Poulan Pro 271150 Owner's Manual

13.5 hp 38 inch lawn tractor
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL NO. 271150
13.5 HP 38 INCH
LAWN TRACTOR
•
Assembly
•
For Parts and Service, contact our authorized distributor:
call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886
Operation
•
Maintenance
•
Ser vice and Adjustments
•
Troubleshooting
•
Repair Parts
185514 11.25.02 RD
PRINTED IN U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Poulan Pro 271150

Summary of Contents for Poulan Pro 271150

  • Page 1 MODEL NO. 271150 13.5 HP 38 INCH LAWN TRACTOR • Assembly • Operation • For Parts and Service, contact our authorized distributor: call 1-800-849-1297 For Technical Assistance: call 1-800-829-5886 Maintenance • Ser vice and Adjustments • Troubleshooting • Repair Parts 185514 11.25.02 RD...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Rules ... 2 Product Specifi cations ... 5 Assembly/Pre-Operation ... 7 Operation... 10 Maintenance Schedule ... 16 IMPORTANT: This cutting machine is ca pa ble of amputating hands and feet and throw- ing objects. Failure to observe the fol low ing safety instructions could result in serious injury or death.
  • Page 3 • Do not mow near drop-offs, ditches, or embankments. The mower could suddenly turn over if a wheel is over the edge of a cliff or ditch, or if an edge caves in. • Do not mow on wet grass. Reduced traction could cause sliding.
  • Page 4 • Avoid starting or stopping on a slope. If tires lose traction, dis en gage the blades and proceed slowly straight down the slope. • If machine stops while going uphill, disengage blades, shift into reverse and back down slowly. •...

  • Page 5: Product Specifi Cations

    PRODUCT SPECIFICATIONS Gasoline 1.25 Capacity and Unleaded and Type: Regular Oil Type SAE 30 (above 32°F) (API-SF-SJ): SAE 5W-30 (below 32°F) Oil Capacity: 3 Pints Spark Plug: Champion RC12YC (Gap: .030") Ground Speed (MPH): Forward: Reverse: Tire Pressure: Front: Rear: Charging 3 Amps Battery System:...

  • Page 6: Unassembled Parts

    UNASSEMBLED PARTS Steering Wheel Insert (1) Hex Bolt 1/4-28 x 1-1/4 Steering Wheel Adapter (1) Oil Drain Tube For Future Use Keys (2) Keys Steering Wheel (1) Hex nut 1/2-20 (1) Large Flat Washer (1) Locknut 1/4-28 Steering Boot Seat (1) Washer 17/32 x 1-3/16 x 12 Gauge (1)Knob...

  • Page 7: Assembly/Pre-Operation

    ASSEMBLY/PRE-OPERATION Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. To ensure safe and proper operation of your tractor all parts and hardware you as sem ble must be tightened securely. Use the correct tools as nec es sary to in sure proper tightness.
  • Page 8 HOW TO SET UP YOUR TRACTOR INSTALL SEAT Adjust seat before tightening adjustment knob. 1. Remove adjustment knob and fl at washer securing seat to cardboard packing and set aside for assembly of seat to tractor. 2. Pivot seat upward and remove from the cardboard packing.
  • Page 9 5. Press lift lever plunger and raise at tach ment lift lever to its highest posi- tion. 6. Start the engine. After engine has started, move throttle control to idle position. 7. Depress clutch/brake pedal into full "BRAKE" position and hold. Move gearshift lever to 1st gear.

  • Page 10: Operation

    These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. REVERSE HIGH NEUTRAL LIGHTS ON ENGINE ON ENGINE OFF OIL PRESSURE FUEL OVER TEMP LIGHT ATTACHMENT ATTACHMENT CLUTCH ENGAGED CLUTCH DISENGAGED FREE WHEEL (Automatic Models only) Failure to follow instructions...
  • Page 11 KNOW YOUR TRACTOR READ THIS OWNER'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Throttle/Choke Control Clutch/Brake Pedal...
  • Page 12 The op er a tion of any trac tor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Al ways wear safety glass es or eye shields while op er at ing your trac tor or per form ing any ad just ments or repairs.
  • Page 13 tip with the engine not running. These heights are approximate and may vary depending upon soil conditions, height of grass and types of grass being mowed. • The average lawn should be cut to ap- prox i mate ly 2-1/2 inches during the cool season and to over 3 inches during hot months.
  • Page 14 ADD GASOLINE • Fill fuel tank to bottom of fi ller neck. Do not overfi ll. Use fresh, clean, regular un lead ed gasoline with a minimum of 87 octane. (Use of leaded gasoline will increase carbon and lead oxide deposits and reduce valve life).
  • Page 15 MOWING TIPS • Tire chains cannot be used when the mower hous ing is attached to tractor. • Mower should be properly leveled for best mowing performance. See “TO LEVEL MOWER HOUSING” in the Service and Adjustments sec tion of this manual.

