Instruction
manual
U.S. Patent D456,234
U.S. Patent D456,685
U.S. Patent D458,825
U.S. Utility Patent 6,464,57
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2003 Porter-Cable Corporation
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE
Double Insulated
Disc Grinder
MODEL
7412
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 903552 - 10-03-03
25
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Porter-Cable 7412
Summary of Contents for Porter-Cable 7412
- Page 1 Instruction manual U.S. Patent D456,234 U.S. Patent D456,685 U.S. Patent D458,825 U.S. Utility Patent 6,464,57 To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2003 Porter-Cable Corporation ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE Double Insulated Disc Grinder...
-
Page 2: Safety Guidelines - Definitions
SAFETY GUIDELINES - DEFINITIONS This manual contains information that is important for you to know and under- stand. This information relates to protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay attention to these sections. indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury. -
Page 3: Personal Safety
Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk of electric shock. Do not abuse the cord. Never use the cord to carry the tools or pull the plug from an outlet. Keep cord away from heat, oil, sharp edges or moving parts. - Page 4 There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter-Cable and we have advised you.
-
Page 5: Additional Safety Rules For Paint Removal
ADDITIONAL SAFETY RULES FOR PAINT REMOVAL Extreme care should be taken when removing paint. The peelings, residue, and vapors of paint may contain lead, which is poisonous. Exposure to even low levels of lead can cause irreversible brain and nervous system damage; young and unborn children are particularly vulnerable. -
Page 6: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 7: Extension Cord Selection
16-18 18-20 FUNCTIONAL DESCRIPTION FOREWORD Porter-Cable disc grinders are designed for numerous grinding operations. Typical applications are auto body grinding, smoothing welding beads, removing gates and flash from castings, removing rust and the like. TO START AND STOP THE TOOL Make sure that the switch is “OFF”... - Page 8 Slide the switch button (A) Fig. 1 forward to turn the tool “ON”. When released, the switch button will return to the "OFF" position. To lock the switch in the “ON” position, move the switch to the “ON” position and depress the front end of the switch button (A) Fig.
- Page 9 Fig. 3A 3. Seat the guard on the mounting flange. Rotate the guard to a position that will place the guard between the operator and the grinding wheel (or any other accessory requiring a guard). Tighten the clamp screw (A) Fig. 3A to secure the guard in proper position (see Fig.
-
Page 10: Operation
FACTORY SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. -
Page 11: Service And Repairs
In any communications, please give all information shown on the nameplate of your tool (model number, type, serial number, etc.). ACCESSORIES A complete line of accessories is available from your Porter-Cable• Delta Supplier, Porter-Cable•Delta Factory Service Centers, and Porter- Cable Authorized Service Stations. Please visit our Web Site for a catalog or for the name of your nearest www.porter-cable.com... - Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 13 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
