- Page 1 MINI-MAX/51-C2 Single Board Computer Technical Manual Date: 4 March, 2005 Document Revision: 1.02 BiPOM Electronics 16301 Blue Ridge Road, Missouri City, Texas 77489 Telephone: 1-713-283-9970. Fax: 1-281-416-2806 E-mail: info@bipom.com Web: www.bipom.com...
-
Page 2: Warranty
© 1996-2004 by BiPOM Electronics. All rights reserved. MINI-MAX/51-C2 Single Board Computer Technical Manual. No part of this work may be reproduced in any manner without written permission of BiPOM Electronics. All trademarked names in this manual are the property of respective owners. - Page 3 1. Overview MINI-MAX/51-C2 is a general purpose, low-cost and highly-expandable micro-controller system. It is based on the ATMEL AT89C51ED2 single-chip Flash micro-controller. This micro-controller features • 64 Kilobytes of In-System Re-programmable Downloadable Flash Memory • 256 bytes of RAM • 1792 bytes of XRAM •...
-
Page 4: Functional Blocks
3. Functional Blocks Figure 1 shows the block diagram of the MINI-MAX/51-C2 system 6…12V Expansion Keypad Power connector connector connector 5 volt Regulator connector 22 MHZ RS232 AT89C51ED2 Crystal connector Controller Analog 24C04A PIC16F818 Input EEPROM controller Connector Figure 1... -
Page 5: In-System Programming
Micro-controller MINI-MAX/51-C2 has an ATMEL AT89C51ED2 micro-controller (U2). Micro-controller ports and power lines are provided on a 20-pin expansion bus for interfacing to peripherals and other external circuits. AT89C51ED2 has 4 ports that are available on the 8051 family of micro-controllers: P0 … P3. - Page 6 PC for In-circuit Programming of the T89C51ED2 through PIC16F818 microcontroller and by T89C51ED2 for data communications. RTS line is used by an external host such as a PC to put MINI-MAX/51-C2 in program or run mode. Therefore, user applications must not use RTS.
- Page 7 A peripheral board can be connected to MINI-MAX/51-C2 either as a piggyback daughter-board using standoffs or can be placed away from the MINI-MAX/51-C2 board using a 20-wire ribbon cable ( Part #: EXPCABLE-6 ). Table 4 shows the pin assignments for the connector.
- Page 8 CAUTION: Depending on the current requirements of the any external circuitry such as peripheral boards that are attached to MINI-MAX/51-C2 and the level of input voltage applied, the power regulator U1 may dissipate enough heat to cause skin injury upon touch. Contact with this regulator should be...
- Page 9 • A peripheral board with four 7-segment LED displays with decimal point (LED-1). Peripheral boards can either be stacked on top of MINI-MAX/51-C2 using stand-offs or connected in a chain configuration using flat ribbon cable. Figure 2 shows how MINI-MAX/51-C2 can be connected to a peripheral board in a stacked fashion.
- Page 10 Please download any suitable development system from http://www.bipom.com/8051dev.shtm http://www.bipom.com/bascom51.shtm http://www.bipom.com/sdcc.shtm Any of the development systems provides MINI-MAX/51-C Loader. Also, stand-alone loaders are available to download program codes to the Mini-Max/51-C2: Windows MINI-MAX/51-C Command-line Loader DOS MINI-MAX/51-C Command-line Loader WinLoad Windows Loader Please visit...
-
Page 11: Board Layout
6. Board Layout Layout of MINI-MAX/51-C2 board is shown below: EEPROM Expansion AT89C51ED2 Socket Connector Analog Terminals Keypad Connector Connector Voltage Regulator RS-232 Power Port Connector... - Page 12 7. Schematics...
