Instruction
manual
Model
BS500
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
PROFESSIONAL POWER TOOLS
Copyright © 2000 PORTER-CABLE Corporation
ESPAÑOL: PÁGINA 21
FRANÇAISE: PAGE 41
Generator
IMPORTANT
Please make certain that the person who is to use this equipment
carefully reads and understands these instructions before starting
operations.
The Model and Serial No. plate is located on the frame. Record
these numbers in the spaces below and retain for future reference.
Model No.
Type
Serial No.
Part No. D21679-008-0
Advertisement
Table of Contents
Related Manuals for Porter-Cable D21679-008-0
Summary of Contents for Porter-Cable D21679-008-0
- Page 1 Instruction manual Model BS500 To learn more about Porter-Cable visit our website at: http://www.porter-cable.com PROFESSIONAL POWER TOOLS Copyright © 2000 PORTER-CABLE Corporation ESPAÑOL: PÁGINA 21 FRANÇAISE: PAGE 41 Generator IMPORTANT Please make certain that the person who is to use this equipment carefully reads and understands these instructions before starting operations.
-
Page 2: Specification
SPECIFICATION MODEL HORSE POWER RATED/SURGE WATTS VOLTAGE AMPERAGE PHASE HERTZ ENGINE SPEED MAX. AMBIENT TEMP. FUEL CAPACITY RUN TIME @ 50%/100% This product is not equipped with a spark arresting muffler. If the product will be used around flammable materials, or on land covered with materials such as agricultural crops, forest, brush, grass, or other similar items, then an approved spark arrester must be installed and is legally required in the state of California. -
