BELT SANDER
MODEL352VS
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 899748 - 04-21-03
Advertisement
Table of Contents
Related Manuals for Porter-Cable 352VS
Summary of Contents for Porter-Cable 352VS
-
Page 1: Belt Sander
Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2003 Porter-Cable Corporation ESPAÑOL: PÁGINA 15 FRANÇAISE : PAGE 31 BELT SANDER MODEL352VS IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations. -
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and understand. This information re- lates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. -
Page 3: Personal Safety
Avoid body contact with grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is grounded. Don’t expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. -
Page 4: Specific Safety Rules And Symbols
If you have any questions relative to its application, DO NOT use the tool until you have written Porter-Cable and we have advised you. Technical Service Manager... -
Page 5: Additional Safety Rules For Paint Removal
SYMBOL DEFINITION ... volts ... amperes ... hertz ... watts ... kilowatts µF ... microfarads ... liters ... kilograms N/cm ... newtons per square centimeter ... pascals ... hours ... minutes ... seconds ... alternating current ... three-phase alternating current ... -
Page 6: Replacement Parts
When servicing, use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 7: Functional Description
14-16 16-18 18-20 FUNCTIONAL DESCRIPTION FOREWORD The Porter-Cable Variable Speed Belt Sander (Model 352VS) is designed for removing old paint and varnish, smoothing rough boards, and fine-surfacing wood, metal, plastics, and other materials. OPERATION INSTALLING AND REMOVING THE ABRASIVE BELT DISCONNECT TOOL FROM POWER SOURCE. -
Page 8: Variable Speed
To release the lock button, squeeze the trigger and release. VARIABLE SPEED Model 352VS has a Variable Speed Control. The operating speed is adjustable between 850 SFM (surface feet per minute) and 1300 SFM. The speed is adjusted by turning the thumbwheel, (C) Fig. 2. The first position provides the slowest operating speed (850 SFM) while position 6 is the fastest (1300 SFM). -
Page 9: General Sanding
Hold the sander off the work before starting the motor. Lower the sander to the work, touching the rear part of the belt first. Level the machine when moving it forward. Guide the machine over the work in overlapping strokes. Allow the sander to do the work. - Page 10 Read and follow “ADDITIONAL SAFETY RULES FOR PAINT REMOVAL” section of this manual. The 352VS is an excellent tool for removing old paint and varnish from flat surfaces. However, two problems are common: 1) sanding material that loads the abrasive and, 2) friction heat caused by working too long in one place. To overcome the loading problem, use a coarse grit open coat abrasive belt and a single stroke action.
- Page 11 Fig. 6 The model 352VS sander works very fast and can do a thorough job in a fraction of the time required by hand sanding. Do not rush the job. Give every surface a thorough sanding with each grade of abrasive before changing to finer grits.
-
Page 12: Maintenance
FACTORY SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. - Page 13 ACCESSORIES A complete line of accessories is available from your Porter-Cable · Delta Supplier, Porter-Cable · Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. Please visit our Web Site www.porter-cable.com for a catalog or for the name of your nearest supplier.
- Page 14 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 15 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