  • Page 16: Maintenance Schedule

    MAINTENANCE SCHEDULE FILL IN DATES AS YOU COMPLETE REGULAR SERVICE Check Brake Operation Check Tire Pressure Check Operator Presence and Interlock Systems Check for Loose Fasteners Sharpen/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Check Transaxle Cooling Check V-Belts Check Engine Oil Level Change Engine Oil (with oil filter)

  • Page 17: Place

    TRACTOR Always observe safety rules when per- form ing any main te nance. BRAKE OPERATION If tractor requires more than six (6) feet stopping distance at high speed in high est gear, then brake must be ad just ed. (See “TO ADJUST BRAKE”...

  • Page 18: Place

    NOTE: The original equipment battery on your tractor is maintenance free. Do not attempt to open or remove caps or cov ers. Adding or checking level of elec tro lyte is not necessary. TO CLEAN BATTERY AND TER MI NALS Corrosion and dirt on the battery and terminals can cause the battery to “leak”...

  • Page 19: Place

    1. Pull up on air fi lter cover handle and rotate towards engine. 2. Remove cover. 3. Carefully remove air fi lter cartridge and pre-cleaner from base. 4. Clean base carefully to prevent debris from falling into carburetor. NOTE: If very dirty or damaged, replace cartridge.

  • Page 20: Service And Adjustments

    SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER- VICE OR AD JUST MENTS: 1. Depress clutch/brake pedal fully and set parking brake. 2. Place gearshift lever in neutral (N) position. 3. Place attachment clutch in “DISENGAGED” position. 4.

  • Page 21: Place

    TO LEVEL MOWER HOUSING Adjust the mower while tractor is parked on level ground or driveway. Make sure tires are properly infl ated (See “PROD- UCT SPECIFICATIONS” section of this man u al). If tires are over or underinfl ated, you will not properly adjust your mower.

  • Page 22: Place

    3. Roll belt off engine pulley. 4. Disconnect R.H. suspension arm from rear deck brack et by removing retainer spring. 5. Work belt off both mandrel pulleys and idler pulleys. 6. Pull belt away from mower. BELT INSTALLATION - 1. Work new belt around both mandrel pulleys and idler pulleys.

  • Page 23: Place

    Engine Pulley Clutching Idler Stationary Idler Center Span Transaxle Keeper Pulley TO AD JUST STEER ING WHEEL ALIGN- MENT If steering wheel crossbars are not hor i zon tal (left to right) when wheels are positioned straight forward, remove steer- ing wheel and reassemble with crossbars horizontal.

  • Page 24: Light

    1. Lift seat pan to raised position. 2. Disconnect BLACK battery cable fi rst then RED battery cable and carefully remove battery from trac tor. 3. Install new battery with terminals in same position as old battery. 4. First connect RED battery cable to positive (+) terminal with hex bolt and keps nut as shown.

  • Page 25: Storage

    Immediately prepare your tractor for stor- age at the end of the season or if the trac- tor will not be used for 30 days or more. WARNING: Never store the trac tor with gas o line in the tank inside a building where fumes may reach an open fl...

  • Page 26: Troubleshooting

    TROUBLESHOOTING CHART PROBLEM CAUSE Will not start 1. Out of fuel. 2. Engine not “CHOKED” properly. 3. Engine fl ooded. 4. Bad spark plug. 5. Dirty air fi lter. 6. Dirty fuel fi lter. 7 Water in fuel. 8. Loose or damaged wiring. 9.

  • Page 27: Place

    TROUBLESHOOTING CHART PROBLEM CAUSE Loss of power 1. Cutting too much grass/too fast. 2. Throttle in “CHOKE” position. 3. Build-up of grass, leaves and trash under mower. 4. Dirty air fi lter. 5. Low oil level/dirty oil. 6. Faulty spark plug. 7.
  • Page 28 TROUBLESHOOTING CHART PROBLEM CAUSE Mower blades will 1. Obstruction in clutch not rotate mechanism. 2. Worn/damaged mower drive belt. 3. Frozen idler pulley. 4. Frozen blade mandrel. Poor grass 1. Engine speed too slow. discharge 2. Travel speed too fast. 3.

  • Page 29: Place

    TRACTOR -- MODEL NUMBER 271150 SCHEMATIC AMMETER (OPTIONAL) WHITE CLUTCH / BRAKE IGNITION SWITCH (OPTIONAL) BLUE FUEL SHUT-OFF SOLENOID (IF SO EQUIPPED) YOUR TRACTOR IS EQUIPPED WITH A SPECIAL ALTERNATOR SYSTEM. THE LIGHTS ARE NOT CONNECTED TO THE BATTERY, BUT HAVE THEIR OWN ELECTRICAL SOURCE.

