Cut-Off Tool
Herramienta de Corte
Outil à tronçonner
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
IMPORTANTE
Asegúrese de que la persona que va a usar esta
herramienta lea cuidadosamente y comprenda
estas instrucciones antes de empezar a
operarla.
IMPORTANT
Veuillez vous assurer que la personne qui
utilise cet outil lit attentivement et comprend
ces instructions avant de commencer à utiliser
l'outil.
MODEL PTX3
MODELO PTX3
MODÈLE PTX3
Part No. D22714-028-3
Advertisement
Table of Contents
Related Manuals for Porter-Cable PTX3
Summary of Contents for Porter-Cable PTX3
-
Page 1: Instruction Manual
Instruction manual Manual de Instrucciones Manuel d'instructions To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Para obtener más información sobre Porter-Cable, visite nuestro sitio web en: http://www.porter-cable.com Pour de plus amples renseignements concernant Porter-Cable, consultez notre site Web à l'adresse suivante: http://www.porter-cable.com... -
Page 2: Safety Guidelines - Definitions
RISK OF EYE OR HEAD INJURY WHAT COULD HAPPEN • Air powered equipment and power tools are capable of propelling materials such as fasteners, metal chips, saw dust, and other debris at high speed, which could result in serious eye injury. - Page 3 HAZARD RISK OF LOSS OF HEARING WHAT COULD HAPPEN • Long term exposure to noise produced from the opera- tion of air tools can lead to permanent hearing loss. HAZARD RISK TO BREATHING INHALATION HAZARD WHAT COULD HAPPEN • Abrasive tools, such as grinders, sanders, and cut-off tools generate dust and abrasive materials which can be harmful to human lungs and respiratory system.
- Page 4 HAZARD RISK OF INJURY (continued) WHAT COULD HAPPEN • Improperly maintained tools and accessories can cause serious injury. • There is a risk of bursting if the tool is damaged. Use only accessories identified by the manufacturer to be used with specific tools. HAZARD RISK OF ELETRIC SHOCK WHAT COULD HAPPEN...
-
Page 5: Specifications
Free Speed (No Load) Maximum Working Pressure Air Inlet Recommended Hose Size Cutting Wheels Air Consumption @ 90 PSI Accessories Required IMPORTANT: Line pressure or hose inside diameter should be increased to compensate for unusually long air hoses (over 25 feet). Minimum hose diameter should be 3/8” I.D. and fittings should have 1/4”... -
Page 6: Maintenance
Set the air compressor’s regulator to 90 PSI. This tool operates at a maximum 90 PSI pressure. Cutting wheels and spindles should be inspected daily for excessive wear, cracking, and other damage. Replace any cutting wheel showing signs of damage. Depress the throttle safety release and throttle control lever to operate tool. -
Page 7: Repair Parts
REPAIR PARTS Part No. D25391 D25392 D25393 + Only available in Trigger Repair Kit D25394 NOTE: Parts not listed are not serviceable. Description Screw Spindle Chuck Wheel Guard O-Ring O-Ring Spring O-Ring Valve Stem O-Ring Spacer Switch Lock Spring Clamp Spring Pin Spring Pin 7- ENG... -
Page 8: Limited Warranty
• Use reasonable care in the operation and maintenance of the product as described in the Owners Manual(s). • Deliver or ship the product to the nearest Porter-Cable Authorized Warranty Service Center. Freight costs, if any, must be paid by the purchaser.
