904461 - 09-04-02.qxd
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2002 Porter-Cable Corporation
9/23/02
8:20 AM
Page 1
ROOFING COIL
NAILER
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 25
MODEL RN175
IMPORTANT
Part No. 904461 - 09-04-02
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable RN175
Summary of Contents for Porter-Cable RN175
- Page 1 904461 - 09-04-02.qxd 9/23/02 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2002 Porter-Cable Corporation 8:20 AM Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 25 ROOFING COIL NAILER MODEL RN175 IMPORTANT Please make certain that the person who is...
-
Page 2: Ec Declaration Of Conformity
EN792 13: 2000 Matthew G. Popik Vice President of Engineering Date of Manufacture:___________________________ Fecha de fabricación:, Date de fabrication: Serial No:______________________________________ Número de serie:, Nombre d'ordre 8:20 AM Page 2 PORTER CABLE Porter-Cable Corporation 4825 Highway 45 North Jackson, TN 38305... -
Page 3: General Safety Rules
READ AND FOLLOW ALL INSTRUCTIONS. There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter- Cable and we have advised you. - Page 4 Fig. 8. 15. Do not use tool without safety warning label. If label is missing, damaged or unreadable, contact your Porter-Cable Service Center for a replacement. Fig. 9. 16. Only use parts, fasteners and accessories approved by Porter-Cable.
- Page 5 904461 - 09-04-02.qxd 9/23/02 Fig. 11 22. Do not overreach. Keep proper footing and balance at all times when using or handling the tool. 23. Fire fasteners into work surface only: never into materials too hard to penetrate. Fig. 15. 24.
-
Page 6: Functional Description
If an in-line oiler is not available: place five or six drops of Porter-Cable Air Tool Oil into the tool’s air inlet at the beginning of each workday. -
Page 7: Preparing The Tool
Always connect tool to air supply before loading fasteners (Fig. 18). Do not load fasteners with trigger or safety depressed. Only use approved Porter-Cable fasteners. Operator and others in work area MUST wear safety glasses with side shields. Always wear ANSI Z87.1 approved safety glasses, and hearing protection when preparing or operating the tool. - Page 8 904461 - 09-04-02.qxd 9/23/02 Close magazine cover, close and latch feeder cover (see Fig. 23). 7. Adjust directional exhaust deflector (A) Fig. 24, so that the exhaust air blast will be directed away from the operator. The exhaust deflector provides seven detented positions for directing the exhaust blast away from the operator.
-
Page 9: Operating Instructions
904461 - 09-04-02.qxd 9/23/02 OPERATING INSTRUCTIONS USING THE TOOL WITH SELECTABLE TRIGGERING OPTIONS Complete all steps of PREPARING THE TOOL before using the tool. This tool is shipped from the factory with a selectable trigger set in the “SINGLE SEQUENTIAL ACTUATION” firing mode as described in number 1 below. - Page 10 904461 - 09-04-02.qxd 9/23/02 DANGER: Keep fingers AWAY from trigger when not driving fasteners to avoid accidental firing. Never carry tool with finger on trigger: tool will fire a fastener if safety is bumped. Never point tool at yourself or others in work area. Never attempt to drive a fastener into material that is too hard, or at too steep an angle, or near the edge of the workpiece.
-
Page 11: Troubleshooting
Keep all screws tight. Loose screws can cause personal injury or damage tool. If tool is used without an in-line oiler: place 5 or 6 drops of Porter-Cable Air Tool Oil into the air inlet of the tool at the beginning of each workday. - Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its nailing and stapling tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 13 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
