Vendor: S000053
ASSEMBLY INSTRUCTIONS
TETRAS 4' BED
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR TETRAS 4' BED
FRAME.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Please keep small parts out of reach of children.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Assemble in the room of use.
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
www.birlea.com
Page 1 of 5
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Birlea tetras
Summary of Contents for Birlea tetras
- Page 1 Vendor: S000053 ASSEMBLY INSTRUCTIONS TETRAS 4’ BED IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR TETRAS 4’ BED FRAME. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE. HEALTH & SAFETY: DO NOT jump on this bed frame. DO NOT use this bed frame if any parts are missing, damaged or worn.
- Page 2 Vendor: S000053 Parts List Hardware List (found in box 1) Part Description Part Description Headpost (L/R) M6 x 20 mm JCBC Screw Footpost (L/R) M6 x 50 mm JCBC Screw Headend M6 x 35 mm JCBC Screw Footend M6 Nut Side Support Double Slat Cap Side Frame...
- Page 3 Vendor: S000053 Step 1: Fix the headposts (1) to the headend (3) then attach the footposts (2) to the footend (4) using hardware part A. DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 2: Fix the side support (5) to the headposts (1) and footposts (2) using hardware part A.
- Page 4 Vendor: S000053 Step 4: Place the mid support (7) on top of both side frames (6) and secure using hardware parts G and H DO NOT use any power tools as this may damage the frame and will invalidate any claim. Step 5: Fit the base legs (8) to the mid support (7) according to the holes at the side and tightly secure using hardware parts C and D.
- Page 5 • If you have any issues with your item please contact the retailer directly you purchased it from who will be able to resolve any issues with Birlea. • Why don’t you send us photos of your assembled furniture to info@birlea.com...
