Installation instructions
Instructions for use
The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms.
Though designed for the wet environment, direct contact with water should be avoided, for example, when showering.
Mirrors require a GFCI 110 V 60 Hz power source. Flat plug will be supplied with mirror.
We reserve the right to make technical improvments and design modifications to the products illustrated.
MAL_Starck_S19721/16.12.1
1x 150
3x S8
3x 5,5x50
# S1 9721
Advertisement
Related Manuals for DURAVIT Starck S1 9721
Summary of Contents for DURAVIT Starck S1 9721
-
Page 1: Installation Instructions
Leben im Bad Living bathrooms # S1 9721 Starck Installation instructions 1x 150 3x S8 3x 5,5x50 Instructions for use The bathroom furniture range complies with the standards and guidelines applicable at the time of delivery and is designed for use in bathrooms. Though designed for the wet environment, direct contact with water should be avoided, for example, when showering. - Page 2 Lift the mirror up and slide the Detach mirror front with four A 110V GFCI outlet is required. Using a 3/8“ drill bit, drill the mirror backing. screws. Mark the holes to be drilled for anchor holes that have been the anchors.
