Instruction
manual
MODELS 333
and 334
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2005 Porter-Cable Corporation
ESPAÑOL: PÁGINA 17
FRANÇAISE : PAGE 33
Double Insulated
Random Orbit Sanders
MODEL
MODEL
333VS
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
332
IMPORTANT
Part No. 913269 - 01-24-05
Advertisement
Table of Contents
Related Manuals for Porter-Cable QUICKSAND 332
Summary of Contents for Porter-Cable QUICKSAND 332
- Page 1 Instruction manual MODELS 333 and 334 To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2005 Porter-Cable Corporation ESPAÑOL: PÁGINA 17 FRANÇAISE : PAGE 33 Double Insulated Random Orbit Sanders MODEL MODEL 333VS IMPORTANT Please make certain that the person who is...
-
Page 2: Table Of Contents
Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage. There are certain applications for which tools and equipment are designed. Porter-Cable strongly recommends that this product NOT be modified and/or used for any application other than for which it was designed. -
Page 3: Safety Guidelines
SAFETY GUIDELINES - DEFINITIONS It is important for you to read and understand this manual. The information it contains relates to protecting YOUR SAFETY and PREVENTING PROBLEMS. The symbols below are used to help you recognize this information. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 4: General Safety Rules
GENERAL SAFETY RULES Read all instructions. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. The term "power tool" in all of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. - Page 5 GENERAL SAFETY RULES d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 6: Additional Specific Safety Rules
Sanding of lead-based paint is not recommended. Lead-based paint should only be removed by a professional. Always maintain a firm grip on the sander handles with both hands to prevent loss of control. Do not operate sander without all guards and covers securely in place. - Page 7 SYMBOL ... volts ... amperes ... hertz ... watts ... kilowatts ... farads µF ... microfarads ... litres ... grams ... kilograms ... bars ... pascals ... hours ... minutes ... seconds ... no-load speed …/min or …min - ... Revolutions or reciprocations per minute or d.c.
-
Page 8: Additional Safety Rules For Paint Removal
ADDITIONAL SAFETY RULES FOR PAINT REMOVAL Extreme care should be taken when removing paint. The peelings, residue, and vapors of paint may contain lead, which is poisonous. Exposure to even low levels of lead can cause irreversible brain and nervous system damage. Young and unborn children are particularly vulnerable. -
Page 9: Carton Contents
MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 10: Functional Description
FUNCTIONAL DESCRIPTION FOREWORD The Porter-Cable Random Orbit Sanders provide rapid stock removal with 80 to 100 grit paper and swirl-free finishing with 120-150 grit paper. Model 332 is equipped to accept 5" diameter STIKIT™ adhesive paper backed abrasives. Model 333 is equipped to accept 5" hook & loop backed abrasives with five dust extraction holes. - Page 11 Place machine on workbench with pad up (see Fig. 3). Clean dust from pad face. Position Hook & Loop Abrasive Disc onto sander pad, aligning the dust extraction holes in paper with holes in pad. NOTE: When using 8-hole abrasive on model 333VS, align the hole pattern in the abrasive with the groove in the sander pad.
-
Page 12: Operation
TO START AND STOP SANDER CAUTION: Make certain the switch is in the “OFF” position, and the power source is the same as that specified on the tool’s nameplate. -
Page 13: Troubleshooting
The pad brake uses a belt to provide the braking action. Eventually, this belt may require replacement. If the brake fails to limit pad rotation, send the sander to a Porter-Cable service facility or replace the belt yourself as explained under BELT REPLACEMENT in the MAINTENANCE SECTION of this manual. -
Page 14: Belt Replacement
SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricated with fresh lubricant. Have new brushes installed, and test the tool for performance. -
Page 15: Service
All quality tools will eventually require servicing, or replacement of parts due to wear from normal use. For assistance with your tool, visit our website at www.porter-cable.com for a list of service centers or call the Customer Care Department at 1-800-487-8665. All repairs made by our service centers are fully guaranteed against defective material and workmanship. -
Page 16: Warranty
PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period. -
Page 17: Español
Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
