Porter-Cable QUICKSAND 335 Instruction Manual

Double insulated random orbit sander
Hide thumbs
Table of Contents

Advertisement

Quick Links

900007 - 02-28-01.QXD
9/26/02
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2001 PORTER-CABLE Corporation
11:46 AM
Page 1
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 27
Double Insulated
Random Orbit Sander
MODEL 335
IMPORTANT
Please make certain that the person who
is to use this equipment carefully reads
and understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 900007 (012)

Advertisement

Table of Contents
loading

Related Manuals for Porter-Cable QUICKSAND 335

Summary of Contents for Porter-Cable QUICKSAND 335

  • Page 1 900007 - 02-28-01.QXD 9/26/02 11:46 AM Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2001 PORTER-CABLE Corporation Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 27 Double Insulated Random Orbit Sander MODEL 335 IMPORTANT...

  • Page 2: Important Safety Instructions

    READ AND FOLLOW ALL INSTRUCTIONS. There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter- Cable and we have advised you.
  • Page 3 20. WEAR EAR PROTECTION to safeguard against possible hearing loss. SAVE THESE INSTRUCTIONS ADDITIONAL SAFETY RULES FOR RANDOM ORBIT SANDERS ALWAYS DISCONNECT the sander cord plug from the power circuit before changing abrasive sheets. USE DUST MASK. Wear a protective mask to minimize breathing in the fine dust created while sanding.

  • Page 4: Additional Safety Rules For Paint Removal

    KEEP HANDS AND BODY PARTS AWAY from rotating disc. Contact with rotating disc cause severe cuts and abrasions. NEVER RUN SANDER with dust container or dust collector assembly removed. Dust could be blown into eyes. WEAR EYE AND FACE PROTECTION. Injury to face and eyes can result if disc flies off or pad ruptures.

  • Page 5: Replacement Parts

    When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C.

  • Page 6: Operating Instructions

    OPERATING INSTRUCTIONS FOREWORD The Porter-Cable Random Orbit Sander provides rapid stock removal with 80 to 100 grit abrasive and swirl-free finishing with 120 to 150 grit abrasive. The Sander is equipped with a reversible pad that can accept 6" diameter, six hole (for six dust extraction) abrasives, with either STIKIT™...
  • Page 7 Place machine on workbench with pad up (see Fig. 4). Clean dust from pad face. Position Hook & Loop Abrasive Disc onto sander pad, aligning the dust extraction holes in paper with holes in pad. CAUTION: Do not use PSA (Pressure Sensitive Adhesive) disc with Hook &...

  • Page 8: Dust Collector

    Place machine on workbench with pad up (see Fig. 5). Clean dust from pad face. Tear a new abrasive disc from roll and position disc to the sander pad. Align the dust extraction holes in paper with holes in pad.

  • Page 9: Pad Brake

    The pad brake uses a belt to provide the braking action. Eventually, this belt may require replacement. If the brake fails to limit pad rotation, send the sander to a Porter-Cable service facility or replace the belt yourself as explained under BELT REPLACEMENT in the MAINTENANCE SECTION of this manual.

  • Page 10: Maintenance

    BRUSH INSPECTION AND LUBRICATION At approximately 200 hours of use, take or send your tool to your nearest Authorized Porter-Cable Service Station to be thoroughly cleaned and inspected; worn parts replaced, when necessary; relubricated with fresh lubricant, if required; reassembled with new brushes; and performance tested.

  • Page 11: Service And Repairs

    These operations, including brush inspection and replacement, should ONLY be performed by either an AUTHORIZED PORTER-CABLE SERVICE STATION or PORTER-CABLE SERVICE CENTER. All repairs made by these agencies are fully guaranteed against defective material and workmanship. We cannot guarantee repairs made or attempted by anyone other than these agencies.
  • Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
  • Page 13 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
