Porter-Cable 7564 Instruction Manual

Double insulated portable electric drill
Hide thumbs Also See for 7564:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
903549 - 09-30-01.qxd
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2001 Porter-Cable Corporation
2/13/02
9:16 AM
Page 1
Double Insulated
Portable Electric Drill
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 25
MODEL
7564
IMPORTANT
Part No. 903549 - 09-30-01

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7564 and is the answer not in the manual?

Questions and answers

Related Manuals for Porter-Cable 7564

Summary of Contents for Porter-Cable 7564

  • Page 1 903549 - 09-30-01.qxd 2/13/02 Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2001 Porter-Cable Corporation 9:16 AM Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 25 Double Insulated Portable Electric Drill MODEL IMPORTANT Please make certain that the person who is...

  • Page 2: General Safety Rules

    903549 - 09-30-01.qxd 2/13/02 WARNING: SOME DUST CREATED BY POWER SANDING, SAWING, GRINDING, DRILLING, AND OTHER CONSTRUCTION ACTIVITIES contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: · lead from lead-based paints, ·...
  • Page 3 903549 - 09-30-01.qxd 2/13/02 influence of drugs, alcohol, or medication. A moment of inattention while operating power tools may result in serious personal injury. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or long hair can be caught in moving parts.
  • Page 4 NEVER hold work in your hand, lap, or against other parts of your body when drilling. DO NOT use drill as a router or try to elongate or enlarge holes by twisting the drill. Drill bits may break and cause injury.

  • Page 5: Replacement Parts

    When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C.

  • Page 6: Functional Description

    903549 - 09-30-01.qxd 2/13/02 FUNCTIONAL DESCRIPTION FOREWORD Porter-Cable Model 7564 Drill is designed to drill holes of various sizes up to " in wood and " in metal. INSTALLING AND REMOVING DRILL BIT CAUTION: DISCONNECT TOOL FROM POWER SOURCE. The three-jaw chuck is designed for self-centering of the drill bit. Open chuck jaws by turning outer sleeve counterclockwise, when viewing the chuck from the bit end.

  • Page 7: Operation

    HOW TO HOLD THE DRILL WARNING: The front end of drill may be made live if the tool drills into live wiring in a wall. TO PREVENT ACCIDENTAL ELECTRICAL SHOCK, DRILL MUST BE HELD AS SHOWN IN FIG. 4.

  • Page 8: How To Use The Drill

    Locate exact center for hole to be drilled and using a center punch, make a small dent in work. Place tip of drill bit in dent made by center punch, hold drill square with work, and start the motor. Apply steady, even pressure to keep drill bit cutting. Too little pressure will keep the bit from cutting and dull the edges due to excessive friction created by sliding over the surface.

  • Page 9: Maintenance

    The harder the material, the slower the speed required. The softer the material, the faster the speed. When drilling a large hole, it is easier to first drill a smaller hole and then enlarge it to the required size. The use of a lubricant, such as oil, on the drill point helps keep the bit cool, increases drilling action and prolongs drill bit life.

  • Page 10: Service And Repairs

    In any communications, please give all information shown on the nameplate of your tool (model number, type, serial number, etc.). A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations.
  • Page 11 903549 - 09-30-01.qxd 2/13/02 9:17 AM Page 11 NOTES...
  • Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
  • Page 13 Pour obtenir des pièces et accessoires pour les produits Porter-Cable • Delta, s’adresser à tout distributeur Porter- Cable • Delta, centre de service agréé ou centre de service d’usine Porter-Cable • Delta. Si vous n’avez accès à aucun de ces centres, appeler le 888-848-5175 et on vous dirigera vers le centre de service d’usine Porter-Cable •...
