3. Carry Case

4. Main Data Link Cable

-
Connects vehicle side DLC and MULTISCAN head unit for data
transmission.
-
Connecting parts on both ends
are exactly
simply put any one end to the
head unit, and then hook the
other end to the vehicle side
DLC
appropriate adaptor
5. Power Cable 1 – Cigarette Lighter
-
Supplies power to the head unit
from the cigarette lighter socket.
Used when DLC is located near
the driver or passenger seat and
power is not supplied through
DLC.
-
LED lights on both ends turn ON
when power is properly supplied.
-
The metal plunger part in the end of cigarette lighter connector is
For MULTISCAN plus
(P/N. 3003-0003)
Provides convenient transportation and the
protection
components from outer physical impact during
the transportation and storage. Carry case is
provided when purchasing the head unit and at
least one software package together. Includes
keys and dial lock
(P/N. 3001-0001)
same, therefore,
after connecting
Chapter 2 - 4
of the head
an
(P/N. 3000-0004)
unit and other
