where grass and leaf bagging equipment has not been used, you are picking up thatch and debris that has accumulated for long periods of time.
  • Page 9: Customer Responsibilities

    CUSTOMER RESPONSIBILITIES GENERAL RECOMMENDATIONS Always observe safety rules when performing any main- te nance. • Before each use check for loose fasteners. • Clean unit thoroughly after each use. BLADE CARE For best results mower blades must be kept sharp. Re place bent or damaged blades.
  • Page 10: Repair Parts

    REPAIR PARTS/PIÈCES DE RECHANGE GRASS CATCHER - MODEL LTT354 (MFG. ID 96072001200) / RAMASSE-HERBE - MODÈLE LTT354 (MFG. ID 96072001200) PRODUCT NO. 960 72 00-12 / NUMÈRO DE PRODUIT 960 72 00-12...
  • Page 11 REPAIR PARTS/PIÈCES DE RECHANGE GRASS CATCHER - MODEL LTT354 (MFG. ID 96072001200) / RAMASSE-HERBE - MODÈLE LTT354 (MFG. ID 96072001200) PRODUCT NO. 960 72 00-12 / NUMÈRO DE PRODUIT 960 72 00-12 PART DESCRIPTION 532069180 Nut, Crown lock #10-24 532192709 Screen, Cover 532195373 Cover Assembly...