  • Page 30: Repair Parts

    TRACTOR -- MODEL NUMBER 271150 ELECTRICAL REPAIR PARTS...

  • Page 31: Light

    TRACTOR -- MODEL NUMBER 271150 ELECTRICAL KEY PART NO. NO. NOTE: All component dimensions given in U. S. inches 1 inch = 25.4 mm DESCRIPTION 163465 Battery 74760412 Bolt, Hex Head 1/4-20 unc x 3/4 176689 Box Battery Fender 176138...
  • Page 32 TRACTOR -- MODEL NUMBER 271150 CHASSIS AND ENCLOSURES...

  • Page 33: Light

    TRACTOR -- MODEL NUMBER 271150 CHASSIS AND ENCLOSURES KEY PART NO. NO. NOTE: All component dimensions given in U. S. inches 1 inch = 25.4 mm DESCRIPTION 174620 Chassis 176554 Drawbar 17060612 Screw 3/8-16 x 3/4 155272 Bumper Hood/Dash 174643X014 Saddle Slkscr Flt LT...
  • Page 34 TRACTOR -- MODEL NUMBER 271150 GROUND DRIVE...
  • Page 35 TRACTOR -- MODEL NUMBER 271150 GROUND DRIVE KEY PART NO. NO. DESCRIPTION - - - - - - Tran sax le Dana D4360-139 (Order parts from transaxle Manufacturer) 146682 Spring Return Brake T/a Zinc 123666X Pulley Transaxle 18/20" tires 12000028...
  • Page 36 TRACTOR -- MODEL NUMBER 271150 STEERING...
  • Page 37 TRACTOR -- MODEL NUMBER 271150 STEERING KEY PART NO. NO. NOTE: All component dimensions given in U. S. inches DESCRIPTION 140044X428 Steering Wheel 175131 Axle Assembly 169840 Spin dle Assembly, L.H. 169839 Spin dle Assembly, R.H. 6266H Bearing, Race, Thrust, Hardened...
  • Page 38 TRACTOR -- MODEL NUMBER 271150 ENGINE OPTIONAL EQUIPMENT Spark Arrester...
  • Page 39 TRACTOR -- MODEL NUMBER 271150 ENGINE KEY PART NO. NO. NOTE: All component dimensions given in U. S. inches 1 inch = 25.4 mm DESCRIPTION 170551 Control Th/ch 17720408 Screw Hex Thd Cut 1/4-20 x 1/2 - - - - - -...

  • Page 40: Seat Assembly

    TRACTOR -- MODEL NUMBER 271150 SEAT ASSEMBLY KEY PART KEY PART NO. NO. NO. NO. DESCRIPTION DESCRIPTION 127427 Seat 140551 Bracket Pvt St 71110616 Bolt Fin Hex 3/8-16unc x 1 19131610 Washer Flat 13/32 x1 x10 Ga 145006 Clip Push-In Hinged...

  • Page 41: Place

    TRACTOR -- MODEL NUMBER 271150 DECALS KEY PART NO. NO. DESCRIPTION 177109 Decal Lower Dash 176394 Decal Engine 171828 Decal Hood 171829 Decal Fender 145005 Decal Battery Danger 186216 Decal Replacement 171830 Decal Steering 156867 Decal, Oper sdl P/L Gear...
  • Page 42 TRACTOR -- MODEL NUMBER 271150 LIFT ASSEMBLY 17 18 20...
  • Page 43 TRACTOR -- MODEL NUMBER 271150 LIFT ASSEMBLY KEY PART NO. NO. NOTE: All component dimensions given in U. S. inches 1 inch = 25.4 mm DESCRIPTION 159460 Wire Asm Inner W/plunger 159471 Shaft Asm Lift 105767X Pin Groove 1 500 Zinc...

  • Page 44: Mower Deck

    TRACTOR -- MODEL NUMBER 271150 MOWER DECK 153 154...

  • Page 45: Place

    TRACTOR -- MODEL NUMBER 271150 MOWER DECK KEY PART NO. NO. DESCRIPTION 170280 Mower Housing Assembly 72140506 Bolt, Carriage 5/16-18 x 3/4 138017 Bracket Asm. Fram Sway Bar 169970 Bracket, Asm. Deck Sway 4939M Retainer, Spring 178024 Bar Sway Deck...

  • Page 46: Warranty

    LIMITED WARRANTY The Manufacturer warrants to the original consumer purchaser that this product as manufactured is free from defects in materials and work man ship. For a period of one (1) year from date of purchase by the original consumer purchaser, we will repair or replace, at our option, without charge for parts or labor incurred in replac- ing parts, any part which we fi...
