Ethernet Ports - GE PACSystems* RX3i Quick Start Manual

LED LED State
SYS FLT
CPE330 Ethernet Indicators
LED LED State
LINK
(upper)
1Gbps
(lower)

1.3. Ethernet Ports

LAN1 connects to the uppermost RJ-45 connector. It is not switched. LAN2 connects
to the two lower RJ-45 connectors. They are switched internally. Record the IP
Address of each LAN in the space provided (Figure 1).
Each of the embedded Ethernet interfaces automatically senses the data rate
(10 Mbps or 100 Mbps or 1 Gbps), communications mode (half-duplex or full-duplex),
and cabling arrangement (straight-through or crossover) of the attached link.
GFK-2941E
Operating State
Off No port activity detected on USB Interface
On Red RDSD Failure
Blinking Target name mismatch: Press same RDSD
Red pushbutton again to dismiss.
On Red CPU is in Stop/Faulted mode: a fatal fault has
occurred.
Off No fatal faults detected.
Operating State
On Green The corresponding link is physically connected.
Blinking Traffic is detected at the corresponding port.
Green
No connection detected at corresponding port.
Off
On Amber Corresponding network data speed is 1 Gbps.
(LAN1) or
On Green
(LAN2)
Corresponding network data speed is 100 Mbps or
Off
10 Mbps.
May 2016 6
