901013 - 12-31-01.qxd
2/11/02
Instruction
manual
To learn more about Porter-Cable
visit our website at:
http://www.porter-cable.com
Copyright © 2001 PORTER-CABLE Corporation
3:01 PM
Page 1
ESPAÑOL: PÁGINA 13
FRANÇAISE : PAGE 25
Double Insulated
Portable Electric Drills
MODEL 2620
3
" Drill
/
8
MODEL 6614
1
" Drill
/
2
MODEL 2621
3
" Keyless Drill
/
8
MODEL 6615
1
" Keyless Drill
/
2
IMPORTANT
Please make certain that the person who is
to use this equipment carefully reads and
understands these instructions before
starting operations.
The Model and Serial No. plate is located on the main
housing of the tool. Record these numbers in the
spaces below and retain for future reference.
Model No. ______________________________________
Type ___________________________________________
Serial No. _______________________________________
Part No. 901013 - 12-31-01
Advertisement
Table of Contents
Related Manuals for Porter-Cable 2620
Summary of Contents for Porter-Cable 2620
- Page 1 901013 - 12-31-01.qxd 2/11/02 3:01 PM Instruction manual To learn more about Porter-Cable visit our website at: http://www.porter-cable.com Copyright © 2001 PORTER-CABLE Corporation Page 1 ESPAÑOL: PÁGINA 13 FRANÇAISE : PAGE 25 Double Insulated Portable Electric Drills MODEL 2620 " Drill MODEL 6614 "...
-
Page 2: Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS. There are certain applications for which this tool was designed. Porter-Cable strongly recommends that this tool NOT be modified and/or used for any application other than for which it was designed. If you have any questions relative to its application DO NOT use the tool until you have written Porter- Cable and we have advised you. - Page 3 DO NOT use bits larger than those recommended. They increase the chance of jamming. Large bits may also overload the drill and damage the motor and gears. USE ONLY the proper chuck key to tighten or loosen the chuck. Do not use chuck if jaws or other parts are cracked or worn.
-
Page 4: Replacement Parts
When servicing use only identical replacement parts. MOTOR Many Porter-Cable tools will operate on either D.C., or single phase 25 to 60 cycle A.C. current and voltage within plus or minus 5 percent of that shown on the specification plate on the tool. Several models, however, are designed for A.C. -
Page 5: Functional Description
901013 - 12-31-01.qxd 2/11/02 3:01 PM FUNCTIONAL DESCRIPTION FOREWORD Porter-Cable drills are designed to drill holes of various sizes in wood and metal as indicated in the following chart: Model # of Drill Type of Bit 2620 Twist Drill Spade Bit... - Page 6 TO START AND STOP DRILL Make sure drill switch is “OFF”. Make sure power circuit voltage is the same as that shown on the specification plate of the drill. Connect drill to power circuit. Squeeze TRIGGER SWITCH (Fig. 3) to start motor. Release trigger to stop motor.
- Page 7 Increases. HOW TO HOLD THE DRILL WARNING: The front end of drill may be made live if the tool drills into live wiring in a wall. TO PREVENT ACCIDENTAL ELECTRICAL SHOCK, DRILL MUST BE HELD AS SHOWN IN FIG. 4. APPLY FORWARD FORCE ON THE PISTOL GRIP HANDLE ONLY, AND ONLY WITH YOUR HANDS.
-
Page 8: How To Use The Drill
Locate exact center for hole to be drilled and using a center punch, make a small dent in work. Place tip of drill bit in dent made by center punch, hold drill square with work, and start the motor. Apply steady, even pressure to keep drill bit cutting. Too little pressure will keep the bit from cutting and dull the edges due to excessive friction created by sliding over the surface. -
Page 9: Maintenance
The harder the material, the slower the speed required. The softer the material, the faster the speed. When drilling a large hole, it is easier to first drill a smaller hole and then enlarge it to the required size. The use of a lubricant, such as oil, on the drill point helps keep the bit cool, increases drilling action and prolongs drill bit life. -
Page 10: Service And Repairs
SERVICE CENTER. At approximately 100 hours of use, take or send your tool to your nearest authorized Porter-Cable Service Station to be thoroughly cleaned and inspected. Have worn parts replaced and lubricate with fresh lubricant. Have new brushes installed, and test the tool for performance. - Page 11 2/11/02 3:01 PM ACCESSORIES A complete line of accessories is available from your Porter-Cable • Delta Supplier, Porter-Cable • Delta Factory Service Centers, and Porter-Cable Authorized Service Stations. Please visit our Web Site for a catalog or for the name of your nearest www.porter-cable.com...
- Page 12 PORTER-CABLE LIMITED ONE YEAR WARRANTY Porter-Cable warrants its Professional Power Tools for a period of one year from the date of original purchase. We will repair or replace at our option, any part or parts of the product and accessories covered under this warranty which, after examination, proves to be defective in workmanship or material during the warranty period.
- Page 13 Porter-Cable • Delta products should be obtained by contacting any Porter-Cable • Delta Distributor, Authorized Service Center, or Porter-Cable • Delta Factory Service Center. If you do not have access to any of these, call 888-848-5175 and you will be directed to the nearest Porter-Cable •...
